MCM-22沸石的生长机理及其在异戊烯低聚反应中的应用

IF 4.7 3区材料科学 Q1 CHEMISTRY, APPLIED

Microporous and Mesoporous Materials Pub Date : 2025-07-31 DOI:10.1016/j.micromeso.2025.113789

Zijian Wang , Shuting Li , Jiashuo Zheng , Jiahan Li , Yanbing Tong , Ming Ke , Zhaozheng Song

{"title":"MCM-22沸石的生长机理及其在异戊烯低聚反应中的应用","authors":"Zijian Wang , Shuting Li , Jiashuo Zheng , Jiahan Li , Yanbing Tong , Ming Ke , Zhaozheng Song","doi":"10.1016/j.micromeso.2025.113789","DOIUrl":null,"url":null,"abstract":"<div><div>MCM-22 zeolite synthesized by utilizing the hexamethyleneimine as the organic structure directing agent has a wide range of applications. For the growth mechanism of the typical sample, on the macro level, XRD, FT-IR, and SEM are used to confirm the epitaxial growth of the intercalation structure. On the micro level, eight different T sites of the zeolite are completely distinguished as well as the guidance of hexamethyleneimine on T<sub>1</sub>, T<sub>2</sub>, T<sub>3</sub> and T<sub>5</sub> sites has been demonstrated through DFT calculation and solid-state nuclear magnetic resonance. A series of MCM-22 zeolites display the good catalytic stability and dimerization selectivity. The synergy of hexamethyleneimine and amphiphilic organosilane optimizates the mesopore and acidity of the sample effectively, which makes the selectivity and yield of dimerization product exceed 94.8 % and 85.0 % after 12 h respectively. At the same time, the carbon deposition decreases from 3.38 % to 3.13 %. This work provides a theoretical basis for the growth mechanism and application in olefin oligomerization of MCM-22 zeolite.</div></div>","PeriodicalId":392,"journal":{"name":"Microporous and Mesoporous Materials","volume":"398 ","pages":"Article 113789"},"PeriodicalIF":4.7000,"publicationDate":"2025-07-31","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"The growth mechanism and application in isoamylene oligomerization of MCM-22 zeolite\",\"authors\":\"Zijian Wang , Shuting Li , Jiashuo Zheng , Jiahan Li , Yanbing Tong , Ming Ke , Zhaozheng Song\",\"doi\":\"10.1016/j.micromeso.2025.113789\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><div>MCM-22 zeolite synthesized by utilizing the hexamethyleneimine as the organic structure directing agent has a wide range of applications. For the growth mechanism of the typical sample, on the macro level, XRD, FT-IR, and SEM are used to confirm the epitaxial growth of the intercalation structure. On the micro level, eight different T sites of the zeolite are completely distinguished as well as the guidance of hexamethyleneimine on T<sub>1</sub>, T<sub>2</sub>, T<sub>3</sub> and T<sub>5</sub> sites has been demonstrated through DFT calculation and solid-state nuclear magnetic resonance. A series of MCM-22 zeolites display the good catalytic stability and dimerization selectivity. The synergy of hexamethyleneimine and amphiphilic organosilane optimizates the mesopore and acidity of the sample effectively, which makes the selectivity and yield of dimerization product exceed 94.8 % and 85.0 % after 12 h respectively. At the same time, the carbon deposition decreases from 3.38 % to 3.13 %. This work provides a theoretical basis for the growth mechanism and application in olefin oligomerization of MCM-22 zeolite.</div></div>\",\"PeriodicalId\":392,\"journal\":{\"name\":\"Microporous and Mesoporous Materials\",\"volume\":\"398 \",\"pages\":\"Article 113789\"},\"PeriodicalIF\":4.7000,\"publicationDate\":\"2025-07-31\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Microporous and Mesoporous Materials\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://www.sciencedirect.com/science/article/pii/S138718112500304X\",\"RegionNum\":3,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, APPLIED\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Microporous and Mesoporous Materials","FirstCategoryId":"88","ListUrlMain":"https://www.sciencedirect.com/science/article/pii/S138718112500304X","RegionNum":3,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, APPLIED","Score":null,"Total":0}

引用次数: 0

摘要

以六亚胺为有机结构导向剂合成的MCM-22分子筛具有广泛的应用前景。对于典型样品的生长机理，在宏观层面上，通过XRD、FT-IR、SEM等手段证实了插层结构的外延生长。在微观层面上，完全区分了沸石的8个不同的T位，并通过DFT计算和固态核磁共振证明了六亚胺对T1、T2、T3和T5位的引导作用。一系列的MCM-22分子筛表现出良好的催化稳定性和二聚化选择性。六亚亚胺和两亲性有机硅烷的协同作用有效地优化了样品的介孔和酸度，使二聚化产物的选择性和收率分别超过94.8%和85.0%。同时，碳沉积由3.38%降低到3.13%。本研究为MCM-22分子筛的生长机理及其在烯烃低聚反应中的应用提供了理论依据。

本文章由计算机程序翻译，如有差异，请以英文原文为准。

The growth mechanism and application in isoamylene oligomerization of MCM-22 zeolite

查看原文本刊更多论文

The growth mechanism and application in isoamylene oligomerization of MCM-22 zeolite

MCM-22 zeolite synthesized by utilizing the hexamethyleneimine as the organic structure directing agent has a wide range of applications. For the growth mechanism of the typical sample, on the macro level, XRD, FT-IR, and SEM are used to confirm the epitaxial growth of the intercalation structure. On the micro level, eight different T sites of the zeolite are completely distinguished as well as the guidance of hexamethyleneimine on T₁, T₂, T₃ and T₅ sites has been demonstrated through DFT calculation and solid-state nuclear magnetic resonance. A series of MCM-22 zeolites display the good catalytic stability and dimerization selectivity. The synergy of hexamethyleneimine and amphiphilic organosilane optimizates the mesopore and acidity of the sample effectively, which makes the selectivity and yield of dimerization product exceed 94.8 % and 85.0 % after 12 h respectively. At the same time, the carbon deposition decreases from 3.38 % to 3.13 %. This work provides a theoretical basis for the growth mechanism and application in olefin oligomerization of MCM-22 zeolite.
