纳米银粒子集成增强C/SiO2阳极快速充放电性能

IF 2 4区 化学 Q3 CHEMISTRY, MULTIDISCIPLINARY
Phat Tan Vu, Yen Nguyen Kim Chuong, Thu Anh Nguyen, Trang Thuy Thi Nguyen, Khuong Quoc Vo, Phung Loan My Le, Man Van Tran
{"title":"纳米银粒子集成增强C/SiO2阳极快速充放电性能","authors":"Phat Tan Vu,&nbsp;Yen Nguyen Kim Chuong,&nbsp;Thu Anh Nguyen,&nbsp;Trang Thuy Thi Nguyen,&nbsp;Khuong Quoc Vo,&nbsp;Phung Loan My Le,&nbsp;Man Van Tran","doi":"10.1002/slct.202502702","DOIUrl":null,"url":null,"abstract":"<p>Silicon-based anode materials are widely considered leading candidates for the next generation of lithium-ion batteries due to their exceptional theoretical capacity. Among them, C/SiO<sub>2</sub> derived from rice husks stands out for its environmental friendliness, abundant availability, and cost-effectiveness. However, its conductivity requires further enhancement to improve high-rate performance. To address this challenge, nano-silver, known for its superior electronic conductivity, is incorporated into the anode. The addition of silver nanoparticles increases the density of charge carriers, thereby enhancing conductivity. Moreover, these nanoparticles form a conductive network within the C/SiO<sub>2</sub> structure, reducing material resistance and ensuring even dispersion. In this study, a silver nanosolution (∼1000 ppm) was synthesized using polyvinylpyrrolidone (PVP) as a surface stabilizer and sodium borohydride (NaBH<sub>4</sub>) as a reducing agent. Various silver concentrations were introduced and analyzed to determine the optimal ratio for the C/SiO<sub>2</sub> anode. The particle size ranges from 20 to 50 nm, with an average diameter of 36 ± 4 nm. The X-ray diffraction of C/SiO<sub>2</sub>/Ag electrodes clearly shows a peak at 23–24° (characteristic of SiO<sub>2</sub>, a peak at 43° featured of carbon and another peak at 38° corresponding to (111) plane of silver. The outstanding conductive agent of silver nanoparticles could be applied for a high-performance lithium-ion battery C/SiO<sub>2</sub> anode. The C/SiO<sub>2</sub>/Ag electrodes exhibit an impressive high rate performance (∼70 mAh g<sup>−1</sup> at 2 A g<sup>−1</sup>). Furthermore, this research highlights the potential of nanotechnology in advancing rechargeable battery performance.</p>","PeriodicalId":146,"journal":{"name":"ChemistrySelect","volume":"10 31","pages":""},"PeriodicalIF":2.0000,"publicationDate":"2025-08-11","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Enhancing Fast Charge–Discharge Behavior of C/SiO2 Anodes by Silver Nanoparticle Integration Through a Facile Fabrication Method\",\"authors\":\"Phat Tan Vu,&nbsp;Yen Nguyen Kim Chuong,&nbsp;Thu Anh Nguyen,&nbsp;Trang Thuy Thi Nguyen,&nbsp;Khuong Quoc Vo,&nbsp;Phung Loan My Le,&nbsp;Man Van Tran\",\"doi\":\"10.1002/slct.202502702\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p>Silicon-based anode materials are widely considered leading candidates for the next generation of lithium-ion batteries due to their exceptional theoretical capacity. Among them, C/SiO<sub>2</sub> derived from rice husks stands out for its environmental friendliness, abundant availability, and cost-effectiveness. However, its conductivity requires further enhancement to improve high-rate performance. To address this challenge, nano-silver, known for its superior electronic conductivity, is incorporated into the anode. The addition of silver nanoparticles increases the density of charge carriers, thereby enhancing conductivity. Moreover, these nanoparticles form a conductive network within the C/SiO<sub>2</sub> structure, reducing material resistance and ensuring even dispersion. In this study, a silver nanosolution (∼1000 ppm) was synthesized using polyvinylpyrrolidone (PVP) as a surface stabilizer and sodium borohydride (NaBH<sub>4</sub>) as a reducing agent. Various silver concentrations were introduced and analyzed to determine the optimal ratio for the C/SiO<sub>2</sub> anode. The particle size ranges from 20 to 50 nm, with an average diameter of 36 ± 4 nm. The X-ray diffraction of C/SiO<sub>2</sub>/Ag electrodes clearly shows a peak at 23–24° (characteristic of SiO<sub>2</sub>, a peak at 43° featured of carbon and another peak at 38° corresponding to (111) plane of silver. The outstanding conductive agent of silver nanoparticles could be applied for a high-performance lithium-ion battery C/SiO<sub>2</sub> anode. The C/SiO<sub>2</sub>/Ag electrodes exhibit an impressive high rate performance (∼70 mAh g<sup>−1</sup> at 2 A g<sup>−1</sup>). Furthermore, this research highlights the potential of nanotechnology in advancing rechargeable battery performance.</p>\",\"PeriodicalId\":146,\"journal\":{\"name\":\"ChemistrySelect\",\"volume\":\"10 31\",\"pages\":\"\"},\"PeriodicalIF\":2.0000,\"publicationDate\":\"2025-08-11\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"ChemistrySelect\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://chemistry-europe.onlinelibrary.wiley.com/doi/10.1002/slct.202502702\",\"RegionNum\":4,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q3\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"ChemistrySelect","FirstCategoryId":"92","ListUrlMain":"https://chemistry-europe.onlinelibrary.wiley.com/doi/10.1002/slct.202502702","RegionNum":4,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q3","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

硅基负极材料由于其卓越的理论容量被广泛认为是下一代锂离子电池的主要候选者。其中,从稻壳中提取的C/SiO2以其环保性、可获得性和成本效益突出。然而,它的导电性需要进一步增强以提高高速率性能。为了解决这一挑战,纳米银,以其优越的电子导电性而闻名,被纳入阳极。银纳米粒子的加入增加了载流子的密度,从而提高了电导率。此外,这些纳米颗粒在C/SiO2结构内形成导电网络,降低了材料电阻并确保均匀分散。在这项研究中,以聚乙烯吡咯烷酮(PVP)为表面稳定剂,硼氢化钠(NaBH4)为还原剂,合成了一种银纳米溶液(~ 1000 ppm)。介绍并分析了不同浓度的银,以确定C/SiO2阳极的最佳配比。粒径范围为20 ~ 50 nm,平均粒径为36±4 nm。C/SiO2/Ag电极的x射线衍射清晰地显示出23-24°峰(SiO2的特征)、43°峰(碳的特征)和38°峰(银的(111)面)。纳米银导电性能优异,可用于高性能锂离子电池C/SiO2阳极。C/SiO2/Ag电极表现出令人印象深刻的高倍率性能(在2 Ag−1时约70 mAh g−1)。此外,这项研究强调了纳米技术在提高可充电电池性能方面的潜力。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Enhancing Fast Charge–Discharge Behavior of C/SiO2 Anodes by Silver Nanoparticle Integration Through a Facile Fabrication Method

Enhancing Fast Charge–Discharge Behavior of C/SiO2 Anodes by Silver Nanoparticle Integration Through a Facile Fabrication Method

Enhancing Fast Charge–Discharge Behavior of C/SiO2 Anodes by Silver Nanoparticle Integration Through a Facile Fabrication Method

Enhancing Fast Charge–Discharge Behavior of C/SiO2 Anodes by Silver Nanoparticle Integration Through a Facile Fabrication Method

Enhancing Fast Charge–Discharge Behavior of C/SiO2 Anodes by Silver Nanoparticle Integration Through a Facile Fabrication Method

Silicon-based anode materials are widely considered leading candidates for the next generation of lithium-ion batteries due to their exceptional theoretical capacity. Among them, C/SiO2 derived from rice husks stands out for its environmental friendliness, abundant availability, and cost-effectiveness. However, its conductivity requires further enhancement to improve high-rate performance. To address this challenge, nano-silver, known for its superior electronic conductivity, is incorporated into the anode. The addition of silver nanoparticles increases the density of charge carriers, thereby enhancing conductivity. Moreover, these nanoparticles form a conductive network within the C/SiO2 structure, reducing material resistance and ensuring even dispersion. In this study, a silver nanosolution (∼1000 ppm) was synthesized using polyvinylpyrrolidone (PVP) as a surface stabilizer and sodium borohydride (NaBH4) as a reducing agent. Various silver concentrations were introduced and analyzed to determine the optimal ratio for the C/SiO2 anode. The particle size ranges from 20 to 50 nm, with an average diameter of 36 ± 4 nm. The X-ray diffraction of C/SiO2/Ag electrodes clearly shows a peak at 23–24° (characteristic of SiO2, a peak at 43° featured of carbon and another peak at 38° corresponding to (111) plane of silver. The outstanding conductive agent of silver nanoparticles could be applied for a high-performance lithium-ion battery C/SiO2 anode. The C/SiO2/Ag electrodes exhibit an impressive high rate performance (∼70 mAh g−1 at 2 A g−1). Furthermore, this research highlights the potential of nanotechnology in advancing rechargeable battery performance.
