Lu Li , Yongming Chen , Mengting Wei , Mingyuan Yang , Jiexiang Ren , Richeng Lian , Bifan Guo , Birong Zeng , Yiting Xu , Conghui Yuan , Lizong Dai
{"title":"基于氟化双马来酰亚胺结构的高性能阻燃、紫外线屏蔽和低介电性能环氧复合材料的制备","authors":"Lu Li , Yongming Chen , Mengting Wei , Mingyuan Yang , Jiexiang Ren , Richeng Lian , Bifan Guo , Birong Zeng , Yiting Xu , Conghui Yuan , Lizong Dai","doi":"10.1016/j.reactfunctpolym.2025.106429","DOIUrl":null,"url":null,"abstract":"<div><div>Epoxy resin is widely used in modern industry, however, its inherent flammability and susceptibility to aging limit its applications. Based on molecular structure design, a fluorinated bismaleimide was first synthesized as the key intermediate. Subsequently, through the highly reactive addition between the P<img>H bond of 9,10-dihydro-9-oxa-10-phosphaphenanthrene-10-oxide (DOPO) and the maleimide double bonds, a novel epoxy modifier (BMFP) was successfully synthesized, which simultaneously exhibited both excellent ultraviolet (UV) shielding performance and better flame retardancy. The resulting modifier demonstrated good compatibility with epoxy resin. Notably, as the addition amount increased, the epoxy composites not only maintained excellent optical transparency but also exhibited better UV-shielding efficiency and flame retardancy. When the BMFP addition amount reached 8 wt%, the epoxy composite achieved a UL-94 V-0 rating with a limiting oxygen index (LOI) of 31 %. In addition, the peak heat release rate (pHRR) and total heat release (THR) were reduced by 21.1 % and 20.3 %, respectively, compared to neat EP. Additionally, the UV-shielding efficiency showed a 93.4 % enhancement relative to the unmodified epoxy matrix. In addition, the presence of -CF<sub>3</sub> in the modifier effectively improved the dielectric and surface hydrophobicity properties of the epoxy composites, reducing dielectric loss by 31.3 % and increasing the water contact angle from 97.2° to 108.2°.</div></div>","PeriodicalId":20916,"journal":{"name":"Reactive & Functional Polymers","volume":"216 ","pages":"Article 106429"},"PeriodicalIF":5.1000,"publicationDate":"2025-08-05","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Preparation of multifunctional epoxy composites with excellent flame retardancy, UV shielding and low dielectric properties based on fluorinated bismaleimide structure\",\"authors\":\"Lu Li , Yongming Chen , Mengting Wei , Mingyuan Yang , Jiexiang Ren , Richeng Lian , Bifan Guo , Birong Zeng , Yiting Xu , Conghui Yuan , Lizong Dai\",\"doi\":\"10.1016/j.reactfunctpolym.2025.106429\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><div>Epoxy resin is widely used in modern industry, however, its inherent flammability and susceptibility to aging limit its applications. Based on molecular structure design, a fluorinated bismaleimide was first synthesized as the key intermediate. Subsequently, through the highly reactive addition between the P<img>H bond of 9,10-dihydro-9-oxa-10-phosphaphenanthrene-10-oxide (DOPO) and the maleimide double bonds, a novel epoxy modifier (BMFP) was successfully synthesized, which simultaneously exhibited both excellent ultraviolet (UV) shielding performance and better flame retardancy. The resulting modifier demonstrated good compatibility with epoxy resin. Notably, as the addition amount increased, the epoxy composites not only maintained excellent optical transparency but also exhibited better UV-shielding efficiency and flame retardancy. When the BMFP addition amount reached 8 wt%, the epoxy composite achieved a UL-94 V-0 rating with a limiting oxygen index (LOI) of 31 %. In addition, the peak heat release rate (pHRR) and total heat release (THR) were reduced by 21.1 % and 20.3 %, respectively, compared to neat EP. Additionally, the UV-shielding efficiency showed a 93.4 % enhancement relative to the unmodified epoxy matrix. In addition, the presence of -CF<sub>3</sub> in the modifier effectively improved the dielectric and surface hydrophobicity properties of the epoxy composites, reducing dielectric loss by 31.3 % and increasing the water contact angle from 97.2° to 108.2°.</div></div>\",\"PeriodicalId\":20916,\"journal\":{\"name\":\"Reactive & Functional Polymers\",\"volume\":\"216 \",\"pages\":\"Article 106429\"},\"PeriodicalIF\":5.1000,\"publicationDate\":\"2025-08-05\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Reactive & Functional Polymers\",\"FirstCategoryId\":\"5\",\"ListUrlMain\":\"https://www.sciencedirect.com/science/article/pii/S1381514825002810\",\"RegionNum\":3,\"RegionCategory\":\"工程技术\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, APPLIED\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Reactive & Functional Polymers","FirstCategoryId":"5","ListUrlMain":"https://www.sciencedirect.com/science/article/pii/S1381514825002810","RegionNum":3,"RegionCategory":"工程技术","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, APPLIED","Score":null,"Total":0}
Preparation of multifunctional epoxy composites with excellent flame retardancy, UV shielding and low dielectric properties based on fluorinated bismaleimide structure
Epoxy resin is widely used in modern industry, however, its inherent flammability and susceptibility to aging limit its applications. Based on molecular structure design, a fluorinated bismaleimide was first synthesized as the key intermediate. Subsequently, through the highly reactive addition between the PH bond of 9,10-dihydro-9-oxa-10-phosphaphenanthrene-10-oxide (DOPO) and the maleimide double bonds, a novel epoxy modifier (BMFP) was successfully synthesized, which simultaneously exhibited both excellent ultraviolet (UV) shielding performance and better flame retardancy. The resulting modifier demonstrated good compatibility with epoxy resin. Notably, as the addition amount increased, the epoxy composites not only maintained excellent optical transparency but also exhibited better UV-shielding efficiency and flame retardancy. When the BMFP addition amount reached 8 wt%, the epoxy composite achieved a UL-94 V-0 rating with a limiting oxygen index (LOI) of 31 %. In addition, the peak heat release rate (pHRR) and total heat release (THR) were reduced by 21.1 % and 20.3 %, respectively, compared to neat EP. Additionally, the UV-shielding efficiency showed a 93.4 % enhancement relative to the unmodified epoxy matrix. In addition, the presence of -CF3 in the modifier effectively improved the dielectric and surface hydrophobicity properties of the epoxy composites, reducing dielectric loss by 31.3 % and increasing the water contact angle from 97.2° to 108.2°.
