利用遥感、水化学和大地电磁数据表征地温带:以印度古吉拉特邦Lasundra地区为例

IF 2.1 4区 地球科学
Peush Chaudhary, Kapil Mohan, Dilip Singh Kushwaha, Sumer Chopra, Ramdayal Singh, Prabhjot Kaur
{"title":"利用遥感、水化学和大地电磁数据表征地温带:以印度古吉拉特邦Lasundra地区为例","authors":"Peush Chaudhary,&nbsp;Kapil Mohan,&nbsp;Dilip Singh Kushwaha,&nbsp;Sumer Chopra,&nbsp;Ramdayal Singh,&nbsp;Prabhjot Kaur","doi":"10.1007/s11600-025-01636-z","DOIUrl":null,"url":null,"abstract":"<div><p>The westernmost part of India is the junction of three rift basins, namely Kachchh, Cambay, and Narmada. The Cambay rift basin, located in the Gujarat state (west of India), is well known for the presence of several geothermal zones. The Lasundra geothermal zone is located on the eastern flank of the Cambay basin, in proximity to the East Cambay Marginal fault. To characterize this geothermal zone, a combined study of remote sensing, hydrochemical, and magnetotellurics is conducted in the study area (Lasundra geothermal zone). To decipher and map the temperature anomalies associated with the geothermal zone, Advanced Spaceborne Thermal Emission and Reflection Radiometer and Landsat-8 remote sensing data are used. The hydrochemical analysis of the water sample indicates the anomalous (excess) value of salinity, fluoride, TDS, conductivity, etc. To determine the depth and extension of the geothermal zone, an MT survey is carried out near and around the geothermal zone. A total of 18 MT sites with a close interstation spacing of ~ 1–2 km are acquired along two transects. From 2-D inversion of the MT data, a ~ 100-m-thick conductive layer (&lt; 30 Ohm.m) of sediments has been seen at the surface followed by the relatively less conductive layer of Deccan trap (30–150 Ohm.m), where thickness increases towards the NW direction of the profile. The results show the presence of highly conductive zones at the depth of ~ 2.5 km and ~ 4 km, respectively, along two transects. This conductive zone may be inferred as the possible reservoir associated with the Lasundra geothermal zone. The highly resistive features (&gt; 4000 Ohm.m) may represent Granite based on the resistivity values and surrounding geology. These resistive structures are encountered at shallow depths in the SE direction and extend deeper in the NW along the transects. Apart from the presence of fractures, the possibility of some blind fault zones acting as conduits for the upward migration of thermal fluid cannot be ruled out.</p></div>","PeriodicalId":6988,"journal":{"name":"Acta Geophysica","volume":"73 5","pages":"4357 - 4377"},"PeriodicalIF":2.1000,"publicationDate":"2025-07-03","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://link.springer.com/content/pdf/10.1007/s11600-025-01636-z.pdf","citationCount":"0","resultStr":"{\"title\":\"Characterization of the geothermal zone by remote sensing, hydrochemical, and magnetotellurics data: a case study from Lasundra, Gujarat, India\",\"authors\":\"Peush Chaudhary,&nbsp;Kapil Mohan,&nbsp;Dilip Singh Kushwaha,&nbsp;Sumer Chopra,&nbsp;Ramdayal Singh,&nbsp;Prabhjot Kaur\",\"doi\":\"10.1007/s11600-025-01636-z\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><p>The westernmost part of India is the junction of three rift basins, namely Kachchh, Cambay, and Narmada. The Cambay rift basin, located in the Gujarat state (west of India), is well known for the presence of several geothermal zones. The Lasundra geothermal zone is located on the eastern flank of the Cambay basin, in proximity to the East Cambay Marginal fault. To characterize this geothermal zone, a combined study of remote sensing, hydrochemical, and magnetotellurics is conducted in the study area (Lasundra geothermal zone). To decipher and map the temperature anomalies associated with the geothermal zone, Advanced Spaceborne Thermal Emission and Reflection Radiometer and Landsat-8 remote sensing data are used. The hydrochemical analysis of the water sample indicates the anomalous (excess) value of salinity, fluoride, TDS, conductivity, etc. To determine the depth and extension of the geothermal zone, an MT survey is carried out near and around the geothermal zone. A total of 18 MT sites with a close interstation spacing of ~ 1–2 km are acquired along two transects. From 2-D inversion of the MT data, a ~ 100-m-thick conductive layer (&lt; 30 Ohm.m) of sediments has been seen at the surface followed by the relatively less conductive layer of Deccan trap (30–150 Ohm.m), where thickness increases towards the NW direction of the profile. The results show the presence of highly conductive zones at the depth of ~ 2.5 km and ~ 4 km, respectively, along two transects. This conductive zone may be inferred as the possible reservoir associated with the Lasundra geothermal zone. The highly resistive features (&gt; 4000 Ohm.m) may represent Granite based on the resistivity values and surrounding geology. These resistive structures are encountered at shallow depths in the SE direction and extend deeper in the NW along the transects. Apart from the presence of fractures, the possibility of some blind fault zones acting as conduits for the upward migration of thermal fluid cannot be ruled out.</p></div>\",\"PeriodicalId\":6988,\"journal\":{\"name\":\"Acta Geophysica\",\"volume\":\"73 5\",\"pages\":\"4357 - 4377\"},\"PeriodicalIF\":2.1000,\"publicationDate\":\"2025-07-03\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://link.springer.com/content/pdf/10.1007/s11600-025-01636-z.pdf\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Acta Geophysica\",\"FirstCategoryId\":\"89\",\"ListUrlMain\":\"https://link.springer.com/article/10.1007/s11600-025-01636-z\",\"RegionNum\":4,\"RegionCategory\":\"地球科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"\",\"JCRName\":\"\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Acta Geophysica","FirstCategoryId":"89","ListUrlMain":"https://link.springer.com/article/10.1007/s11600-025-01636-z","RegionNum":4,"RegionCategory":"地球科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"","JCRName":"","Score":null,"Total":0}
引用次数: 0

摘要

印度的最西端是三个裂谷盆地的交界处,即Kachchh, Cambay和Narmada。坎贝裂谷盆地位于古吉拉特邦(印度西部),以存在几个地热带而闻名。Lasundra地热带位于Cambay盆地东侧,靠近东Cambay边缘断层。为了描述该地热带的特征,在研究区(Lasundra地热带)进行了遥感、水化学和大地电磁学的综合研究。为了破译和绘制与地热带相关的温度异常,使用了先进的星载热发射和反射辐射计和Landsat-8遥感数据。水样的水化学分析表明,矿化度、氟化物、TDS、电导率等指标异常(超标)。为了确定地热带的深度和范围,在地热带附近和周围进行了大地电磁法测量。沿两条样带共获得18个MT站点,站点间距约为1 ~ 2 km。从大地电磁数据的二维反演中,发现了~ 100 m厚的导电层(<; 30欧姆)。m)的沉积物在地表被观察到,其次是导电相对较低的德干圈闭层(30-150欧姆)。m),其中厚度向剖面的NW方向增加。结果表明,在~ 2.5 km深度和~ 4 km深度,沿两个断面分别存在高导电性带。这一导电带可以推断为与Lasundra地热带相关的可能储层。高电阻特性(>; 4000欧姆)m)根据电阻率值和周围地质情况可以代表花岗岩。这些阻性结构在东南方向的浅深度处遇到,并沿着横断面向西北方向延伸。除了裂缝的存在外,不能排除一些盲断裂带作为热流体向上运移通道的可能性。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Characterization of the geothermal zone by remote sensing, hydrochemical, and magnetotellurics data: a case study from Lasundra, Gujarat, India

Characterization of the geothermal zone by remote sensing, hydrochemical, and magnetotellurics data: a case study from Lasundra, Gujarat, India

The westernmost part of India is the junction of three rift basins, namely Kachchh, Cambay, and Narmada. The Cambay rift basin, located in the Gujarat state (west of India), is well known for the presence of several geothermal zones. The Lasundra geothermal zone is located on the eastern flank of the Cambay basin, in proximity to the East Cambay Marginal fault. To characterize this geothermal zone, a combined study of remote sensing, hydrochemical, and magnetotellurics is conducted in the study area (Lasundra geothermal zone). To decipher and map the temperature anomalies associated with the geothermal zone, Advanced Spaceborne Thermal Emission and Reflection Radiometer and Landsat-8 remote sensing data are used. The hydrochemical analysis of the water sample indicates the anomalous (excess) value of salinity, fluoride, TDS, conductivity, etc. To determine the depth and extension of the geothermal zone, an MT survey is carried out near and around the geothermal zone. A total of 18 MT sites with a close interstation spacing of ~ 1–2 km are acquired along two transects. From 2-D inversion of the MT data, a ~ 100-m-thick conductive layer (< 30 Ohm.m) of sediments has been seen at the surface followed by the relatively less conductive layer of Deccan trap (30–150 Ohm.m), where thickness increases towards the NW direction of the profile. The results show the presence of highly conductive zones at the depth of ~ 2.5 km and ~ 4 km, respectively, along two transects. This conductive zone may be inferred as the possible reservoir associated with the Lasundra geothermal zone. The highly resistive features (> 4000 Ohm.m) may represent Granite based on the resistivity values and surrounding geology. These resistive structures are encountered at shallow depths in the SE direction and extend deeper in the NW along the transects. Apart from the presence of fractures, the possibility of some blind fault zones acting as conduits for the upward migration of thermal fluid cannot be ruled out.
