Zarina Ansari, Suresh Kadam, Sujata Kasabe, Jenis Tripathi, Pramod Agale, Sunil Patange, Paresh More
{"title":"优化Mn掺杂ZnO@rGO纳米复合材料:先进储能和PEC系统的突破","authors":"Zarina Ansari, Suresh Kadam, Sujata Kasabe, Jenis Tripathi, Pramod Agale, Sunil Patange, Paresh More","doi":"10.1007/s11581-025-06468-x","DOIUrl":null,"url":null,"abstract":"<div><p>Pristine ZnO and Mn doped ZnO (Mn-ZnO) were synthesized by sol–gel auto-combustion method. Three different concentrations of Mn-ZnO (1%, 5%, and 10%) were treated with rGO in hydrothermal reactor to obtained (1%, 5%, and 10%) Mn-ZnO@rGO nanocomposites. X-ray diffraction (XRD) pattern confirmed the successful incorporation of Mn into the ZnO lattice and the formation of Mn-ZnO@rGO nanocomposites. The peak at 2θ = 25.16° signifies the presence of reduced graphene oxide (rGO) thus confirmed formation of Mn-ZnO@rGO nanocomposite. Rietveld refined pattern showed that all the samples are pure with wurtzite structure. The Fourier-transform infrared (FTIR) spectroscopy revealed the presence of metal–oxygen bonds and functional groups within the composites. The stretching vibration of ZnO at 464 cm<sup>−1</sup> confirmed the wurtzite structure. The peak at 600 cm<sup>−1</sup> and 880 cm<sup>−1</sup> assigned for vibrational, antisymmetric stretching mode of MnO and Mn–O respectively. Significant peaks at 1080 cm<sup>−1</sup> and 1392 cm<sup>−1</sup> are due to C-O stretching vibrations from C–O–C bonds and C–OH bending vibrations, respectively. The peak at 1432 cm<sup>−1</sup> indicates the -C = O group stretching vibration from inorganic carbonate species. The peak at 2850 cm<sup>−1</sup> corresponds to the symmetrical stretching vibration of the C-H group. FTIR analysis confirmed formation of Mn-ZnO@rGO nanocomposite. Field emission scanning electron microscopy (FESEM) images demonstrate a high density of irregularly sized nanoparticles, confirming the effective deposition of Mn-ZnO nanoparticles on to rGO sheets and the robust binding of these nanoparticles, resulting in Mn-ZnO@rGO nanocomposites. X-ray photoelectron spectroscopy (XPS) provided detailed insights into the oxidation states of the elements with a focus on 5% Mn-ZnO@rGO nano composite. The survey spectrum for the 5% Mn-ZnO@rGO nanocomposite confirmed the presence of Zn, Mn, O, and C. The lack of contaminants peaks in the XPS analysis supports the successful synthesis of Mn-ZnO@rGO nanocomposite. Raman spectroscopy detected vibrational modes between 1300 cm⁻<sup>1</sup> and 1600 cm⁻<sup>1</sup>, which are characteristic of rGO and Mn-ZnO@rGO nanocomposites. There is increase in the D band and G band intensity ratio (ID/IG), and this confirms the disorder in the carbon components. It further confirmed that during the Mn-ZnO@rGO composite's formation, GO was converted to rGO. Electrochemical performance, assessed through Electrochemical Impedance Spectroscopy (EIS), Galvanostatic Charge–Discharge (GCD), and Cyclic Voltammetry (CV). Long-term cycling stability over 5000 cycles indicated that 5% Mn-ZnO@rGO nanocomposite exhibited superior performance compared to 1% and 10% counterparts. Additionally, photoelectrochemical cell (PEC) measurements further validated the exceptional performance of the 5% Mn-ZnO@rGO nanocomposite. These findings demonstrate that the 5% Mn-ZnO@rGO nanocomposite is a highly promising material for supercapacitor and PEC applications.</p></div>","PeriodicalId":599,"journal":{"name":"Ionics","volume":"31 8","pages":"8151 - 8172"},"PeriodicalIF":2.6000,"publicationDate":"2025-06-16","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Optimized Mn doped ZnO@rGO nanocomposites: a breakthrough for advanced energy storage and PEC systems\",\"authors\":\"Zarina Ansari, Suresh Kadam, Sujata Kasabe, Jenis Tripathi, Pramod Agale, Sunil Patange, Paresh More\",\"doi\":\"10.1007/s11581-025-06468-x\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><p>Pristine ZnO and Mn doped ZnO (Mn-ZnO) were synthesized by sol–gel auto-combustion method. Three different concentrations of Mn-ZnO (1%, 5%, and 10%) were treated with rGO in hydrothermal reactor to obtained (1%, 5%, and 10%) Mn-ZnO@rGO nanocomposites. X-ray diffraction (XRD) pattern confirmed the successful incorporation of Mn into the ZnO lattice and the formation of Mn-ZnO@rGO nanocomposites. The peak at 2θ = 25.16° signifies the presence of reduced graphene oxide (rGO) thus confirmed formation of Mn-ZnO@rGO nanocomposite. Rietveld refined pattern showed that all the samples are pure with wurtzite structure. The Fourier-transform infrared (FTIR) spectroscopy revealed the presence of metal–oxygen bonds and functional groups within the composites. The stretching vibration of ZnO at 464 cm<sup>−1</sup> confirmed the wurtzite structure. The peak at 600 cm<sup>−1</sup> and 880 cm<sup>−1</sup> assigned for vibrational, antisymmetric stretching mode of MnO and Mn–O respectively. Significant peaks at 1080 cm<sup>−1</sup> and 1392 cm<sup>−1</sup> are due to C-O stretching vibrations from C–O–C bonds and C–OH bending vibrations, respectively. The peak at 1432 cm<sup>−1</sup> indicates the -C = O group stretching vibration from inorganic carbonate species. The peak at 2850 cm<sup>−1</sup> corresponds to the symmetrical stretching vibration of the C-H group. FTIR analysis confirmed formation of Mn-ZnO@rGO nanocomposite. Field emission scanning electron microscopy (FESEM) images demonstrate a high density of irregularly sized nanoparticles, confirming the effective deposition of Mn-ZnO nanoparticles on to rGO sheets and the robust binding of these nanoparticles, resulting in Mn-ZnO@rGO nanocomposites. X-ray photoelectron spectroscopy (XPS) provided detailed insights into the oxidation states of the elements with a focus on 5% Mn-ZnO@rGO nano composite. The survey spectrum for the 5% Mn-ZnO@rGO nanocomposite confirmed the presence of Zn, Mn, O, and C. The lack of contaminants peaks in the XPS analysis supports the successful synthesis of Mn-ZnO@rGO nanocomposite. Raman spectroscopy detected vibrational modes between 1300 cm⁻<sup>1</sup> and 1600 cm⁻<sup>1</sup>, which are characteristic of rGO and Mn-ZnO@rGO nanocomposites. There is increase in the D band and G band intensity ratio (ID/IG), and this confirms the disorder in the carbon components. It further confirmed that during the Mn-ZnO@rGO composite's formation, GO was converted to rGO. Electrochemical performance, assessed through Electrochemical Impedance Spectroscopy (EIS), Galvanostatic Charge–Discharge (GCD), and Cyclic Voltammetry (CV). Long-term cycling stability over 5000 cycles indicated that 5% Mn-ZnO@rGO nanocomposite exhibited superior performance compared to 1% and 10% counterparts. Additionally, photoelectrochemical cell (PEC) measurements further validated the exceptional performance of the 5% Mn-ZnO@rGO nanocomposite. These findings demonstrate that the 5% Mn-ZnO@rGO nanocomposite is a highly promising material for supercapacitor and PEC applications.</p></div>\",\"PeriodicalId\":599,\"journal\":{\"name\":\"Ionics\",\"volume\":\"31 8\",\"pages\":\"8151 - 8172\"},\"PeriodicalIF\":2.6000,\"publicationDate\":\"2025-06-16\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Ionics\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://link.springer.com/article/10.1007/s11581-025-06468-x\",\"RegionNum\":4,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q3\",\"JCRName\":\"CHEMISTRY, PHYSICAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Ionics","FirstCategoryId":"92","ListUrlMain":"https://link.springer.com/article/10.1007/s11581-025-06468-x","RegionNum":4,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q3","JCRName":"CHEMISTRY, PHYSICAL","Score":null,"Total":0}
Optimized Mn doped ZnO@rGO nanocomposites: a breakthrough for advanced energy storage and PEC systems
Pristine ZnO and Mn doped ZnO (Mn-ZnO) were synthesized by sol–gel auto-combustion method. Three different concentrations of Mn-ZnO (1%, 5%, and 10%) were treated with rGO in hydrothermal reactor to obtained (1%, 5%, and 10%) Mn-ZnO@rGO nanocomposites. X-ray diffraction (XRD) pattern confirmed the successful incorporation of Mn into the ZnO lattice and the formation of Mn-ZnO@rGO nanocomposites. The peak at 2θ = 25.16° signifies the presence of reduced graphene oxide (rGO) thus confirmed formation of Mn-ZnO@rGO nanocomposite. Rietveld refined pattern showed that all the samples are pure with wurtzite structure. The Fourier-transform infrared (FTIR) spectroscopy revealed the presence of metal–oxygen bonds and functional groups within the composites. The stretching vibration of ZnO at 464 cm−1 confirmed the wurtzite structure. The peak at 600 cm−1 and 880 cm−1 assigned for vibrational, antisymmetric stretching mode of MnO and Mn–O respectively. Significant peaks at 1080 cm−1 and 1392 cm−1 are due to C-O stretching vibrations from C–O–C bonds and C–OH bending vibrations, respectively. The peak at 1432 cm−1 indicates the -C = O group stretching vibration from inorganic carbonate species. The peak at 2850 cm−1 corresponds to the symmetrical stretching vibration of the C-H group. FTIR analysis confirmed formation of Mn-ZnO@rGO nanocomposite. Field emission scanning electron microscopy (FESEM) images demonstrate a high density of irregularly sized nanoparticles, confirming the effective deposition of Mn-ZnO nanoparticles on to rGO sheets and the robust binding of these nanoparticles, resulting in Mn-ZnO@rGO nanocomposites. X-ray photoelectron spectroscopy (XPS) provided detailed insights into the oxidation states of the elements with a focus on 5% Mn-ZnO@rGO nano composite. The survey spectrum for the 5% Mn-ZnO@rGO nanocomposite confirmed the presence of Zn, Mn, O, and C. The lack of contaminants peaks in the XPS analysis supports the successful synthesis of Mn-ZnO@rGO nanocomposite. Raman spectroscopy detected vibrational modes between 1300 cm⁻1 and 1600 cm⁻1, which are characteristic of rGO and Mn-ZnO@rGO nanocomposites. There is increase in the D band and G band intensity ratio (ID/IG), and this confirms the disorder in the carbon components. It further confirmed that during the Mn-ZnO@rGO composite's formation, GO was converted to rGO. Electrochemical performance, assessed through Electrochemical Impedance Spectroscopy (EIS), Galvanostatic Charge–Discharge (GCD), and Cyclic Voltammetry (CV). Long-term cycling stability over 5000 cycles indicated that 5% Mn-ZnO@rGO nanocomposite exhibited superior performance compared to 1% and 10% counterparts. Additionally, photoelectrochemical cell (PEC) measurements further validated the exceptional performance of the 5% Mn-ZnO@rGO nanocomposite. These findings demonstrate that the 5% Mn-ZnO@rGO nanocomposite is a highly promising material for supercapacitor and PEC applications.
