碳包覆MgO-Al2O3复合催化剂在肉桂醛转移加氢制肉桂醇中的高性能研究

IF 3.9 3区 工程技术 Q2 ENGINEERING, CHEMICAL
Peng Zhang, Tianli Chen, Ying-Ya Liu, Zhichao Sun, Yao Wang*, Wei Wang and Anjie Wang*,
{"title":"碳包覆MgO-Al2O3复合催化剂在肉桂醛转移加氢制肉桂醇中的高性能研究","authors":"Peng Zhang,&nbsp;Tianli Chen,&nbsp;Ying-Ya Liu,&nbsp;Zhichao Sun,&nbsp;Yao Wang*,&nbsp;Wei Wang and Anjie Wang*,&nbsp;","doi":"10.1021/acs.iecr.5c03051","DOIUrl":null,"url":null,"abstract":"<p >Mg and Al layered double hydroxide (LDH) was allowed to react with glucose at 180 °C for 3 h, and subsequent pyrolysis in N<sub>2</sub> at 600 °C for 4 h led to a carbon-coated MgO–Al<sub>2</sub>O<sub>3</sub> composite catalyst. The catalytic performance was tested in the transfer hydrogenation of cinnamaldehyde (CAL) to selectively produce cinnamyl alcohol (COL). The catalyst with a Mg/Al ratio of 3 (Mg<sub>3</sub>–Al<sub>1</sub>@C) exhibited 97.2% conversion with 99.9% selectivity to COL in 3 h at 100 °C using isopropanol (IPA) as the solvent and hydrogen donor, and, in contrast, the counterpart without carbon coating (Mg<sub>3</sub>–Al<sub>1</sub>) gave 50.3% conversion with 88.2% selectivity. Characterization by means of X-ray diffraction (XRD), CO<sub>2</sub>-TPD, NH<sub>3</sub>-TPD, and transmission electron microscopy (TEM) revealed that the carbon layer on Mg–Al mixed metal oxide was able to markedly reduce the undesired sites of strong acid and strong base. It was found that the improved selectivity to COL was related to the reduction of the strong basic sites on the surface, which promoted the side reaction of aldol condensation of cinnamaldehyde. The adsorption of IPA, CAL, and COL, as well as the measurements of contact angle, revealed that the high performance of Mg<sub>3</sub>–Al<sub>1</sub>@C was closely related to the enhanced desorption of COL and improved adsorption of both IPA and CAL due to the presence of the external carbon layers. In addition, the presence of carbon layers helps to prevent the unfavorable deposition of bulky molecules produced in the course of the reaction. After seven consecutive runs, the conversion and selectivity of Mg<sub>3</sub>–Al<sub>1</sub>@C hardly changed, whereas those of Mg<sub>3</sub>–Al<sub>1</sub> declined from 43.3% to 3.9%. In addition, Mg<sub>3</sub>–Al<sub>1</sub>@C exhibited high performance in the transfer hydrogenation of other unsaturated aldehydes, including furfural, geranialdehyde, benzaldehyde, and syringaldehyde.</p>","PeriodicalId":39,"journal":{"name":"Industrial & Engineering Chemistry Research","volume":"64 36","pages":"17646–17657"},"PeriodicalIF":3.9000,"publicationDate":"2025-09-01","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"High Performance of Carbon-Coated MgO–Al2O3 Composite Catalysts in Transfer Hydrogenation of Cinnamaldehyde to Cinnamyl Alcohol\",\"authors\":\"Peng Zhang,&nbsp;Tianli Chen,&nbsp;Ying-Ya Liu,&nbsp;Zhichao Sun,&nbsp;Yao Wang*,&nbsp;Wei Wang and Anjie Wang*,&nbsp;\",\"doi\":\"10.1021/acs.iecr.5c03051\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >Mg and Al layered double hydroxide (LDH) was allowed to react with glucose at 180 °C for 3 h, and subsequent pyrolysis in N<sub>2</sub> at 600 °C for 4 h led to a carbon-coated MgO–Al<sub>2</sub>O<sub>3</sub> composite catalyst. The catalytic performance was tested in the transfer hydrogenation of cinnamaldehyde (CAL) to selectively produce cinnamyl alcohol (COL). The catalyst with a Mg/Al ratio of 3 (Mg<sub>3</sub>–Al<sub>1</sub>@C) exhibited 97.2% conversion with 99.9% selectivity to COL in 3 h at 100 °C using isopropanol (IPA) as the solvent and hydrogen donor, and, in contrast, the counterpart without carbon coating (Mg<sub>3</sub>–Al<sub>1</sub>) gave 50.3% conversion with 88.2% selectivity. Characterization by means of X-ray diffraction (XRD), CO<sub>2</sub>-TPD, NH<sub>3</sub>-TPD, and transmission electron microscopy (TEM) revealed that the carbon layer on Mg–Al mixed metal oxide was able to markedly reduce the undesired sites of strong acid and strong base. It was found that the improved selectivity to COL was related to the reduction of the strong basic sites on the surface, which promoted the side reaction of aldol condensation of cinnamaldehyde. The adsorption of IPA, CAL, and COL, as well as the measurements of contact angle, revealed that the high performance of Mg<sub>3</sub>–Al<sub>1</sub>@C was closely related to the enhanced desorption of COL and improved adsorption of both IPA and CAL due to the presence of the external carbon layers. In addition, the presence of carbon layers helps to prevent the unfavorable deposition of bulky molecules produced in the course of the reaction. After seven consecutive runs, the conversion and selectivity of Mg<sub>3</sub>–Al<sub>1</sub>@C hardly changed, whereas those of Mg<sub>3</sub>–Al<sub>1</sub> declined from 43.3% to 3.9%. In addition, Mg<sub>3</sub>–Al<sub>1</sub>@C exhibited high performance in the transfer hydrogenation of other unsaturated aldehydes, including furfural, geranialdehyde, benzaldehyde, and syringaldehyde.</p>\",\"PeriodicalId\":39,\"journal\":{\"name\":\"Industrial & Engineering Chemistry Research\",\"volume\":\"64 36\",\"pages\":\"17646–17657\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2025-09-01\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Industrial & Engineering Chemistry Research\",\"FirstCategoryId\":\"5\",\"ListUrlMain\":\"https://pubs.acs.org/doi/10.1021/acs.iecr.5c03051\",\"RegionNum\":3,\"RegionCategory\":\"工程技术\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"ENGINEERING, CHEMICAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Industrial & Engineering Chemistry Research","FirstCategoryId":"5","ListUrlMain":"https://pubs.acs.org/doi/10.1021/acs.iecr.5c03051","RegionNum":3,"RegionCategory":"工程技术","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"ENGINEERING, CHEMICAL","Score":null,"Total":0}
引用次数: 0

摘要

Mg和Al层状双氢氧化物(LDH)与葡萄糖在180℃下反应3 h,然后在600℃的N2中热解4 h,得到碳包覆的MgO-Al2O3复合催化剂。研究了肉桂醛(CAL)转移加氢选择性制备肉桂醇(COL)的催化性能。Mg/Al比为3的催化剂(Mg3 - Al1@C)在100℃条件下,以异丙醇(IPA)为溶剂和氢供体,在3 h内对COL的转化率为97.2%,选择性为99.9%,而未包碳的对应物(Mg3 - al1)的转化率为50.3%,选择性为88.2%。通过x射线衍射(XRD)、CO2-TPD、NH3-TPD和透射电镜(TEM)表征表明,碳层在Mg-Al混合金属氧化物上能够显著减少强酸和强碱的不需要位点。结果表明,对COL选择性的提高与表面强碱位的减少有关,这促进了肉桂醛醛缩合的副反应。对IPA、CAL和COL的吸附以及接触角的测量表明,Mg3 - Al1@C的高性能与外部碳层的存在增强了对COL的解吸和对IPA和CAL的吸附密切相关。此外,碳层的存在有助于防止反应过程中产生的大分子的不利沉积。连续运行7次后,Mg3 - Al1@C的转化率和选择性基本没有变化,而Mg3 - al1的转化率和选择性从43.3%下降到3.9%。此外,Mg3 - Al1@C在其他不饱和醛(包括糠醛、香叶醛、苯甲醛和丁香醛)的转移加氢反应中表现出优异的性能。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

High Performance of Carbon-Coated MgO–Al2O3 Composite Catalysts in Transfer Hydrogenation of Cinnamaldehyde to Cinnamyl Alcohol

High Performance of Carbon-Coated MgO–Al2O3 Composite Catalysts in Transfer Hydrogenation of Cinnamaldehyde to Cinnamyl Alcohol

High Performance of Carbon-Coated MgO–Al2O3 Composite Catalysts in Transfer Hydrogenation of Cinnamaldehyde to Cinnamyl Alcohol

Mg and Al layered double hydroxide (LDH) was allowed to react with glucose at 180 °C for 3 h, and subsequent pyrolysis in N2 at 600 °C for 4 h led to a carbon-coated MgO–Al2O3 composite catalyst. The catalytic performance was tested in the transfer hydrogenation of cinnamaldehyde (CAL) to selectively produce cinnamyl alcohol (COL). The catalyst with a Mg/Al ratio of 3 (Mg3–Al1@C) exhibited 97.2% conversion with 99.9% selectivity to COL in 3 h at 100 °C using isopropanol (IPA) as the solvent and hydrogen donor, and, in contrast, the counterpart without carbon coating (Mg3–Al1) gave 50.3% conversion with 88.2% selectivity. Characterization by means of X-ray diffraction (XRD), CO2-TPD, NH3-TPD, and transmission electron microscopy (TEM) revealed that the carbon layer on Mg–Al mixed metal oxide was able to markedly reduce the undesired sites of strong acid and strong base. It was found that the improved selectivity to COL was related to the reduction of the strong basic sites on the surface, which promoted the side reaction of aldol condensation of cinnamaldehyde. The adsorption of IPA, CAL, and COL, as well as the measurements of contact angle, revealed that the high performance of Mg3–Al1@C was closely related to the enhanced desorption of COL and improved adsorption of both IPA and CAL due to the presence of the external carbon layers. In addition, the presence of carbon layers helps to prevent the unfavorable deposition of bulky molecules produced in the course of the reaction. After seven consecutive runs, the conversion and selectivity of Mg3–Al1@C hardly changed, whereas those of Mg3–Al1 declined from 43.3% to 3.9%. In addition, Mg3–Al1@C exhibited high performance in the transfer hydrogenation of other unsaturated aldehydes, including furfural, geranialdehyde, benzaldehyde, and syringaldehyde.
