秋季条件下浅水声脉冲响应波动与相干水声通信

IF 1.2 4区 物理与天体物理 Q4 ACOUSTICS
A. V. Shatravin
{"title":"秋季条件下浅水声脉冲响应波动与相干水声通信","authors":"A. V. Shatravin","doi":"10.1134/S1063771024602954","DOIUrl":null,"url":null,"abstract":"<div><p>The article presents the results of a full-scale experiment aimed at assessing the temporal variability of the impulse response of a hydroacoustic channel and efficiency of coherent underwater acoustic communications using bottom-mounted transmitters and receivers at frequencies of ~10 kHz on the Black Sea shelf in autumn. Three prominent maxima of variable amplitude were observed in the impulse response structure throughout the experiment (~36 h). The range of variability of the root-mean-square decoding error was ~11 dB; the bit error ratio varied from 0 to 0.10. A strong relationship was found between the values of decoding errors and the amplitude of the maximum arrival in the structure of the reference impulse response, corresponding to a group of rays with one reflection off the surface, as well as the coefficient of variation of high-frequency fluctuations of the amplitude of this arrival in the instantaneous estimate of the impulse response. Numerical modeling was used to confirm the hypothesis that in autumn conditions, characterized by the absence of a pronounced seasonal thermocline, the main hydrophysical cause of the variability of the amplitude of the main arrival, and, as a consequence, the effectiveness of underwater acoustic communications, consisted in an insignificant (fractions of a degree) change of temperature in the upper layer of sea water.</p></div>","PeriodicalId":455,"journal":{"name":"Acoustical Physics","volume":"71 2","pages":"223 - 239"},"PeriodicalIF":1.2000,"publicationDate":"2025-08-18","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Acoustic Impulse Response Fluctuations and Coherent Underwater Acoustic Communications in Shallow Water under Autumn Conditions\",\"authors\":\"A. V. Shatravin\",\"doi\":\"10.1134/S1063771024602954\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><p>The article presents the results of a full-scale experiment aimed at assessing the temporal variability of the impulse response of a hydroacoustic channel and efficiency of coherent underwater acoustic communications using bottom-mounted transmitters and receivers at frequencies of ~10 kHz on the Black Sea shelf in autumn. Three prominent maxima of variable amplitude were observed in the impulse response structure throughout the experiment (~36 h). The range of variability of the root-mean-square decoding error was ~11 dB; the bit error ratio varied from 0 to 0.10. A strong relationship was found between the values of decoding errors and the amplitude of the maximum arrival in the structure of the reference impulse response, corresponding to a group of rays with one reflection off the surface, as well as the coefficient of variation of high-frequency fluctuations of the amplitude of this arrival in the instantaneous estimate of the impulse response. Numerical modeling was used to confirm the hypothesis that in autumn conditions, characterized by the absence of a pronounced seasonal thermocline, the main hydrophysical cause of the variability of the amplitude of the main arrival, and, as a consequence, the effectiveness of underwater acoustic communications, consisted in an insignificant (fractions of a degree) change of temperature in the upper layer of sea water.</p></div>\",\"PeriodicalId\":455,\"journal\":{\"name\":\"Acoustical Physics\",\"volume\":\"71 2\",\"pages\":\"223 - 239\"},\"PeriodicalIF\":1.2000,\"publicationDate\":\"2025-08-18\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Acoustical Physics\",\"FirstCategoryId\":\"101\",\"ListUrlMain\":\"https://link.springer.com/article/10.1134/S1063771024602954\",\"RegionNum\":4,\"RegionCategory\":\"物理与天体物理\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q4\",\"JCRName\":\"ACOUSTICS\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Acoustical Physics","FirstCategoryId":"101","ListUrlMain":"https://link.springer.com/article/10.1134/S1063771024602954","RegionNum":4,"RegionCategory":"物理与天体物理","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q4","JCRName":"ACOUSTICS","Score":null,"Total":0}
引用次数: 0

摘要

本文介绍了一项全面实验的结果,旨在评估水声通道脉冲响应的时间变化,并在秋季在黑海大陆架上使用频率为~10 kHz的底部安装的发射机和接收机进行相干水声通信的效率。在整个实验期间(~36 h),脉冲响应结构中出现了三个显著的变幅最大值。译码误差均方根变异性范围为~11 dB;误码率范围为0 ~ 0.10。在解码误差值与参考脉冲响应结构中最大到达的振幅之间发现了很强的关系,对应于一组在表面上有一个反射的射线,以及在脉冲响应的瞬时估计中该到达的振幅的高频波动的变异系数。数值模拟被用来证实这样一个假设,即在秋季条件下,其特征是没有明显的季节性温跃层,主要的水物理原因是主要到达幅度的变化,因此,水声通信的有效性包括海水上层温度的微不足道(几分之一度)变化。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Acoustic Impulse Response Fluctuations and Coherent Underwater Acoustic Communications in Shallow Water under Autumn Conditions

Acoustic Impulse Response Fluctuations and Coherent Underwater Acoustic Communications in Shallow Water under Autumn Conditions

The article presents the results of a full-scale experiment aimed at assessing the temporal variability of the impulse response of a hydroacoustic channel and efficiency of coherent underwater acoustic communications using bottom-mounted transmitters and receivers at frequencies of ~10 kHz on the Black Sea shelf in autumn. Three prominent maxima of variable amplitude were observed in the impulse response structure throughout the experiment (~36 h). The range of variability of the root-mean-square decoding error was ~11 dB; the bit error ratio varied from 0 to 0.10. A strong relationship was found between the values of decoding errors and the amplitude of the maximum arrival in the structure of the reference impulse response, corresponding to a group of rays with one reflection off the surface, as well as the coefficient of variation of high-frequency fluctuations of the amplitude of this arrival in the instantaneous estimate of the impulse response. Numerical modeling was used to confirm the hypothesis that in autumn conditions, characterized by the absence of a pronounced seasonal thermocline, the main hydrophysical cause of the variability of the amplitude of the main arrival, and, as a consequence, the effectiveness of underwater acoustic communications, consisted in an insignificant (fractions of a degree) change of temperature in the upper layer of sea water.

求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
Acoustical Physics
Acoustical Physics 物理-声学
CiteScore
1.60
自引率
50.00%
发文量
58
审稿时长
3.5 months
期刊介绍: Acoustical Physics is an international peer reviewed journal published with the participation of the Russian Academy of Sciences. It covers theoretical and experimental aspects of basic and applied acoustics: classical problems of linear acoustics and wave theory; nonlinear acoustics; physical acoustics; ocean acoustics and hydroacoustics; atmospheric and aeroacoustics; acoustics of structurally inhomogeneous solids; geological acoustics; acoustical ecology, noise and vibration; chamber acoustics, musical acoustics; acoustic signals processing, computer simulations; acoustics of living systems, biomedical acoustics; physical principles of engineering acoustics. The journal publishes critical reviews, original articles, short communications, and letters to the editor. It covers theoretical and experimental aspects of basic and applied acoustics. The journal welcomes manuscripts from all countries in the English or Russian language.
×
