通过双动力机制平衡环氧树脂及其复合材料的力学性能和修复能力

IF 4.5 2区 化学 Q2 POLYMER SCIENCE
Lei Wang, Mushan Yuan, Yisen Huang, Yang Chen, Shengtai Zhou, Huawei Zou, Yinfu Luo, Zhengguang Heng, Mei Liang
{"title":"通过双动力机制平衡环氧树脂及其复合材料的力学性能和修复能力","authors":"Lei Wang, Mushan Yuan, Yisen Huang, Yang Chen, Shengtai Zhou, Huawei Zou, Yinfu Luo, Zhengguang Heng, Mei Liang","doi":"10.1016/j.polymer.2025.128881","DOIUrl":null,"url":null,"abstract":"Introducing dynamic covalent bonds offers a promising strategy to enable the reprocessing and repair of epoxy resins and their composites, with efficacy tied to the type and extent of dynamic exchange. Although combining multiple mechanisms has received increasing attention, in most studies, these multiple mechanisms are independent of each other, lacking more efficient synergistic effects, and often exhibit worse mechanical performance along with elevated reprocessing temperatures. To overcome these challenges, we developed an epoxy vitrimer and its composites incorporating synergistic dual dynamic exchange mechanisms. This was achieved by combining an imine-containing epoxy resin with a curing agent featuring vinylogous urethane (VU) dynamic bonds, which is designed with excess amine groups to undergo dynamic exchange with both mechanisms. The resulting samples exhibit outstanding mechanical properties, including a tensile strength of 100.32 MPa, a glass transition temperature (T<sub>g</sub>) of 125.07°C, and an elongation of 6.77%. Reprocessing near T<sub>g</sub> allows tensile strength and elongation at break to recover to 75.54% and 52.14% of their original values, respectively, after two cycles. These epoxy vitrimers and composites optimally balance high mechanical strength and structural reversibility through dual dynamic exchange mechanisms. Additionally, this design enables rapid, non-destructive carbon fiber recovery at room temperature and effective shear repair of carbon fiber layers, offering insights for designing longer-lasting epoxy materials and repair strategies.","PeriodicalId":405,"journal":{"name":"Polymer","volume":"40 1","pages":""},"PeriodicalIF":4.5000,"publicationDate":"2025-08-06","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Balancing Mechanical Performance and Repair Ability of Epoxy and Its Composites via Dual Dynamic Mechanism\",\"authors\":\"Lei Wang, Mushan Yuan, Yisen Huang, Yang Chen, Shengtai Zhou, Huawei Zou, Yinfu Luo, Zhengguang Heng, Mei Liang\",\"doi\":\"10.1016/j.polymer.2025.128881\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"Introducing dynamic covalent bonds offers a promising strategy to enable the reprocessing and repair of epoxy resins and their composites, with efficacy tied to the type and extent of dynamic exchange. Although combining multiple mechanisms has received increasing attention, in most studies, these multiple mechanisms are independent of each other, lacking more efficient synergistic effects, and often exhibit worse mechanical performance along with elevated reprocessing temperatures. To overcome these challenges, we developed an epoxy vitrimer and its composites incorporating synergistic dual dynamic exchange mechanisms. This was achieved by combining an imine-containing epoxy resin with a curing agent featuring vinylogous urethane (VU) dynamic bonds, which is designed with excess amine groups to undergo dynamic exchange with both mechanisms. The resulting samples exhibit outstanding mechanical properties, including a tensile strength of 100.32 MPa, a glass transition temperature (T<sub>g</sub>) of 125.07°C, and an elongation of 6.77%. Reprocessing near T<sub>g</sub> allows tensile strength and elongation at break to recover to 75.54% and 52.14% of their original values, respectively, after two cycles. These epoxy vitrimers and composites optimally balance high mechanical strength and structural reversibility through dual dynamic exchange mechanisms. Additionally, this design enables rapid, non-destructive carbon fiber recovery at room temperature and effective shear repair of carbon fiber layers, offering insights for designing longer-lasting epoxy materials and repair strategies.\",\"PeriodicalId\":405,\"journal\":{\"name\":\"Polymer\",\"volume\":\"40 1\",\"pages\":\"\"},\"PeriodicalIF\":4.5000,\"publicationDate\":\"2025-08-06\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Polymer\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://doi.org/10.1016/j.polymer.2025.128881\",\"RegionNum\":2,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"POLYMER SCIENCE\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Polymer","FirstCategoryId":"92","ListUrlMain":"https://doi.org/10.1016/j.polymer.2025.128881","RegionNum":2,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"POLYMER SCIENCE","Score":null,"Total":0}
引用次数: 0

摘要

引入动态共价键为环氧树脂及其复合材料的再加工和修复提供了一种有前途的策略,其效果与动态交换的类型和程度有关。虽然多机制组合越来越受到关注,但在大多数研究中,这些多机制相互独立,缺乏更有效的协同作用,并且随着再加工温度的升高,力学性能往往会变差。为了克服这些挑战,我们开发了一种具有协同双动态交换机制的环氧玻璃体及其复合材料。这是通过将一种含亚胺的环氧树脂与一种具有乙烯基氨基甲酸乙酯(VU)动态键的固化剂结合而实现的,该固化剂具有过量的胺基,可以在两种机制下进行动态交换。所得样品具有优异的力学性能,包括抗拉强度为100.32 MPa,玻璃化转变温度(Tg)为125.07℃,伸长率为6.77%。在Tg附近再处理,两次循环后,拉伸强度和断裂伸长率分别恢复到原始值的75.54%和52.14%。这些环氧树脂和复合材料通过双重动态交换机制,最佳地平衡了高机械强度和结构可逆性。此外,这种设计能够在室温下快速、无损地恢复碳纤维,并对碳纤维层进行有效的剪切修复,为设计更持久的环氧树脂材料和修复策略提供了见解。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Balancing Mechanical Performance and Repair Ability of Epoxy and Its Composites via Dual Dynamic Mechanism

Balancing Mechanical Performance and Repair Ability of Epoxy and Its Composites via Dual Dynamic Mechanism
Introducing dynamic covalent bonds offers a promising strategy to enable the reprocessing and repair of epoxy resins and their composites, with efficacy tied to the type and extent of dynamic exchange. Although combining multiple mechanisms has received increasing attention, in most studies, these multiple mechanisms are independent of each other, lacking more efficient synergistic effects, and often exhibit worse mechanical performance along with elevated reprocessing temperatures. To overcome these challenges, we developed an epoxy vitrimer and its composites incorporating synergistic dual dynamic exchange mechanisms. This was achieved by combining an imine-containing epoxy resin with a curing agent featuring vinylogous urethane (VU) dynamic bonds, which is designed with excess amine groups to undergo dynamic exchange with both mechanisms. The resulting samples exhibit outstanding mechanical properties, including a tensile strength of 100.32 MPa, a glass transition temperature (Tg) of 125.07°C, and an elongation of 6.77%. Reprocessing near Tg allows tensile strength and elongation at break to recover to 75.54% and 52.14% of their original values, respectively, after two cycles. These epoxy vitrimers and composites optimally balance high mechanical strength and structural reversibility through dual dynamic exchange mechanisms. Additionally, this design enables rapid, non-destructive carbon fiber recovery at room temperature and effective shear repair of carbon fiber layers, offering insights for designing longer-lasting epoxy materials and repair strategies.
