Alteration mapping in granitic gneiss using handheld geophysical and geochemical instruments: Implications for iron oxide-apatite and rare earth elements exploration

The Adirondack Mountains of New York, U.S.A. contain iron oxide-apatite (IOA) mineral deposits with variable concentrations of rare earth elements (REE). The IOA mineral deposits are typically hosted in the Lyon Mountain Granite Gneiss and are spatially correlated with extensive Na metasomatism (albitization) of the surrounding country rocks, although some mineral deposits also occur in metagabbro, paragneiss, and anorthosite hosts. The location of albitization zones is key to finding new IOA mineral deposits and better understanding the mineralization processes associated with their genesis. However, the Na alteration zones are generally not visibly identifiable in outcrop or hand specimens because the color and textural changes are subtle and are thus difficult to map. Here, we discuss the results from testing two spectroscopic techniques (handheld, field gamma-ray spectroscopy, and portable X-ray fluorescence (pXRF)) to characterize albitization zones surrounding IOA mineral deposits.

The gamma-ray and pXRF spectrometers successfully distinguished the relative intensity of alteration in the Lyon Mountain Granite Gneiss based on the K abundance. The measured K content decreases towards the IOA mineral deposits, and the magnitude and width of the gradient are similar along the strike of each mineral deposit. Elevated Th and U values are present in host rocks adjacent to REE-bearing IOA mineral deposits. The pXRF and gamma-ray spectrometer K values are remarkably consistent with laboratory-based, whole-rock XRF compositional data and, therefore, useful for semi-quantitative analysis. Notably, albitization aureoles are consistent around REE-rich and REE-poor mineral deposits, suggesting that saline fluids are essential for the petrogenesis of IOA mineral deposits but may not be critical to REE mineralization. Ultimately, this study demonstrates the utility of handheld gamma-ray and pXRF spectrometry for identifying otherwise cryptic albitization gradients associated with IOA mineral deposits in granitic gneiss.
