LaNiO3/MXene超级电容器电极的离子电导率、扩散动力学和转移数的协同改进

IF 4.7 4区 材料科学 Q2 ELECTROCHEMISTRY
Abdul Shakoor, Muhammad Adnan, Muhammad Luqman, Muhammad Ahmed Khan, Shahid M. Ramay, Farooq Ahmad, Shahid Atiq
{"title":"LaNiO3/MXene超级电容器电极的离子电导率、扩散动力学和转移数的协同改进","authors":"Abdul Shakoor,&nbsp;Muhammad Adnan,&nbsp;Muhammad Luqman,&nbsp;Muhammad Ahmed Khan,&nbsp;Shahid M. Ramay,&nbsp;Farooq Ahmad,&nbsp;Shahid Atiq","doi":"10.1002/batt.202500014","DOIUrl":null,"url":null,"abstract":"<p>Supercapacitors are crucial for bridging energy storage gaps, offering rapid charge/discharge rates, long cycle life, and high power density, key for renewable energy systems and electric vehicles. This study incorporated MXene (Ti<sub>3</sub>C<sub>2</sub>T<sub><i>x</i></sub>) into LaNiO<sub>3</sub> (PLNO) at 0, 10, 20, and 30 wt% via solvothermal synthesis. X-ray diffraction confirmed a simple cubic phase across all samples. BET analysis and FESEM revealed mesoporous structures and reduced grain sizes due to MXene inclusion, contributing to enhanced electrochemical performance. Elemental analysis via EDS matched expected stoichiometry. Cyclic voltammetry indicated battery-type behavior, with the LNO-III sample achieving the highest capacity of 541.60 C g<sup>−1</sup> at 2.5 mV s<sup>−1</sup>. Galvanostatic charge/discharge profiles showed increasing discharge times with higher MXene content. The Ragone plot highlighted excellent energy and power densities of 84.30 Wh kg<sup>−1</sup> and 2125 W kg<sup>−1</sup> at 2.5 A g<sup>−1</sup>. Long-term testing demonstrated strong cycle stability, with 88.12% retention over 10 000 cycles. Electrochemical impedance spectroscopy showed low charge transfer resistance (0.84 Ω), short relaxation time (17 ms), high ion diffusion rate (9.5 × 10<sup>−13</sup> m<sup>2</sup> s<sup>−1</sup>), good ionic conductivity (6.3 × 10<sup>−</sup><sup>3</sup> S cm<sup>−1</sup>), and a transference number (t<sub>+</sub>) of 0.3. These results confirm the potential of MXene-modified PLNO as a promising electrode for high-performance supercapacitors.\n <figure>\n <div><picture>\n <source></source></picture><p></p>\n </div>\n </figure></p>","PeriodicalId":132,"journal":{"name":"Batteries & Supercaps","volume":"8 9","pages":""},"PeriodicalIF":4.7000,"publicationDate":"2025-04-14","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Synergistic Improvements in Ionic Conductivity, Diffusion Dynamics, and Transference Numbers for LaNiO3/MXene Supercapacitor Electrodes\",\"authors\":\"Abdul Shakoor,&nbsp;Muhammad Adnan,&nbsp;Muhammad Luqman,&nbsp;Muhammad Ahmed Khan,&nbsp;Shahid M. Ramay,&nbsp;Farooq Ahmad,&nbsp;Shahid Atiq\",\"doi\":\"10.1002/batt.202500014\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p>Supercapacitors are crucial for bridging energy storage gaps, offering rapid charge/discharge rates, long cycle life, and high power density, key for renewable energy systems and electric vehicles. This study incorporated MXene (Ti<sub>3</sub>C<sub>2</sub>T<sub><i>x</i></sub>) into LaNiO<sub>3</sub> (PLNO) at 0, 10, 20, and 30 wt% via solvothermal synthesis. X-ray diffraction confirmed a simple cubic phase across all samples. BET analysis and FESEM revealed mesoporous structures and reduced grain sizes due to MXene inclusion, contributing to enhanced electrochemical performance. Elemental analysis via EDS matched expected stoichiometry. Cyclic voltammetry indicated battery-type behavior, with the LNO-III sample achieving the highest capacity of 541.60 C g<sup>−1</sup> at 2.5 mV s<sup>−1</sup>. Galvanostatic charge/discharge profiles showed increasing discharge times with higher MXene content. The Ragone plot highlighted excellent energy and power densities of 84.30 Wh kg<sup>−1</sup> and 2125 W kg<sup>−1</sup> at 2.5 A g<sup>−1</sup>. Long-term testing demonstrated strong cycle stability, with 88.12% retention over 10 000 cycles. Electrochemical impedance spectroscopy showed low charge transfer resistance (0.84 Ω), short relaxation time (17 ms), high ion diffusion rate (9.5 × 10<sup>−13</sup> m<sup>2</sup> s<sup>−1</sup>), good ionic conductivity (6.3 × 10<sup>−</sup><sup>3</sup> S cm<sup>−1</sup>), and a transference number (t<sub>+</sub>) of 0.3. These results confirm the potential of MXene-modified PLNO as a promising electrode for high-performance supercapacitors.\\n <figure>\\n <div><picture>\\n <source></source></picture><p></p>\\n </div>\\n </figure></p>\",\"PeriodicalId\":132,\"journal\":{\"name\":\"Batteries & Supercaps\",\"volume\":\"8 9\",\"pages\":\"\"},\"PeriodicalIF\":4.7000,\"publicationDate\":\"2025-04-14\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Batteries & Supercaps\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://chemistry-europe.onlinelibrary.wiley.com/doi/10.1002/batt.202500014\",\"RegionNum\":4,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"ELECTROCHEMISTRY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Batteries & Supercaps","FirstCategoryId":"88","ListUrlMain":"https://chemistry-europe.onlinelibrary.wiley.com/doi/10.1002/batt.202500014","RegionNum":4,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"ELECTROCHEMISTRY","Score":null,"Total":0}
引用次数: 0

摘要

超级电容器对于弥合能量存储差距至关重要,它提供快速的充放电速率、长循环寿命和高功率密度,是可再生能源系统和电动汽车的关键。本研究通过溶剂热合成将MXene (Ti3C2Tx)加入到LaNiO3 (PLNO)中,质量分数分别为0%、10%、20%和30%。x射线衍射证实了所有样品的简单立方相。BET分析和FESEM分析显示,由于MXene的加入,材料具有介孔结构,晶粒尺寸减小,有助于提高电化学性能。元素分析通过EDS符合预期的化学计量。循环伏安法显示了电池类型的行为,LNO-III样品在2.5 mV s−1下的最高容量为541.60 C g−1。恒流充放电曲线显示,随着MXene含量的增加,放电次数增加。Ragone图显示,在2.5 A g - 1下,能量和功率密度分别为84.30 Wh kg - 1和2125 W kg - 1。长期测试表明具有很强的循环稳定性,在10,000次循环中保留率为88.12%。电化学阻抗谱显示电荷转移电阻低(0.84 Ω),弛豫时间短(17 ms),离子扩散速率高(9.5 × 10−13 m2 s−1),离子电导率好(6.3 × 10−3 s cm−1),转移数(t+)为0.3。这些结果证实了mxene修饰PLNO作为高性能超级电容器电极的潜力。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Synergistic Improvements in Ionic Conductivity, Diffusion Dynamics, and Transference Numbers for LaNiO3/MXene Supercapacitor Electrodes

Synergistic Improvements in Ionic Conductivity, Diffusion Dynamics, and Transference Numbers for LaNiO3/MXene Supercapacitor Electrodes

Synergistic Improvements in Ionic Conductivity, Diffusion Dynamics, and Transference Numbers for LaNiO3/MXene Supercapacitor Electrodes

Synergistic Improvements in Ionic Conductivity, Diffusion Dynamics, and Transference Numbers for LaNiO3/MXene Supercapacitor Electrodes

Synergistic Improvements in Ionic Conductivity, Diffusion Dynamics, and Transference Numbers for LaNiO3/MXene Supercapacitor Electrodes

Supercapacitors are crucial for bridging energy storage gaps, offering rapid charge/discharge rates, long cycle life, and high power density, key for renewable energy systems and electric vehicles. This study incorporated MXene (Ti3C2Tx) into LaNiO3 (PLNO) at 0, 10, 20, and 30 wt% via solvothermal synthesis. X-ray diffraction confirmed a simple cubic phase across all samples. BET analysis and FESEM revealed mesoporous structures and reduced grain sizes due to MXene inclusion, contributing to enhanced electrochemical performance. Elemental analysis via EDS matched expected stoichiometry. Cyclic voltammetry indicated battery-type behavior, with the LNO-III sample achieving the highest capacity of 541.60 C g−1 at 2.5 mV s−1. Galvanostatic charge/discharge profiles showed increasing discharge times with higher MXene content. The Ragone plot highlighted excellent energy and power densities of 84.30 Wh kg−1 and 2125 W kg−1 at 2.5 A g−1. Long-term testing demonstrated strong cycle stability, with 88.12% retention over 10 000 cycles. Electrochemical impedance spectroscopy showed low charge transfer resistance (0.84 Ω), short relaxation time (17 ms), high ion diffusion rate (9.5 × 10−13 m2 s−1), good ionic conductivity (6.3 × 103 S cm−1), and a transference number (t+) of 0.3. These results confirm the potential of MXene-modified PLNO as a promising electrode for high-performance supercapacitors.
