由杂环吡唑酮配体衍生的两个新的方形平面Cu(II)配合物:合成、体外抗癌活性、DFT和Hirshfeld分析

IF 1.7 4区 化学 Q3 CHEMISTRY, INORGANIC & NUCLEAR
Sapna V. Barad, Rajendrasinh N. Jadeja, Ray J. Butcher
{"title":"由杂环吡唑酮配体衍生的两个新的方形平面Cu(II)配合物:合成、体外抗癌活性、DFT和Hirshfeld分析","authors":"Sapna V. Barad,&nbsp;Rajendrasinh N. Jadeja,&nbsp;Ray J. Butcher","doi":"10.1007/s11243-025-00649-3","DOIUrl":null,"url":null,"abstract":"<div><p>The current work describes the synthesis of two Cu(II) complexes [Cu(LA<sub>I</sub>)<sub>2</sub>] complex-1 and [Cu(LA<sub>II</sub>)<sub>2</sub>] complex-2 based on <i>σ</i>-donating acylpyarazolone ligands. Both complexes were thoroughly investigated using FTIR, UV–Vis, TGA and ESR spectroscopy methods. Additionally, single-crystal X-ray diffraction analysis was employed to determine their structures. The analysis indicates that the Cu<sup>2</sup>⁺ ion in both complexes occupies a centre of inversion symmetry and exhibits square-planar geometry. The examined complexes [Cu(LA<sub>I</sub>)<sub>2</sub>] complex-1 and [Cu(LA<sub>II</sub>)<sub>2</sub>] complex-2 crystallize in the <i>P</i>2<sub>1</sub>/c Monoclinic and <i>P</i>2<sub>1</sub>/n Monoclinic space groups, respectively, according to the X-ray single-crystal investigation. In addition to the experimental and spectroscopic investigations, DFT calculations were performed using the B3LYP functional with the LANL2DZ basis set for optimization. The bond lengths and bond angles determined from the DFT calculations are consistent with the X-ray data. HOMO–LUMO energy, natural bonding orbital and spin density analyses were also conducted to provide the best possible correlation and comparison with the experimental data. Intermolecular and non-covalent interactions were examined using Hirshfeld surface analysis. Furthermore, a cytotoxicity assay of the synthesized [Cu(LA<sub>II</sub>)<sub>2</sub>] complex-2 was performed against three different cancer cell lines: NCI-H23 (lung carcinoma cell line—lung cancer), SH-SY5Y (neuroblastoma cell line—neuroblastoma cancer) and HepG2 (hepatocellular carcinoma cell line—liver cancer), where notable cell death was observed, demonstrating the effectiveness of the complex against cancer cells.</p><h3>Graphical abstract</h3><div><figure><div><div><picture><source><img></source></picture></div></div></figure></div></div>","PeriodicalId":803,"journal":{"name":"Transition Metal Chemistry","volume":"50 5","pages":"687 - 706"},"PeriodicalIF":1.7000,"publicationDate":"2025-03-18","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Two new square-planar Cu(II) complexes derived from a heterocyclic pyrazolone ligand: synthesis, in vitro anticancer activity, DFT and Hirshfeld analysis\",\"authors\":\"Sapna V. Barad,&nbsp;Rajendrasinh N. Jadeja,&nbsp;Ray J. Butcher\",\"doi\":\"10.1007/s11243-025-00649-3\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><p>The current work describes the synthesis of two Cu(II) complexes [Cu(LA<sub>I</sub>)<sub>2</sub>] complex-1 and [Cu(LA<sub>II</sub>)<sub>2</sub>] complex-2 based on <i>σ</i>-donating acylpyarazolone ligands. Both complexes were thoroughly investigated using FTIR, UV–Vis, TGA and ESR spectroscopy methods. Additionally, single-crystal X-ray diffraction analysis was employed to determine their structures. The analysis indicates that the Cu<sup>2</sup>⁺ ion in both complexes occupies a centre of inversion symmetry and exhibits square-planar geometry. The examined complexes [Cu(LA<sub>I</sub>)<sub>2</sub>] complex-1 and [Cu(LA<sub>II</sub>)<sub>2</sub>] complex-2 crystallize in the <i>P</i>2<sub>1</sub>/c Monoclinic and <i>P</i>2<sub>1</sub>/n Monoclinic space groups, respectively, according to the X-ray single-crystal investigation. In addition to the experimental and spectroscopic investigations, DFT calculations were performed using the B3LYP functional with the LANL2DZ basis set for optimization. The bond lengths and bond angles determined from the DFT calculations are consistent with the X-ray data. HOMO–LUMO energy, natural bonding orbital and spin density analyses were also conducted to provide the best possible correlation and comparison with the experimental data. Intermolecular and non-covalent interactions were examined using Hirshfeld surface analysis. Furthermore, a cytotoxicity assay of the synthesized [Cu(LA<sub>II</sub>)<sub>2</sub>] complex-2 was performed against three different cancer cell lines: NCI-H23 (lung carcinoma cell line—lung cancer), SH-SY5Y (neuroblastoma cell line—neuroblastoma cancer) and HepG2 (hepatocellular carcinoma cell line—liver cancer), where notable cell death was observed, demonstrating the effectiveness of the complex against cancer cells.</p><h3>Graphical abstract</h3><div><figure><div><div><picture><source><img></source></picture></div></div></figure></div></div>\",\"PeriodicalId\":803,\"journal\":{\"name\":\"Transition Metal Chemistry\",\"volume\":\"50 5\",\"pages\":\"687 - 706\"},\"PeriodicalIF\":1.7000,\"publicationDate\":\"2025-03-18\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Transition Metal Chemistry\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://link.springer.com/article/10.1007/s11243-025-00649-3\",\"RegionNum\":4,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q3\",\"JCRName\":\"CHEMISTRY, INORGANIC & NUCLEAR\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Transition Metal Chemistry","FirstCategoryId":"92","ListUrlMain":"https://link.springer.com/article/10.1007/s11243-025-00649-3","RegionNum":4,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q3","JCRName":"CHEMISTRY, INORGANIC & NUCLEAR","Score":null,"Total":0}
引用次数: 0

摘要

本文描述了以σ给体酰基吡喃唑酮为配体合成两种Cu(II)配合物[Cu(LAI)2]配合物1和[Cu(LAI)2]配合物2。用FTIR、UV-Vis、TGA和ESR等方法对这两种配合物进行了深入的研究。此外,采用单晶x射线衍射分析确定了它们的结构。分析表明,两种配合物中的Cu2 +离子都占据了一个反演对称中心,并呈现出方平面几何形状。x射线单晶研究表明,[Cu(LAI)2]配合物-1和[Cu(LAII)2]配合物-2分别在P21/c单斜和P21/n单斜空间群中结晶。除了实验和光谱研究外,使用B3LYP泛函进行DFT计算,并使用LANL2DZ基集进行优化。由DFT计算得到的键长和键角与x射线数据一致。为了提供与实验数据最好的相关性和比较,还进行了HOMO-LUMO能量、自然成键轨道和自旋密度分析。分子间和非共价相互作用采用赫希菲尔德表面分析。此外,合成的[Cu(LAII)2]复合物-2对三种不同的癌细胞系进行了细胞毒性试验:NCI-H23(肺癌细胞系-肺癌),SH-SY5Y(神经母细胞瘤细胞系-神经母细胞瘤癌)和HepG2(肝细胞癌细胞系-肝癌),观察到明显的细胞死亡,证明了复合物对癌细胞的有效性。图形抽象
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Two new square-planar Cu(II) complexes derived from a heterocyclic pyrazolone ligand: synthesis, in vitro anticancer activity, DFT and Hirshfeld analysis

Two new square-planar Cu(II) complexes derived from a heterocyclic pyrazolone ligand: synthesis, in vitro anticancer activity, DFT and Hirshfeld analysis

Two new square-planar Cu(II) complexes derived from a heterocyclic pyrazolone ligand: synthesis, in vitro anticancer activity, DFT and Hirshfeld analysis

The current work describes the synthesis of two Cu(II) complexes [Cu(LAI)2] complex-1 and [Cu(LAII)2] complex-2 based on σ-donating acylpyarazolone ligands. Both complexes were thoroughly investigated using FTIR, UV–Vis, TGA and ESR spectroscopy methods. Additionally, single-crystal X-ray diffraction analysis was employed to determine their structures. The analysis indicates that the Cu2⁺ ion in both complexes occupies a centre of inversion symmetry and exhibits square-planar geometry. The examined complexes [Cu(LAI)2] complex-1 and [Cu(LAII)2] complex-2 crystallize in the P21/c Monoclinic and P21/n Monoclinic space groups, respectively, according to the X-ray single-crystal investigation. In addition to the experimental and spectroscopic investigations, DFT calculations were performed using the B3LYP functional with the LANL2DZ basis set for optimization. The bond lengths and bond angles determined from the DFT calculations are consistent with the X-ray data. HOMO–LUMO energy, natural bonding orbital and spin density analyses were also conducted to provide the best possible correlation and comparison with the experimental data. Intermolecular and non-covalent interactions were examined using Hirshfeld surface analysis. Furthermore, a cytotoxicity assay of the synthesized [Cu(LAII)2] complex-2 was performed against three different cancer cell lines: NCI-H23 (lung carcinoma cell line—lung cancer), SH-SY5Y (neuroblastoma cell line—neuroblastoma cancer) and HepG2 (hepatocellular carcinoma cell line—liver cancer), where notable cell death was observed, demonstrating the effectiveness of the complex against cancer cells.

Graphical abstract
