镍基高温合金K444热处理中γ′相的溶解与析出行为

IF 2.3 4区 材料科学 Q3 MATERIALS SCIENCE, MULTIDISCIPLINARY
JOM Pub Date : 2025-07-15 DOI:10.1007/s11837-025-07573-y
Hao Huang, Yao Huang, Hexin Zhang
{"title":"镍基高温合金K444热处理中γ′相的溶解与析出行为","authors":"Hao Huang,&nbsp;Yao Huang,&nbsp;Hexin Zhang","doi":"10.1007/s11837-025-07573-y","DOIUrl":null,"url":null,"abstract":"<div><p>The morphology, volume fraction, and size distribution of the <i>γ</i>′ phase significantly influence the fabrication of high-temperature alloys and their performance under severe service conditions. This study systematically investigates the dissolution, precipitation, and growth behavior of various <i>γ</i>′ phases during heat treatment. The results demonstrate that the <i>γ</i>/<i>γ</i>′ eutectic structure between dendrites decomposes first during the solution treatment, forming coarsened <i>γ</i>′ agglomerates, which subsequently dissolve into the <i>γ</i> matrix. The splitting and dissolution mechanism of the coarsened primary <i>γ</i>′ phase within the <i>γ</i>′ agglomerate regions is clarified. Increasing the solution temperature and prolonging the solution time enhance the growth of secondary <i>γ</i>′ phases by accelerating the splitting and dissolution of the <i>γ</i>/<i>γ</i>″ eutectic structure. During heat treatment, carbide segregation at grain boundaries induces <i>γ</i>′ coarsening at these boundaries. The combined effects of carbides with varying sizes, the coarsened <i>γ</i>′ precipitates at grain boundaries, and the pinning effect of precipitates on local grain boundaries lead to the formation of serrated grain boundary morphologies. These findings enhance the understanding of the evolution of <i>γ</i>′ phases in nickel-based superalloys during heat treatment and provide a theoretical basis for optimizing the heat treatment processes of the K444 alloy.</p></div>","PeriodicalId":605,"journal":{"name":"JOM","volume":"77 10","pages":"7655 - 7667"},"PeriodicalIF":2.3000,"publicationDate":"2025-07-15","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Dissolution and Precipitation Behavior of the γ′ Phase During Heat Treatment of the Nickel-Based High-Temperature Alloy K444\",\"authors\":\"Hao Huang,&nbsp;Yao Huang,&nbsp;Hexin Zhang\",\"doi\":\"10.1007/s11837-025-07573-y\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><p>The morphology, volume fraction, and size distribution of the <i>γ</i>′ phase significantly influence the fabrication of high-temperature alloys and their performance under severe service conditions. This study systematically investigates the dissolution, precipitation, and growth behavior of various <i>γ</i>′ phases during heat treatment. The results demonstrate that the <i>γ</i>/<i>γ</i>′ eutectic structure between dendrites decomposes first during the solution treatment, forming coarsened <i>γ</i>′ agglomerates, which subsequently dissolve into the <i>γ</i> matrix. The splitting and dissolution mechanism of the coarsened primary <i>γ</i>′ phase within the <i>γ</i>′ agglomerate regions is clarified. Increasing the solution temperature and prolonging the solution time enhance the growth of secondary <i>γ</i>′ phases by accelerating the splitting and dissolution of the <i>γ</i>/<i>γ</i>″ eutectic structure. During heat treatment, carbide segregation at grain boundaries induces <i>γ</i>′ coarsening at these boundaries. The combined effects of carbides with varying sizes, the coarsened <i>γ</i>′ precipitates at grain boundaries, and the pinning effect of precipitates on local grain boundaries lead to the formation of serrated grain boundary morphologies. These findings enhance the understanding of the evolution of <i>γ</i>′ phases in nickel-based superalloys during heat treatment and provide a theoretical basis for optimizing the heat treatment processes of the K444 alloy.</p></div>\",\"PeriodicalId\":605,\"journal\":{\"name\":\"JOM\",\"volume\":\"77 10\",\"pages\":\"7655 - 7667\"},\"PeriodicalIF\":2.3000,\"publicationDate\":\"2025-07-15\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"JOM\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://link.springer.com/article/10.1007/s11837-025-07573-y\",\"RegionNum\":4,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q3\",\"JCRName\":\"MATERIALS SCIENCE, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"JOM","FirstCategoryId":"88","ListUrlMain":"https://link.springer.com/article/10.1007/s11837-025-07573-y","RegionNum":4,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q3","JCRName":"MATERIALS SCIENCE, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

γ′相的形貌、体积分数和尺寸分布对高温合金的制备及其在恶劣使用条件下的性能有重要影响。本研究系统地研究了热处理过程中各种γ′相的溶解、析出和生长行为。结果表明:固溶处理时,枝晶间的γ/γ′共晶结构首先分解,形成粗化的γ′团聚体,并溶入γ基体;阐明了粗化初生γ′相在γ′凝聚区内的分裂和溶解机理。提高固溶温度和延长固溶时间,通过加速γ/γ″共晶结构的分裂和溶解,促进γ′次生相的生长。热处理过程中,晶界处碳化物偏析导致晶界处γ′粗化。不同尺寸的碳化物、晶界处粗化的γ′析出物以及析出物对局部晶界的钉住作用共同作用,形成了锯齿状的晶界形貌。这些发现增强了对镍基高温合金在热处理过程中γ′相演化的认识,为优化K444合金的热处理工艺提供了理论依据。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Dissolution and Precipitation Behavior of the γ′ Phase During Heat Treatment of the Nickel-Based High-Temperature Alloy K444

Dissolution and Precipitation Behavior of the γ′ Phase During Heat Treatment of the Nickel-Based High-Temperature Alloy K444

Dissolution and Precipitation Behavior of the γ′ Phase During Heat Treatment of the Nickel-Based High-Temperature Alloy K444

The morphology, volume fraction, and size distribution of the γ′ phase significantly influence the fabrication of high-temperature alloys and their performance under severe service conditions. This study systematically investigates the dissolution, precipitation, and growth behavior of various γ′ phases during heat treatment. The results demonstrate that the γ/γ′ eutectic structure between dendrites decomposes first during the solution treatment, forming coarsened γ′ agglomerates, which subsequently dissolve into the γ matrix. The splitting and dissolution mechanism of the coarsened primary γ′ phase within the γ′ agglomerate regions is clarified. Increasing the solution temperature and prolonging the solution time enhance the growth of secondary γ′ phases by accelerating the splitting and dissolution of the γ/γ″ eutectic structure. During heat treatment, carbide segregation at grain boundaries induces γ′ coarsening at these boundaries. The combined effects of carbides with varying sizes, the coarsened γ′ precipitates at grain boundaries, and the pinning effect of precipitates on local grain boundaries lead to the formation of serrated grain boundary morphologies. These findings enhance the understanding of the evolution of γ′ phases in nickel-based superalloys during heat treatment and provide a theoretical basis for optimizing the heat treatment processes of the K444 alloy.
