BONE-Net:一种新的混合深度学习模型,用于有效的骨质疏松症检测。

IF 2.6 3区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES
PLoS ONE Pub Date : 2025-10-16 eCollection Date: 2025-01-01 DOI:10.1371/journal.pone.0334664
Ishaq Muhammad, Routhu Srinivasa Rao, Bumshik Lee
{"title":"BONE-Net:一种新的混合深度学习模型,用于有效的骨质疏松症检测。","authors":"Ishaq Muhammad, Routhu Srinivasa Rao, Bumshik Lee","doi":"10.1371/journal.pone.0334664","DOIUrl":null,"url":null,"abstract":"<p><p>Osteoporosis is a prevalent bone disease characterized by reduced bone density and an elevated risk of fractures, especially in older adults and postmenopausal women. The clinical consequences of osteoporotic fractures extend beyond pain and disability, contributing substantially to morbidity, mortality, and healthcare costs. Early intervention and accurate detection is therefore essential to improve patient outcomes. This paper introduces an advanced deep-learning methodology to enhance the accuracy and efficiency of osteoporosis detection through knee X-ray analysis. The proposed approach integrates features from two pre-trained models, DenseNet169 and Vision Transformer (ViT), with a custom-designed Attention Model (AM) to capture detailed spatial and channel-specific information from the input images. These fused features are then fed into a fully connected neural network to classify the images as osteoporotic or normal. The results indicate significant improvements in classification accuracy, achieving a high accuracy rate on previously unseen test data. The proposed model achieves superior performance over existing methods and other recent models for osteoporosis detection, with an accuracy of 0.8611, specificity of 0.9474, and precision of 0.9286. Our approach effectively combines convolutional and transformer-based representations, enabling extraction of both local and global features for comprehensive bone characterization. These findings highlight the model's potential to support early diagnosis, timely intervention, and improved patient care in osteoporosis management.</p>","PeriodicalId":20189,"journal":{"name":"PLoS ONE","volume":"20 10","pages":"e0334664"},"PeriodicalIF":2.6000,"publicationDate":"2025-10-16","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12530578/pdf/","citationCount":"0","resultStr":"{\"title\":\"BONE-Net: A novel hybrid deep-learning model for effective osteoporosis detection.\",\"authors\":\"Ishaq Muhammad, Routhu Srinivasa Rao, Bumshik Lee\",\"doi\":\"10.1371/journal.pone.0334664\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Osteoporosis is a prevalent bone disease characterized by reduced bone density and an elevated risk of fractures, especially in older adults and postmenopausal women. The clinical consequences of osteoporotic fractures extend beyond pain and disability, contributing substantially to morbidity, mortality, and healthcare costs. Early intervention and accurate detection is therefore essential to improve patient outcomes. This paper introduces an advanced deep-learning methodology to enhance the accuracy and efficiency of osteoporosis detection through knee X-ray analysis. The proposed approach integrates features from two pre-trained models, DenseNet169 and Vision Transformer (ViT), with a custom-designed Attention Model (AM) to capture detailed spatial and channel-specific information from the input images. These fused features are then fed into a fully connected neural network to classify the images as osteoporotic or normal. The results indicate significant improvements in classification accuracy, achieving a high accuracy rate on previously unseen test data. The proposed model achieves superior performance over existing methods and other recent models for osteoporosis detection, with an accuracy of 0.8611, specificity of 0.9474, and precision of 0.9286. Our approach effectively combines convolutional and transformer-based representations, enabling extraction of both local and global features for comprehensive bone characterization. These findings highlight the model's potential to support early diagnosis, timely intervention, and improved patient care in osteoporosis management.</p>\",\"PeriodicalId\":20189,\"journal\":{\"name\":\"PLoS ONE\",\"volume\":\"20 10\",\"pages\":\"e0334664\"},\"PeriodicalIF\":2.6000,\"publicationDate\":\"2025-10-16\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12530578/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"PLoS ONE\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1371/journal.pone.0334664\",\"RegionNum\":3,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"2025/1/1 0:00:00\",\"PubModel\":\"eCollection\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"PLoS ONE","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1371/journal.pone.0334664","RegionNum":3,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2025/1/1 0:00:00","PubModel":"eCollection","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

骨质疏松症是一种常见的骨病,其特点是骨密度降低和骨折风险增加,尤其是在老年人和绝经后妇女中。骨质疏松性骨折的临床后果不仅仅是疼痛和残疾,还会导致发病率、死亡率和医疗费用的增加。因此,早期干预和准确检测对于改善患者预后至关重要。本文介绍了一种先进的深度学习方法,以提高膝关节x线分析骨质疏松症检测的准确性和效率。该方法集成了两个预训练模型DenseNet169和Vision Transformer (ViT)的特征,并使用定制设计的注意力模型(AM)从输入图像中捕获详细的空间和通道特定信息。然后将这些融合的特征输入到一个完全连接的神经网络中,将图像分类为骨质疏松症或正常。结果表明,分类精度有了显著提高,在以前未见过的测试数据上实现了很高的准确率。该模型的准确率为0.8611,特异性为0.9474,精密度为0.9286,优于现有的骨质疏松症检测方法和近期的其他模型。我们的方法有效地结合了卷积和基于变换的表示,能够提取局部和全局特征,以进行全面的骨骼表征。这些发现强调了该模型在骨质疏松症早期诊断、及时干预和改善患者护理方面的潜力。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

BONE-Net: A novel hybrid deep-learning model for effective osteoporosis detection.

BONE-Net: A novel hybrid deep-learning model for effective osteoporosis detection.

BONE-Net: A novel hybrid deep-learning model for effective osteoporosis detection.

BONE-Net: A novel hybrid deep-learning model for effective osteoporosis detection.

Osteoporosis is a prevalent bone disease characterized by reduced bone density and an elevated risk of fractures, especially in older adults and postmenopausal women. The clinical consequences of osteoporotic fractures extend beyond pain and disability, contributing substantially to morbidity, mortality, and healthcare costs. Early intervention and accurate detection is therefore essential to improve patient outcomes. This paper introduces an advanced deep-learning methodology to enhance the accuracy and efficiency of osteoporosis detection through knee X-ray analysis. The proposed approach integrates features from two pre-trained models, DenseNet169 and Vision Transformer (ViT), with a custom-designed Attention Model (AM) to capture detailed spatial and channel-specific information from the input images. These fused features are then fed into a fully connected neural network to classify the images as osteoporotic or normal. The results indicate significant improvements in classification accuracy, achieving a high accuracy rate on previously unseen test data. The proposed model achieves superior performance over existing methods and other recent models for osteoporosis detection, with an accuracy of 0.8611, specificity of 0.9474, and precision of 0.9286. Our approach effectively combines convolutional and transformer-based representations, enabling extraction of both local and global features for comprehensive bone characterization. These findings highlight the model's potential to support early diagnosis, timely intervention, and improved patient care in osteoporosis management.

求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
PLoS ONE
PLoS ONE 生物-生物学
CiteScore
6.20
自引率
5.40%
发文量
14242
审稿时长
3.7 months
期刊介绍: PLOS ONE is an international, peer-reviewed, open-access, online publication. PLOS ONE welcomes reports on primary research from any scientific discipline. It provides: * Open-access—freely accessible online, authors retain copyright * Fast publication times * Peer review by expert, practicing researchers * Post-publication tools to indicate quality and impact * Community-based dialogue on articles * Worldwide media coverage
×
