Sn-Pb底部亚电池的晶格稳定和应变均匀化使全钙钛矿串联太阳能电池稳定

IF 15.7 1区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES
Yang Bai, Yuanyuan Meng, Ming Yang, Ruijia Tian, Jingnan Wang, Boxin Jiao, Haibin Pan, Jiangwei Gao, Yaohua Wang, Kexuan Sun, Shujing Zhou, Xiaoyi Lu, Zhenhua Song, Chang Liu, Ziyi Ge
{"title":"Sn-Pb底部亚电池的晶格稳定和应变均匀化使全钙钛矿串联太阳能电池稳定","authors":"Yang Bai, Yuanyuan Meng, Ming Yang, Ruijia Tian, Jingnan Wang, Boxin Jiao, Haibin Pan, Jiangwei Gao, Yaohua Wang, Kexuan Sun, Shujing Zhou, Xiaoyi Lu, Zhenhua Song, Chang Liu, Ziyi Ge","doi":"10.1038/s41467-025-62661-6","DOIUrl":null,"url":null,"abstract":"<p>All-perovskite tandem solar cells (PTSCs) offer a promising approach to surpass the Shockley-Queisser (SQ) limit, driven by efficiently reducing thermalization and transmission losses. However, the efficiency and stability of the narrow-bandgap (NBG) subcells, which are essential for PTSC performance, remain severely constrained by challenges such as lattice instability, strain accumulation and halide migration under illumination. This study introduces a rigid sulfonate-based molecule, sodium naphthalene-1,3,6-trisulfonate (NTS), into tin-lead (Sn-Pb) perovskites, where it strengthens the Sn-I bond through Sn-trisulfonate coordination and reduces light-induced dynamic lattice distortions via the rigid NTS backbone. These molecular interactions alleviate strain heterogeneity within the lattice and homogenize the Sn-Pb compositional gradient, thereby enhancing the structural integrity and long-term stability of Sn-Pb perovskites under operational conditions. As a result, Sn-Pb single-junction perovskite solar cells (PSCs) achieve a power conversion efficiency (PCE) of 23.2%. When integrated into a tandem configuration, the device attains an impressive PCE of 29.6% (certified PCE of 29.2%, one of the highest certified efficiencies to date), with 93.1% of the initial efficiency retained after 700 h of continuous operation. By stabilizing the lattice structure, this work lays a solid foundation for achieving both high efficiency and long-term durability in next-generation perovskite photovoltaics.</p>","PeriodicalId":19066,"journal":{"name":"Nature Communications","volume":"7 1","pages":""},"PeriodicalIF":15.7000,"publicationDate":"2025-08-09","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Lattice stabilization and strain homogenization in Sn-Pb bottom subcells enable stable all-perovskite tandems solar cells\",\"authors\":\"Yang Bai, Yuanyuan Meng, Ming Yang, Ruijia Tian, Jingnan Wang, Boxin Jiao, Haibin Pan, Jiangwei Gao, Yaohua Wang, Kexuan Sun, Shujing Zhou, Xiaoyi Lu, Zhenhua Song, Chang Liu, Ziyi Ge\",\"doi\":\"10.1038/s41467-025-62661-6\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p>All-perovskite tandem solar cells (PTSCs) offer a promising approach to surpass the Shockley-Queisser (SQ) limit, driven by efficiently reducing thermalization and transmission losses. However, the efficiency and stability of the narrow-bandgap (NBG) subcells, which are essential for PTSC performance, remain severely constrained by challenges such as lattice instability, strain accumulation and halide migration under illumination. This study introduces a rigid sulfonate-based molecule, sodium naphthalene-1,3,6-trisulfonate (NTS), into tin-lead (Sn-Pb) perovskites, where it strengthens the Sn-I bond through Sn-trisulfonate coordination and reduces light-induced dynamic lattice distortions via the rigid NTS backbone. These molecular interactions alleviate strain heterogeneity within the lattice and homogenize the Sn-Pb compositional gradient, thereby enhancing the structural integrity and long-term stability of Sn-Pb perovskites under operational conditions. As a result, Sn-Pb single-junction perovskite solar cells (PSCs) achieve a power conversion efficiency (PCE) of 23.2%. When integrated into a tandem configuration, the device attains an impressive PCE of 29.6% (certified PCE of 29.2%, one of the highest certified efficiencies to date), with 93.1% of the initial efficiency retained after 700 h of continuous operation. By stabilizing the lattice structure, this work lays a solid foundation for achieving both high efficiency and long-term durability in next-generation perovskite photovoltaics.</p>\",\"PeriodicalId\":19066,\"journal\":{\"name\":\"Nature Communications\",\"volume\":\"7 1\",\"pages\":\"\"},\"PeriodicalIF\":15.7000,\"publicationDate\":\"2025-08-09\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Nature Communications\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1038/s41467-025-62661-6\",\"RegionNum\":1,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Nature Communications","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1038/s41467-025-62661-6","RegionNum":1,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

全钙钛矿串联太阳能电池(PTSCs)提供了一种超越Shockley-Queisser (SQ)极限的有前途的方法,有效地减少了热化和传输损耗。然而,对于PTSC性能至关重要的窄带隙(NBG)亚电池的效率和稳定性仍然受到晶格不稳定性、应变积累和光照下卤化物迁移等挑战的严重制约。本研究将刚性磺酸基分子萘-1,3,6-三磺酸钠(NTS)引入锡铅(Sn-Pb)钙钛矿中,通过sn -三磺酸盐配位加强Sn-I键,并通过刚性NTS主链减少光诱导的动态晶格畸变。这些分子相互作用减轻了晶格内的应变不均一性,使Sn-Pb组成梯度均匀化,从而提高了Sn-Pb钙钛矿在操作条件下的结构完整性和长期稳定性。结果表明,Sn-Pb单结钙钛矿太阳能电池(PSCs)的功率转换效率(PCE)为23.2%。当集成到串联配置中时,该设备的PCE达到了令人印象深刻的29.6%(认证的PCE为29.2%,是迄今为止最高的认证效率之一),连续运行700小时后仍保持93.1%的初始效率。通过稳定晶格结构,这项工作为实现下一代钙钛矿光伏电池的高效率和长期耐用性奠定了坚实的基础。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Lattice stabilization and strain homogenization in Sn-Pb bottom subcells enable stable all-perovskite tandems solar cells

Lattice stabilization and strain homogenization in Sn-Pb bottom subcells enable stable all-perovskite tandems solar cells

All-perovskite tandem solar cells (PTSCs) offer a promising approach to surpass the Shockley-Queisser (SQ) limit, driven by efficiently reducing thermalization and transmission losses. However, the efficiency and stability of the narrow-bandgap (NBG) subcells, which are essential for PTSC performance, remain severely constrained by challenges such as lattice instability, strain accumulation and halide migration under illumination. This study introduces a rigid sulfonate-based molecule, sodium naphthalene-1,3,6-trisulfonate (NTS), into tin-lead (Sn-Pb) perovskites, where it strengthens the Sn-I bond through Sn-trisulfonate coordination and reduces light-induced dynamic lattice distortions via the rigid NTS backbone. These molecular interactions alleviate strain heterogeneity within the lattice and homogenize the Sn-Pb compositional gradient, thereby enhancing the structural integrity and long-term stability of Sn-Pb perovskites under operational conditions. As a result, Sn-Pb single-junction perovskite solar cells (PSCs) achieve a power conversion efficiency (PCE) of 23.2%. When integrated into a tandem configuration, the device attains an impressive PCE of 29.6% (certified PCE of 29.2%, one of the highest certified efficiencies to date), with 93.1% of the initial efficiency retained after 700 h of continuous operation. By stabilizing the lattice structure, this work lays a solid foundation for achieving both high efficiency and long-term durability in next-generation perovskite photovoltaics.

求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
Nature Communications
Nature Communications Biological Science Disciplines-
CiteScore
24.90
自引率
2.40%
发文量
6928
审稿时长
3.7 months
期刊介绍: Nature Communications, an open-access journal, publishes high-quality research spanning all areas of the natural sciences. Papers featured in the journal showcase significant advances relevant to specialists in each respective field. With a 2-year impact factor of 16.6 (2022) and a median time of 8 days from submission to the first editorial decision, Nature Communications is committed to rapid dissemination of research findings. As a multidisciplinary journal, it welcomes contributions from biological, health, physical, chemical, Earth, social, mathematical, applied, and engineering sciences, aiming to highlight important breakthroughs within each domain.
×
