Experimental performance evaluation of a single-body typed TDLAS sensor using a scramjet ground test facility

The performance evaluation of a single-body typed TDLAS sensor was experimentally conducted using a scramjet ground test facility. The scramjet ground test facility includes model scramjet isolator and combustor. The model scramjet isolator of the test facility can simulate the air flow condition of total temperature of 1,220 K, total pressure of 862 kPa, and Mach number of 2.43 which are representative of the internal flow condition of the scramjet isolator. To evaluate the performance of the single-body typed TDLAS sensor, the TDLAS sensor was flush-mounted on the model scramjet isolator wall of the test facility during the ground test, and the structural integrity and operability of the TDLAS sensor were analyzed based on the robustness of the TDLAS’s components, the stability of signal acquisition, and an accuracy of the measured data. The experimental ground test results demonstrated that the single-body typed TDLAS sensor in this study can withstand and operate well under the harsh mechanical and thermal environments of the model scramjet isolator.
