利用基于xlstm的深度学习和空间注意和滤波器库技术增强SSVEP仿生拼写。

IF 3.9 3区 医学 Q1 ENGINEERING, MULTIDISCIPLINARY
Liuyuan Dong, Chengzhi Xu, Ruizhen Xie, Xuyang Wang, Wanli Yang, Yimeng Li
{"title":"利用基于xlstm的深度学习和空间注意和滤波器库技术增强SSVEP仿生拼写。","authors":"Liuyuan Dong, Chengzhi Xu, Ruizhen Xie, Xuyang Wang, Wanli Yang, Yimeng Li","doi":"10.3390/biomimetics10080554","DOIUrl":null,"url":null,"abstract":"<p><p>Steady-State Visual Evoked Potentials (SSVEPs) have emerged as an efficient means of interaction in brain-computer interfaces (BCIs), achieving bioinspired efficient language output for individuals with aphasia. Addressing the underutilization of frequency information of SSVEPs and redundant computation by existing transformer-based deep learning methods, this paper analyzes signals from both the time and frequency domains, proposing a stacked encoder-decoder (SED) network architecture based on an xLSTM model and spatial attention mechanism, termed SED-xLSTM, which firstly applies xLSTM to the SSVEP speller field. This model takes the low-channel spectrogram as input and employs the filter bank technique to make full use of harmonic information. By leveraging a gating mechanism, SED-xLSTM effectively extracts and fuses high-dimensional spatial-channel semantic features from SSVEP signals. Experimental results on three public datasets demonstrate the superior performance of SED-xLSTM in terms of classification accuracy and information transfer rate, particularly outperforming existing methods under cross-validation across various temporal scales.</p>","PeriodicalId":8907,"journal":{"name":"Biomimetics","volume":"10 8","pages":""},"PeriodicalIF":3.9000,"publicationDate":"2025-08-21","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12383547/pdf/","citationCount":"0","resultStr":"{\"title\":\"Enhanced SSVEP Bionic Spelling via xLSTM-Based Deep Learning with Spatial Attention and Filter Bank Techniques.\",\"authors\":\"Liuyuan Dong, Chengzhi Xu, Ruizhen Xie, Xuyang Wang, Wanli Yang, Yimeng Li\",\"doi\":\"10.3390/biomimetics10080554\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Steady-State Visual Evoked Potentials (SSVEPs) have emerged as an efficient means of interaction in brain-computer interfaces (BCIs), achieving bioinspired efficient language output for individuals with aphasia. Addressing the underutilization of frequency information of SSVEPs and redundant computation by existing transformer-based deep learning methods, this paper analyzes signals from both the time and frequency domains, proposing a stacked encoder-decoder (SED) network architecture based on an xLSTM model and spatial attention mechanism, termed SED-xLSTM, which firstly applies xLSTM to the SSVEP speller field. This model takes the low-channel spectrogram as input and employs the filter bank technique to make full use of harmonic information. By leveraging a gating mechanism, SED-xLSTM effectively extracts and fuses high-dimensional spatial-channel semantic features from SSVEP signals. Experimental results on three public datasets demonstrate the superior performance of SED-xLSTM in terms of classification accuracy and information transfer rate, particularly outperforming existing methods under cross-validation across various temporal scales.</p>\",\"PeriodicalId\":8907,\"journal\":{\"name\":\"Biomimetics\",\"volume\":\"10 8\",\"pages\":\"\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2025-08-21\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12383547/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Biomimetics\",\"FirstCategoryId\":\"5\",\"ListUrlMain\":\"https://doi.org/10.3390/biomimetics10080554\",\"RegionNum\":3,\"RegionCategory\":\"医学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"ENGINEERING, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Biomimetics","FirstCategoryId":"5","ListUrlMain":"https://doi.org/10.3390/biomimetics10080554","RegionNum":3,"RegionCategory":"医学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"ENGINEERING, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

稳态视觉诱发电位(SSVEPs)已成为脑机接口(bci)中一种有效的交互手段,为失语症患者实现生物启发的高效语言输出。针对现有基于变压器的深度学习方法对SSVEP频率信息利用不足和计算冗余的问题,从时域和频域对信号进行分析,提出了一种基于xLSTM模型和空间注意机制的堆叠式编码器(SED)网络架构SED-xLSTM,首次将xLSTM应用于SSVEP拼写领域。该模型以低通道频谱图为输入,采用滤波器组技术,充分利用谐波信息。通过利用门通机制,SED-xLSTM可以有效地从SSVEP信号中提取和融合高维空间通道语义特征。在三个公共数据集上的实验结果表明,该方法在分类精度和信息传递率方面具有优异的性能,特别是在跨时间尺度的交叉验证下优于现有方法。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Enhanced SSVEP Bionic Spelling via xLSTM-Based Deep Learning with Spatial Attention and Filter Bank Techniques.

Enhanced SSVEP Bionic Spelling via xLSTM-Based Deep Learning with Spatial Attention and Filter Bank Techniques.

Enhanced SSVEP Bionic Spelling via xLSTM-Based Deep Learning with Spatial Attention and Filter Bank Techniques.

Enhanced SSVEP Bionic Spelling via xLSTM-Based Deep Learning with Spatial Attention and Filter Bank Techniques.

Steady-State Visual Evoked Potentials (SSVEPs) have emerged as an efficient means of interaction in brain-computer interfaces (BCIs), achieving bioinspired efficient language output for individuals with aphasia. Addressing the underutilization of frequency information of SSVEPs and redundant computation by existing transformer-based deep learning methods, this paper analyzes signals from both the time and frequency domains, proposing a stacked encoder-decoder (SED) network architecture based on an xLSTM model and spatial attention mechanism, termed SED-xLSTM, which firstly applies xLSTM to the SSVEP speller field. This model takes the low-channel spectrogram as input and employs the filter bank technique to make full use of harmonic information. By leveraging a gating mechanism, SED-xLSTM effectively extracts and fuses high-dimensional spatial-channel semantic features from SSVEP signals. Experimental results on three public datasets demonstrate the superior performance of SED-xLSTM in terms of classification accuracy and information transfer rate, particularly outperforming existing methods under cross-validation across various temporal scales.
