揭示ZnCl2在提高氨基as基InAs@ZnSe量子点光致发光效率中的作用

IF 16 1区 材料科学 Q1 CHEMISTRY, MULTIDISCIPLINARY
ACS Nano Pub Date : 2025-09-24 DOI:10.1021/acsnano.5c10371
Dongxu Zhu, , , Jordi Llusar, , , Aswin Asaithambi, , , Zheming Liu, , , René Bes, , , Damien Prieur, , , Hiba H. Karakkal, , , Mirko Prato, , , Sergio Brovelli, , , Gabriele Saleh, , , Satyaprakash Panda, , , Ivan Infante*, , , Luca De Trizio*, , and , Liberato Manna*,
{"title":"揭示ZnCl2在提高氨基as基InAs@ZnSe量子点光致发光效率中的作用","authors":"Dongxu Zhu,&nbsp;, ,&nbsp;Jordi Llusar,&nbsp;, ,&nbsp;Aswin Asaithambi,&nbsp;, ,&nbsp;Zheming Liu,&nbsp;, ,&nbsp;René Bes,&nbsp;, ,&nbsp;Damien Prieur,&nbsp;, ,&nbsp;Hiba H. Karakkal,&nbsp;, ,&nbsp;Mirko Prato,&nbsp;, ,&nbsp;Sergio Brovelli,&nbsp;, ,&nbsp;Gabriele Saleh,&nbsp;, ,&nbsp;Satyaprakash Panda,&nbsp;, ,&nbsp;Ivan Infante*,&nbsp;, ,&nbsp;Luca De Trizio*,&nbsp;, and ,&nbsp;Liberato Manna*,&nbsp;","doi":"10.1021/acsnano.5c10371","DOIUrl":null,"url":null,"abstract":"<p >We investigated how ZnCl<sub>2</sub>, employed as an additive in the amino-As-based synthesis of indium arsenide (InAs) quantum dots (QDs), considerably improves the photoluminescence quantum yield (PLQY) of the resulting InAs@ZnSe core@shell QDs. We achieved this by synthesizing and comparing three distinct InAs QD samples and their corresponding core@shell structures: (1) In(Zn)As QDs (synthesized with ZnCl<sub>2</sub>); (2) standard InAs QDs (std-InAs, made without additives); and (3) std-InAs QDs postsynthesis treated with ZnCl<sub>2</sub> (Zn–InAs). High PLQY values (∼70%) were attained only with In(Zn)As@ZnSe QDs, while std-InAs@ZnSe and Zn–InAs@ZnSe samples exhibited much lower PL efficiencies (10–20%). We also demonstrated that (i) the high PLQY in In(Zn)As@ZnSe QDs could not be attributed solely to the presence of an In–Zn–Se interlayer, as this was present in all three samples; (ii) the specific ZnSe shelling procedure had only a minor impact on the final PLQY; and (iii) the PL efficiency was significantly improved only when high amounts of ZnCl<sub>2</sub> additive (specifically with ZnCl<sub>2</sub>:InCl<sub>3</sub> precursor ratios over 10:1) were used during the InAs QDs synthesis. These findings were rationalized through density functional theory (DFT) calculations coupled with X-ray absorption spectroscopy measurements. DFT models suggested that std-InAs QDs feature surface trap states, mainly located on the (−1–1–1) facets, thus low PL efficiency even after ZnSe shelling. The use of ZnCl<sub>2</sub> in the InAs synthesis led to surface Zn incorporation, particularly on the (100) and (−1–1–1) facets, effectively passivating surface traps and, consequently, yielding highly emissive In(Zn)As@ZnSe QD systems. In contrast, ZnCl<sub>2</sub> employed in the postsynthesis treatment of std-InAs QDs resulted only in a limited surface Zn incorporation and in ZnCl<sub>2</sub> adsorption on the (−1–1–1) facets (i.e., ZnCl<sub>2</sub> acting as a Z-type ligand), leading to poor passivation of surface traps. Overall, our study demonstrates the critical role of ZnCl<sub>2</sub> as a synthesis additive in delivering highly emissive amino-As-based InAs@ZnSe QDs.</p>","PeriodicalId":21,"journal":{"name":"ACS Nano","volume":"19 39","pages":"34807–34818"},"PeriodicalIF":16.0000,"publicationDate":"2025-09-24","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://pubs.acs.org/doi/pdf/10.1021/acsnano.5c10371","citationCount":"0","resultStr":"{\"title\":\"Unveiling the Role of ZnCl2 in Enhancing the Photoluminescence Efficiency of Amino-As-Based InAs@ZnSe Quantum Dots\",\"authors\":\"Dongxu Zhu,&nbsp;, ,&nbsp;Jordi Llusar,&nbsp;, ,&nbsp;Aswin Asaithambi,&nbsp;, ,&nbsp;Zheming Liu,&nbsp;, ,&nbsp;René Bes,&nbsp;, ,&nbsp;Damien Prieur,&nbsp;, ,&nbsp;Hiba H. Karakkal,&nbsp;, ,&nbsp;Mirko Prato,&nbsp;, ,&nbsp;Sergio Brovelli,&nbsp;, ,&nbsp;Gabriele Saleh,&nbsp;, ,&nbsp;Satyaprakash Panda,&nbsp;, ,&nbsp;Ivan Infante*,&nbsp;, ,&nbsp;Luca De Trizio*,&nbsp;, and ,&nbsp;Liberato Manna*,&nbsp;\",\"doi\":\"10.1021/acsnano.5c10371\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >We investigated how ZnCl<sub>2</sub>, employed as an additive in the amino-As-based synthesis of indium arsenide (InAs) quantum dots (QDs), considerably improves the photoluminescence quantum yield (PLQY) of the resulting InAs@ZnSe core@shell QDs. We achieved this by synthesizing and comparing three distinct InAs QD samples and their corresponding core@shell structures: (1) In(Zn)As QDs (synthesized with ZnCl<sub>2</sub>); (2) standard InAs QDs (std-InAs, made without additives); and (3) std-InAs QDs postsynthesis treated with ZnCl<sub>2</sub> (Zn–InAs). High PLQY values (∼70%) were attained only with In(Zn)As@ZnSe QDs, while std-InAs@ZnSe and Zn–InAs@ZnSe samples exhibited much lower PL efficiencies (10–20%). We also demonstrated that (i) the high PLQY in In(Zn)As@ZnSe QDs could not be attributed solely to the presence of an In–Zn–Se interlayer, as this was present in all three samples; (ii) the specific ZnSe shelling procedure had only a minor impact on the final PLQY; and (iii) the PL efficiency was significantly improved only when high amounts of ZnCl<sub>2</sub> additive (specifically with ZnCl<sub>2</sub>:InCl<sub>3</sub> precursor ratios over 10:1) were used during the InAs QDs synthesis. These findings were rationalized through density functional theory (DFT) calculations coupled with X-ray absorption spectroscopy measurements. DFT models suggested that std-InAs QDs feature surface trap states, mainly located on the (−1–1–1) facets, thus low PL efficiency even after ZnSe shelling. The use of ZnCl<sub>2</sub> in the InAs synthesis led to surface Zn incorporation, particularly on the (100) and (−1–1–1) facets, effectively passivating surface traps and, consequently, yielding highly emissive In(Zn)As@ZnSe QD systems. In contrast, ZnCl<sub>2</sub> employed in the postsynthesis treatment of std-InAs QDs resulted only in a limited surface Zn incorporation and in ZnCl<sub>2</sub> adsorption on the (−1–1–1) facets (i.e., ZnCl<sub>2</sub> acting as a Z-type ligand), leading to poor passivation of surface traps. Overall, our study demonstrates the critical role of ZnCl<sub>2</sub> as a synthesis additive in delivering highly emissive amino-As-based InAs@ZnSe QDs.</p>\",\"PeriodicalId\":21,\"journal\":{\"name\":\"ACS Nano\",\"volume\":\"19 39\",\"pages\":\"34807–34818\"},\"PeriodicalIF\":16.0000,\"publicationDate\":\"2025-09-24\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://pubs.acs.org/doi/pdf/10.1021/acsnano.5c10371\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"ACS Nano\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://pubs.acs.org/doi/10.1021/acsnano.5c10371\",\"RegionNum\":1,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Nano","FirstCategoryId":"88","ListUrlMain":"https://pubs.acs.org/doi/10.1021/acsnano.5c10371","RegionNum":1,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

我们研究了ZnCl2作为添加剂如何在氨基as基合成砷化铟(InAs)量子点(QDs)中显著提高所得到的InAs@ZnSe core@shell量子点的光致发光量子产率(PLQY)。我们通过合成和比较三种不同的InAs量子点样品及其相应的core@shell结构来实现这一目标:(1)In(Zn)As量子点(用ZnCl2合成);(2)标准InAs量子点(标准InAs,不含添加剂);(3)用ZnCl2 (Zn-InAs)处理后合成std-InAs量子点。只有使用In(Zn)As@ZnSe量子点才能获得高PLQY值(~ 70%),而std-InAs@ZnSe和Zn -InAs@ZnSe样品的PL效率要低得多(10-20%)。我们还证明(i) in (Zn)As@ZnSe量子点中的高PLQY不能仅仅归因于in - Zn - se中间层的存在,因为这存在于所有三个样品中;(ii)具体的ZnSe炮击程序对最终PLQY的影响很小;(iii)只有在合成InAs量子点时使用大量的ZnCl2添加剂(特别是ZnCl2:InCl3前驱体比超过10:1)才能显著提高PL效率。这些发现通过密度泛函理论(DFT)计算和x射线吸收光谱测量加以合理化。DFT模型表明,std-InAs量子点具有表面陷阱态,主要位于(−1-1-1)面,因此即使在ZnSe炮击后,PL效率也很低。在InAs合成中使用ZnCl2导致了表面Zn的掺入,特别是在(100)和(- 1-1-1)面,有效地钝化了表面陷阱,从而产生了高发射的in (Zn)As@ZnSe QD体系。相比之下,在std-InAs量子点的合成后处理中使用的ZnCl2只导致了有限的表面Zn掺入和ZnCl2在(−1-1-1)面上的吸附(即ZnCl2作为z型配体),导致表面陷阱钝化效果差。总的来说,我们的研究证明了ZnCl2作为合成添加剂在提供高发射氨基as基InAs@ZnSe量子点中的关键作用。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Unveiling the Role of ZnCl2 in Enhancing the Photoluminescence Efficiency of Amino-As-Based InAs@ZnSe Quantum Dots

Unveiling the Role of ZnCl2 in Enhancing the Photoluminescence Efficiency of Amino-As-Based InAs@ZnSe Quantum Dots

We investigated how ZnCl2, employed as an additive in the amino-As-based synthesis of indium arsenide (InAs) quantum dots (QDs), considerably improves the photoluminescence quantum yield (PLQY) of the resulting InAs@ZnSe core@shell QDs. We achieved this by synthesizing and comparing three distinct InAs QD samples and their corresponding core@shell structures: (1) In(Zn)As QDs (synthesized with ZnCl2); (2) standard InAs QDs (std-InAs, made without additives); and (3) std-InAs QDs postsynthesis treated with ZnCl2 (Zn–InAs). High PLQY values (∼70%) were attained only with In(Zn)As@ZnSe QDs, while std-InAs@ZnSe and Zn–InAs@ZnSe samples exhibited much lower PL efficiencies (10–20%). We also demonstrated that (i) the high PLQY in In(Zn)As@ZnSe QDs could not be attributed solely to the presence of an In–Zn–Se interlayer, as this was present in all three samples; (ii) the specific ZnSe shelling procedure had only a minor impact on the final PLQY; and (iii) the PL efficiency was significantly improved only when high amounts of ZnCl2 additive (specifically with ZnCl2:InCl3 precursor ratios over 10:1) were used during the InAs QDs synthesis. These findings were rationalized through density functional theory (DFT) calculations coupled with X-ray absorption spectroscopy measurements. DFT models suggested that std-InAs QDs feature surface trap states, mainly located on the (−1–1–1) facets, thus low PL efficiency even after ZnSe shelling. The use of ZnCl2 in the InAs synthesis led to surface Zn incorporation, particularly on the (100) and (−1–1–1) facets, effectively passivating surface traps and, consequently, yielding highly emissive In(Zn)As@ZnSe QD systems. In contrast, ZnCl2 employed in the postsynthesis treatment of std-InAs QDs resulted only in a limited surface Zn incorporation and in ZnCl2 adsorption on the (−1–1–1) facets (i.e., ZnCl2 acting as a Z-type ligand), leading to poor passivation of surface traps. Overall, our study demonstrates the critical role of ZnCl2 as a synthesis additive in delivering highly emissive amino-As-based InAs@ZnSe QDs.
