基于商用底电池的两端钙钛矿/Cu(In,Ga)Se2共形涂层串联,效率为>26%

IF 30.8 1区 材料科学 Q1 CHEMISTRY, MULTIDISCIPLINARY
Cong Geng, Kuanxiang Zhang, Jiwen Jiang, Changhua Wang, Chung Hsien Wu, Jize Wang, Fei Long, Liyuan Han, Yi-Bing Cheng and Yong Peng
{"title":"基于商用底电池的两端钙钛矿/Cu(In,Ga)Se2共形涂层串联,效率为>26%","authors":"Cong Geng, Kuanxiang Zhang, Jiwen Jiang, Changhua Wang, Chung Hsien Wu, Jize Wang, Fei Long, Liyuan Han, Yi-Bing Cheng and Yong Peng","doi":"10.1039/D5EE03339J","DOIUrl":null,"url":null,"abstract":"<p >High-performance of two-terminal (2-T) perovskite/Cu(In,Ga)Se<small><sub>2</sub></small> (PVK/CIGS) tandem solar cells (TSCs) is fundamentally limited by submicron-scale topographic irregularities inherent to commercially available CIGS substrates. We demonstrate that these features induce spatial heterogeneity in the widely adopted [4-(3,6-dimethyl-9<em>H</em>-carbazol-9-yl)butyl]phosphonic acid (Me-4PACz) self-assembled molecules (SAMs), resulting in non-conformal PVK deposition due to poor wettability. By developing a <em>N</em>,<em>N</em>-dimethylformamide (DMF)-assisted hydrophilic-terminated SAM-reconstructed Me-4PACz interface strategy, we achieved conformal coverage of SAMs and PVK. Furthermore, we identify that the conformal PVK layer inherits substrate textures with rich defects, impeding homogeneous C60 evaporation and conformal capping. To address this, we devised a bimolecular synergistic surface self-accumulation (BSSS) strategy combining 2,3,4,5,6-pentafluorobenzylphosphonic acid (F5BPA) and <em>p</em>-trifluoromethylphenyl ethylamine (<em>p</em>-CF3PEA). These modifiers spontaneously concentrate on textured PVK surfaces to construct a uniform interfacial network that recasts the PVK surface and bridges C60 through enhanced interactions. This enables homogeneous C60 adsorption and minimizes interfacial contact losses. The resulting 2-T PVK/CIGS TSCs exhibit a power conversion efficiency (PCE) of 26.14% (independently certified 25.21%), significantly surpassing previous records.</p>","PeriodicalId":72,"journal":{"name":"Energy & Environmental Science","volume":" 19","pages":" 8907-8917"},"PeriodicalIF":30.8000,"publicationDate":"2025-08-20","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Two-terminal perovskite/Cu(In,Ga)Se2 tandems with conformal coatings based on commercial bottom cells with >26% efficiency\",\"authors\":\"Cong Geng, Kuanxiang Zhang, Jiwen Jiang, Changhua Wang, Chung Hsien Wu, Jize Wang, Fei Long, Liyuan Han, Yi-Bing Cheng and Yong Peng\",\"doi\":\"10.1039/D5EE03339J\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >High-performance of two-terminal (2-T) perovskite/Cu(In,Ga)Se<small><sub>2</sub></small> (PVK/CIGS) tandem solar cells (TSCs) is fundamentally limited by submicron-scale topographic irregularities inherent to commercially available CIGS substrates. We demonstrate that these features induce spatial heterogeneity in the widely adopted [4-(3,6-dimethyl-9<em>H</em>-carbazol-9-yl)butyl]phosphonic acid (Me-4PACz) self-assembled molecules (SAMs), resulting in non-conformal PVK deposition due to poor wettability. By developing a <em>N</em>,<em>N</em>-dimethylformamide (DMF)-assisted hydrophilic-terminated SAM-reconstructed Me-4PACz interface strategy, we achieved conformal coverage of SAMs and PVK. Furthermore, we identify that the conformal PVK layer inherits substrate textures with rich defects, impeding homogeneous C60 evaporation and conformal capping. To address this, we devised a bimolecular synergistic surface self-accumulation (BSSS) strategy combining 2,3,4,5,6-pentafluorobenzylphosphonic acid (F5BPA) and <em>p</em>-trifluoromethylphenyl ethylamine (<em>p</em>-CF3PEA). These modifiers spontaneously concentrate on textured PVK surfaces to construct a uniform interfacial network that recasts the PVK surface and bridges C60 through enhanced interactions. This enables homogeneous C60 adsorption and minimizes interfacial contact losses. The resulting 2-T PVK/CIGS TSCs exhibit a power conversion efficiency (PCE) of 26.14% (independently certified 25.21%), significantly surpassing previous records.</p>\",\"PeriodicalId\":72,\"journal\":{\"name\":\"Energy & Environmental Science\",\"volume\":\" 19\",\"pages\":\" 8907-8917\"},\"PeriodicalIF\":30.8000,\"publicationDate\":\"2025-08-20\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Energy & Environmental Science\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://pubs.rsc.org/en/content/articlelanding/2025/ee/d5ee03339j\",\"RegionNum\":1,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Energy & Environmental Science","FirstCategoryId":"88","ListUrlMain":"https://pubs.rsc.org/en/content/articlelanding/2025/ee/d5ee03339j","RegionNum":1,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

双端(2-T)钙钛矿/Cu(In,Ga)Se2 (PVK/CIGS)串联太阳能电池(tsc)的高性能从根本上受到亚微米尺度的地形不规则性的限制,固有的商业CIGS衬底。我们证明了这些特征导致了广泛采用的[4-(3,6-二甲基- 9h -咔唑-9-基)丁基]膦酸(Me-4PACz)自组装分子(sam)的空间异质性,导致PVK因较差的湿润性而非适形沉积。通过开发一种N,N-二甲基甲酰胺(DMF)辅助的亲水端sam -重构Me-4PACz界面策略,我们实现了sam和PVK的保形覆盖。此外,我们发现共形PVK层继承了具有丰富缺陷的衬底纹理,阻碍了C60的均匀蒸发和共形覆盖。为了解决这个问题,我们设计了一种双分子协同表面自积累(BSSS)策略,结合2,3,4,5,6-五氟苯膦酸(F5BPA)和对三氟甲基苯基乙胺(p-CF3PEA)。这些修饰剂自发地集中在有纹理的PVK表面,构建一个统一的界面网络,重塑PVK表面,并通过增强的相互作用桥接C60。这使得C60吸附均匀,并最大限度地减少界面接触损失。由此产生的2-T PVK/CIGS TSCs的功率转换效率(PCE)为26.14%(独立认证为25.21%),大大超过了之前的记录。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Two-terminal perovskite/Cu(In,Ga)Se2 tandems with conformal coatings based on commercial bottom cells with >26% efficiency

Two-terminal perovskite/Cu(In,Ga)Se2 tandems with conformal coatings based on commercial bottom cells with >26% efficiency

High-performance of two-terminal (2-T) perovskite/Cu(In,Ga)Se2 (PVK/CIGS) tandem solar cells (TSCs) is fundamentally limited by submicron-scale topographic irregularities inherent to commercially available CIGS substrates. We demonstrate that these features induce spatial heterogeneity in the widely adopted [4-(3,6-dimethyl-9H-carbazol-9-yl)butyl]phosphonic acid (Me-4PACz) self-assembled molecules (SAMs), resulting in non-conformal PVK deposition due to poor wettability. By developing a N,N-dimethylformamide (DMF)-assisted hydrophilic-terminated SAM-reconstructed Me-4PACz interface strategy, we achieved conformal coverage of SAMs and PVK. Furthermore, we identify that the conformal PVK layer inherits substrate textures with rich defects, impeding homogeneous C60 evaporation and conformal capping. To address this, we devised a bimolecular synergistic surface self-accumulation (BSSS) strategy combining 2,3,4,5,6-pentafluorobenzylphosphonic acid (F5BPA) and p-trifluoromethylphenyl ethylamine (p-CF3PEA). These modifiers spontaneously concentrate on textured PVK surfaces to construct a uniform interfacial network that recasts the PVK surface and bridges C60 through enhanced interactions. This enables homogeneous C60 adsorption and minimizes interfacial contact losses. The resulting 2-T PVK/CIGS TSCs exhibit a power conversion efficiency (PCE) of 26.14% (independently certified 25.21%), significantly surpassing previous records.
