滚动翅果的岁差动力学和形态。

IF 3.5 2区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES
Journal of The Royal Society Interface Pub Date : 2025-09-01 Epub Date: 2025-09-24 DOI:10.1098/rsif.2025.0391
Breanna Marie Schaeffer, Andrew Keith Dickerson
{"title":"滚动翅果的岁差动力学和形态。","authors":"Breanna Marie Schaeffer, Andrew Keith Dickerson","doi":"10.1098/rsif.2025.0391","DOIUrl":null,"url":null,"abstract":"<p><p>Samaras of species such as <i>Fraxinus americana</i>, <i>Fraxinus excelsior</i> and <i>Liriodendron tulipifera</i> exhibit a unique dual-axis descent characterized by spanwise rolling superimposed on vertical helical precession. While prior work has established the aerodynamic mechanisms of non-rolling samaras, <i>Acer</i> spp. serving as the classic example,, the aerodynamic role of rolling motion remains largely uncharacterized. Here, we present a comparative kinematic and morphological analysis of 30 rolling samaras across three species using high-speed multi-camera imaging and digital tracking. Our results reveal that all species maintain stable autorotation by rolling approximately seven cycles for each precession cycle, inducing periodic modulation of angle of attack and sinusoidal lift generation without observable wingtip wobble. Species-specific variation in wingspan, mass and thickness generates distinct descent velocities, but across all groups wing thickness emerges as the single most predictive morphological trait. We demonstrate that descent velocity scales inversely with thickness, with additional inverse power-law relationships linking thickness to both rolling and precessional angular velocities. Analytical modelling of lift-induced torque predicts negligible vertical oscillation, confirming observations. Samaras released into a vertical wind tunnel from a static position show that the time to stable autorotation strongly depends on the initial release orientation. In our observations, rolling begins before precession, and the stochastic direction of rolling sets the precessional direction.</p>","PeriodicalId":17488,"journal":{"name":"Journal of The Royal Society Interface","volume":"22 230","pages":"20250391"},"PeriodicalIF":3.5000,"publicationDate":"2025-09-01","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12457913/pdf/","citationCount":"0","resultStr":"{\"title\":\"Precession dynamics and morphology of rolling samaras.\",\"authors\":\"Breanna Marie Schaeffer, Andrew Keith Dickerson\",\"doi\":\"10.1098/rsif.2025.0391\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Samaras of species such as <i>Fraxinus americana</i>, <i>Fraxinus excelsior</i> and <i>Liriodendron tulipifera</i> exhibit a unique dual-axis descent characterized by spanwise rolling superimposed on vertical helical precession. While prior work has established the aerodynamic mechanisms of non-rolling samaras, <i>Acer</i> spp. serving as the classic example,, the aerodynamic role of rolling motion remains largely uncharacterized. Here, we present a comparative kinematic and morphological analysis of 30 rolling samaras across three species using high-speed multi-camera imaging and digital tracking. Our results reveal that all species maintain stable autorotation by rolling approximately seven cycles for each precession cycle, inducing periodic modulation of angle of attack and sinusoidal lift generation without observable wingtip wobble. Species-specific variation in wingspan, mass and thickness generates distinct descent velocities, but across all groups wing thickness emerges as the single most predictive morphological trait. We demonstrate that descent velocity scales inversely with thickness, with additional inverse power-law relationships linking thickness to both rolling and precessional angular velocities. Analytical modelling of lift-induced torque predicts negligible vertical oscillation, confirming observations. Samaras released into a vertical wind tunnel from a static position show that the time to stable autorotation strongly depends on the initial release orientation. In our observations, rolling begins before precession, and the stochastic direction of rolling sets the precessional direction.</p>\",\"PeriodicalId\":17488,\"journal\":{\"name\":\"Journal of The Royal Society Interface\",\"volume\":\"22 230\",\"pages\":\"20250391\"},\"PeriodicalIF\":3.5000,\"publicationDate\":\"2025-09-01\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12457913/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Journal of The Royal Society Interface\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1098/rsif.2025.0391\",\"RegionNum\":2,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"2025/9/24 0:00:00\",\"PubModel\":\"Epub\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Journal of The Royal Society Interface","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1098/rsif.2025.0391","RegionNum":2,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2025/9/24 0:00:00","PubModel":"Epub","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

美洲黄曲柳(Fraxinus americana)、excelsior黄曲柳(Fraxinus excelsior)和鹅毛楸(Liriodendron tulipifera)等物种的翅果翅果表现出独特的双轴下降,其特征是在垂直螺旋进动的基础上进行展向滚动。虽然先前的工作已经建立了非滚动翅果的空气动力学机制,以Acer为经典例子,但滚动运动的空气动力学作用在很大程度上仍然没有被表征。在这里,我们使用高速多相机成像和数字跟踪技术对30种不同物种的滚动翅果进行了运动学和形态学的比较分析。我们的研究结果表明,所有物种通过每个进动周期滚动大约7个周期来保持稳定的自旋,从而引起攻角的周期性调制和正弦升力的产生,而没有观察到翼尖摆动。不同物种在翼展、质量和厚度上的差异产生了不同的下降速度,但在所有物种中,翼厚都是最具预测性的形态特征。我们证明了下降速度与厚度成反比,并具有附加的逆幂律关系,将厚度与滚动角速度和进动角速度联系起来。升力引起的扭矩的分析模型预测可以忽略不计的垂直振荡,证实了观察结果。从静态位置释放到垂直风洞的萨马拉斯表明,稳定自旋的时间很大程度上取决于初始释放方向。在我们的观测中,滚动在岁差之前就开始了,滚动的随机方向决定了岁差方向。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Precession dynamics and morphology of rolling samaras.

Precession dynamics and morphology of rolling samaras.

Precession dynamics and morphology of rolling samaras.

Precession dynamics and morphology of rolling samaras.

Samaras of species such as Fraxinus americana, Fraxinus excelsior and Liriodendron tulipifera exhibit a unique dual-axis descent characterized by spanwise rolling superimposed on vertical helical precession. While prior work has established the aerodynamic mechanisms of non-rolling samaras, Acer spp. serving as the classic example,, the aerodynamic role of rolling motion remains largely uncharacterized. Here, we present a comparative kinematic and morphological analysis of 30 rolling samaras across three species using high-speed multi-camera imaging and digital tracking. Our results reveal that all species maintain stable autorotation by rolling approximately seven cycles for each precession cycle, inducing periodic modulation of angle of attack and sinusoidal lift generation without observable wingtip wobble. Species-specific variation in wingspan, mass and thickness generates distinct descent velocities, but across all groups wing thickness emerges as the single most predictive morphological trait. We demonstrate that descent velocity scales inversely with thickness, with additional inverse power-law relationships linking thickness to both rolling and precessional angular velocities. Analytical modelling of lift-induced torque predicts negligible vertical oscillation, confirming observations. Samaras released into a vertical wind tunnel from a static position show that the time to stable autorotation strongly depends on the initial release orientation. In our observations, rolling begins before precession, and the stochastic direction of rolling sets the precessional direction.

求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
Journal of The Royal Society Interface
Journal of The Royal Society Interface 综合性期刊-综合性期刊
CiteScore
7.10
自引率
2.60%
发文量
234
审稿时长
2.5 months
期刊介绍: J. R. Soc. Interface welcomes articles of high quality research at the interface of the physical and life sciences. It provides a high-quality forum to publish rapidly and interact across this boundary in two main ways: J. R. Soc. Interface publishes research applying chemistry, engineering, materials science, mathematics and physics to the biological and medical sciences; it also highlights discoveries in the life sciences of relevance to the physical sciences. Both sides of the interface are considered equally and it is one of the only journals to cover this exciting new territory. J. R. Soc. Interface welcomes contributions on a diverse range of topics, including but not limited to; biocomplexity, bioengineering, bioinformatics, biomaterials, biomechanics, bionanoscience, biophysics, chemical biology, computer science (as applied to the life sciences), medical physics, synthetic biology, systems biology, theoretical biology and tissue engineering.
×
