一种基于半监督时态上下文网络的鱼类姿态估计新方法。

IF 3.9 3区 医学 Q1 ENGINEERING, MULTIDISCIPLINARY
Yuanchang Wang, Ming Wang, Jianrong Cao, Chen Wang, Zhen Wu, He Gao
{"title":"一种基于半监督时态上下文网络的鱼类姿态估计新方法。","authors":"Yuanchang Wang, Ming Wang, Jianrong Cao, Chen Wang, Zhen Wu, He Gao","doi":"10.3390/biomimetics10090566","DOIUrl":null,"url":null,"abstract":"<p><p>Underwater biomimetic robotic fish are emerging as vital platforms for ocean exploration tasks such as environmental monitoring, biological observation, and seabed investigation, particularly in areas inaccessible to humans. Central to their effectiveness is high-precision fish pose estimation, which enables detailed analysis of swimming patterns and ecological behavior, while informing the design of agile, efficient bio-inspired robots. To address the widespread scarcity of high-quality motion datasets in this domain, this study presents a custom-built dual-camera experimental platform that captures multi-view sequences of carp exhibiting three representative swimming behaviors-straight swimming, backward swimming, and turning-resulting in a richly annotated dataset. To overcome key limitations in existing pose estimation methods, including heavy reliance on labeled data and inadequate modeling of temporal dependencies, a novel Semi-supervised Temporal Context-Aware Network (STC-Net) is proposed. STC-Net incorporates two innovative unsupervised loss functions-temporal continuity loss and pose plausibility loss-to leverage both annotated and unannotated video frames, and integrates a Bi-directional Convolutional Recurrent Neural Network to model spatio-temporal correlations across adjacent frames. These enhancements are architecturally compatible and computationally efficient, preserving end-to-end trainability. Experimental results on the proposed dataset demonstrate that STC-Net achieves a keypoint detection RMSE of 9.71, providing a robust and scalable solution for biological pose estimation under complex motion scenarios.</p>","PeriodicalId":8907,"journal":{"name":"Biomimetics","volume":"10 9","pages":""},"PeriodicalIF":3.9000,"publicationDate":"2025-08-25","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12467721/pdf/","citationCount":"0","resultStr":"{\"title\":\"A Novel Fish Pose Estimation Method Based on Semi-Supervised Temporal Context Network.\",\"authors\":\"Yuanchang Wang, Ming Wang, Jianrong Cao, Chen Wang, Zhen Wu, He Gao\",\"doi\":\"10.3390/biomimetics10090566\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Underwater biomimetic robotic fish are emerging as vital platforms for ocean exploration tasks such as environmental monitoring, biological observation, and seabed investigation, particularly in areas inaccessible to humans. Central to their effectiveness is high-precision fish pose estimation, which enables detailed analysis of swimming patterns and ecological behavior, while informing the design of agile, efficient bio-inspired robots. To address the widespread scarcity of high-quality motion datasets in this domain, this study presents a custom-built dual-camera experimental platform that captures multi-view sequences of carp exhibiting three representative swimming behaviors-straight swimming, backward swimming, and turning-resulting in a richly annotated dataset. To overcome key limitations in existing pose estimation methods, including heavy reliance on labeled data and inadequate modeling of temporal dependencies, a novel Semi-supervised Temporal Context-Aware Network (STC-Net) is proposed. STC-Net incorporates two innovative unsupervised loss functions-temporal continuity loss and pose plausibility loss-to leverage both annotated and unannotated video frames, and integrates a Bi-directional Convolutional Recurrent Neural Network to model spatio-temporal correlations across adjacent frames. These enhancements are architecturally compatible and computationally efficient, preserving end-to-end trainability. Experimental results on the proposed dataset demonstrate that STC-Net achieves a keypoint detection RMSE of 9.71, providing a robust and scalable solution for biological pose estimation under complex motion scenarios.</p>\",\"PeriodicalId\":8907,\"journal\":{\"name\":\"Biomimetics\",\"volume\":\"10 9\",\"pages\":\"\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2025-08-25\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12467721/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Biomimetics\",\"FirstCategoryId\":\"5\",\"ListUrlMain\":\"https://doi.org/10.3390/biomimetics10090566\",\"RegionNum\":3,\"RegionCategory\":\"医学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"ENGINEERING, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Biomimetics","FirstCategoryId":"5","ListUrlMain":"https://doi.org/10.3390/biomimetics10090566","RegionNum":3,"RegionCategory":"医学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"ENGINEERING, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

水下仿生机器鱼正在成为海洋探测任务的重要平台,如环境监测、生物观察和海底调查,特别是在人类无法进入的区域。其有效性的核心是高精度的鱼类姿态估计,这使得对游泳模式和生态行为的详细分析成为可能,同时为敏捷、高效的仿生机器人的设计提供信息。为了解决该领域普遍缺乏高质量运动数据集的问题,本研究提出了一个定制的双摄像头实验平台,该平台捕获了展示三种代表性游泳行为(直线游泳、向后游泳和转身)的鲤鱼的多视图序列,从而生成了一个注释丰富的数据集。为了克服现有姿态估计方法严重依赖标记数据和时间依赖性建模不足等关键局限性,提出了一种新型的半监督时态上下文感知网络(STC-Net)。STC-Net采用了两种创新的无监督损失函数——时间连续性损失和姿态合理性损失——来利用带注释和未带注释的视频帧,并集成了双向卷积循环神经网络来模拟相邻帧之间的时空相关性。这些增强在架构上兼容且计算效率高,保持了端到端的可训练性。在该数据集上的实验结果表明,STC-Net关键点检测RMSE为9.71,为复杂运动场景下的生物姿态估计提供了鲁棒性和可扩展性的解决方案。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

A Novel Fish Pose Estimation Method Based on Semi-Supervised Temporal Context Network.

A Novel Fish Pose Estimation Method Based on Semi-Supervised Temporal Context Network.

A Novel Fish Pose Estimation Method Based on Semi-Supervised Temporal Context Network.

A Novel Fish Pose Estimation Method Based on Semi-Supervised Temporal Context Network.

Underwater biomimetic robotic fish are emerging as vital platforms for ocean exploration tasks such as environmental monitoring, biological observation, and seabed investigation, particularly in areas inaccessible to humans. Central to their effectiveness is high-precision fish pose estimation, which enables detailed analysis of swimming patterns and ecological behavior, while informing the design of agile, efficient bio-inspired robots. To address the widespread scarcity of high-quality motion datasets in this domain, this study presents a custom-built dual-camera experimental platform that captures multi-view sequences of carp exhibiting three representative swimming behaviors-straight swimming, backward swimming, and turning-resulting in a richly annotated dataset. To overcome key limitations in existing pose estimation methods, including heavy reliance on labeled data and inadequate modeling of temporal dependencies, a novel Semi-supervised Temporal Context-Aware Network (STC-Net) is proposed. STC-Net incorporates two innovative unsupervised loss functions-temporal continuity loss and pose plausibility loss-to leverage both annotated and unannotated video frames, and integrates a Bi-directional Convolutional Recurrent Neural Network to model spatio-temporal correlations across adjacent frames. These enhancements are architecturally compatible and computationally efficient, preserving end-to-end trainability. Experimental results on the proposed dataset demonstrate that STC-Net achieves a keypoint detection RMSE of 9.71, providing a robust and scalable solution for biological pose estimation under complex motion scenarios.
