{"title":"高效、毒理学安全的ZnO(NP)@GO纳米复合材料在水介质中同时检测Cd 2 +、Hg 2 +、Pb 2 +和Zn 2 +","authors":"Melody Lalhruaitluangi , Lalruatkima Ralte , Diwakar Tiwari , Jinho Jung","doi":"10.1016/j.snr.2025.100373","DOIUrl":null,"url":null,"abstract":"<div><div>Miniaturised devices for trace, simultaneous and off-site detection are the need of the hour for protecting public health and the environment at large. Using sustainable and greener approach, the current study explores using <em>Acmella oleracea</em> extract to derive zinc oxide nanoparticles. Further, ZnO incorporates graphene oxide to obtain the nanocomposite material (ZnO(NP)@GO). The thin film electrode using the ZnO(NP)@GO efficiently detects potential heavy metal ions <em>viz.</em>, Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ individually and simultaneously at trace level concentrations. The thin film electrode using the ZnO(NP)@GO showed significantly enhanced electroactive surface area and reduced electron transfer resistance compared to the unmodified glassy carbon electrode. The calibration curve for detecting Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ shows the limits of detection of 0.026, 0.03, 0.010 and 0.020 µgL⁻¹, respectively, in their simultaneous detection. The ZnO(NP)@GO thin film electrode possesses good shelf life and stability for repeated detections of these heavy metal toxic ions. Furthermore, the thin film electrode detects simultaneously these ions at trace levels in the hospital effluent waters with real implications. Moreover, the acute toxicity of ZnO(NP)@GO towards <em>D. magna</em> shows an EC<sub>50</sub> value of 115.7 mgL⁻¹ after 48 hrs, proving the safety and environmental sustainability of the modified electrode.</div></div>","PeriodicalId":426,"journal":{"name":"Sensors and Actuators Reports","volume":"10 ","pages":"Article 100373"},"PeriodicalIF":7.6000,"publicationDate":"2025-08-11","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Highly efficient and toxicologically safe ZnO(NP)@GO nanocomposite in the simultaneous detection of Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ in aqueous medium\",\"authors\":\"Melody Lalhruaitluangi , Lalruatkima Ralte , Diwakar Tiwari , Jinho Jung\",\"doi\":\"10.1016/j.snr.2025.100373\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><div>Miniaturised devices for trace, simultaneous and off-site detection are the need of the hour for protecting public health and the environment at large. Using sustainable and greener approach, the current study explores using <em>Acmella oleracea</em> extract to derive zinc oxide nanoparticles. Further, ZnO incorporates graphene oxide to obtain the nanocomposite material (ZnO(NP)@GO). The thin film electrode using the ZnO(NP)@GO efficiently detects potential heavy metal ions <em>viz.</em>, Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ individually and simultaneously at trace level concentrations. The thin film electrode using the ZnO(NP)@GO showed significantly enhanced electroactive surface area and reduced electron transfer resistance compared to the unmodified glassy carbon electrode. The calibration curve for detecting Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ shows the limits of detection of 0.026, 0.03, 0.010 and 0.020 µgL⁻¹, respectively, in their simultaneous detection. The ZnO(NP)@GO thin film electrode possesses good shelf life and stability for repeated detections of these heavy metal toxic ions. Furthermore, the thin film electrode detects simultaneously these ions at trace levels in the hospital effluent waters with real implications. Moreover, the acute toxicity of ZnO(NP)@GO towards <em>D. magna</em> shows an EC<sub>50</sub> value of 115.7 mgL⁻¹ after 48 hrs, proving the safety and environmental sustainability of the modified electrode.</div></div>\",\"PeriodicalId\":426,\"journal\":{\"name\":\"Sensors and Actuators Reports\",\"volume\":\"10 \",\"pages\":\"Article 100373\"},\"PeriodicalIF\":7.6000,\"publicationDate\":\"2025-08-11\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Sensors and Actuators Reports\",\"FirstCategoryId\":\"1085\",\"ListUrlMain\":\"https://www.sciencedirect.com/science/article/pii/S2666053925000918\",\"RegionNum\":0,\"RegionCategory\":null,\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"BIOTECHNOLOGY & APPLIED MICROBIOLOGY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Sensors and Actuators Reports","FirstCategoryId":"1085","ListUrlMain":"https://www.sciencedirect.com/science/article/pii/S2666053925000918","RegionNum":0,"RegionCategory":null,"ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"BIOTECHNOLOGY & APPLIED MICROBIOLOGY","Score":null,"Total":0}
Highly efficient and toxicologically safe ZnO(NP)@GO nanocomposite in the simultaneous detection of Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ in aqueous medium
Miniaturised devices for trace, simultaneous and off-site detection are the need of the hour for protecting public health and the environment at large. Using sustainable and greener approach, the current study explores using Acmella oleracea extract to derive zinc oxide nanoparticles. Further, ZnO incorporates graphene oxide to obtain the nanocomposite material (ZnO(NP)@GO). The thin film electrode using the ZnO(NP)@GO efficiently detects potential heavy metal ions viz., Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ individually and simultaneously at trace level concentrations. The thin film electrode using the ZnO(NP)@GO showed significantly enhanced electroactive surface area and reduced electron transfer resistance compared to the unmodified glassy carbon electrode. The calibration curve for detecting Cd²⁺, Hg²⁺, Pb²⁺, and Zn²⁺ shows the limits of detection of 0.026, 0.03, 0.010 and 0.020 µgL⁻¹, respectively, in their simultaneous detection. The ZnO(NP)@GO thin film electrode possesses good shelf life and stability for repeated detections of these heavy metal toxic ions. Furthermore, the thin film electrode detects simultaneously these ions at trace levels in the hospital effluent waters with real implications. Moreover, the acute toxicity of ZnO(NP)@GO towards D. magna shows an EC50 value of 115.7 mgL⁻¹ after 48 hrs, proving the safety and environmental sustainability of the modified electrode.
