几何翘曲补偿数值方法的比较

IF 1.8 4区 工程技术 Q3 COMPUTER SCIENCE, INTERDISCIPLINARY APPLICATIONS
Steffen Tillmann, Stefan Basermann, Stefanie Elgeti
{"title":"几何翘曲补偿数值方法的比较","authors":"Steffen Tillmann,&nbsp;Stefan Basermann,&nbsp;Stefanie Elgeti","doi":"10.1002/fld.5404","DOIUrl":null,"url":null,"abstract":"<p>In injection molding processes, shrinkage and warpage cause deviations in the size and shape of produced parts compared to the cavity shape. While shrinkage is due to the change of material density during solidification, warpage is caused by uneven cooling and internal stresses within the part. One approach to mitigate these effects is by adjusting the cavity shape to anticipate the deformation. While finding the optimal cavity shape is often experience-based in practice, numerical design optimization can greatly assist in this process. In this study, we evaluate various numerical algorithms from existing literature to identify the optimal cavity shape. Each method is briefly outlined regarding how it adapts the geometry, and we discuss their respective strengths and weaknesses for different scenarios. We conduct comparisons using 3D geometries of varying complexity. Our findings demonstrate that, for geometric warpage compensation, the node-based reverse geometry method yields the least warpage and is computationally cost-effective. Furthermore, it is straightforward to implement and consistently performs well across different geometries.</p>","PeriodicalId":50348,"journal":{"name":"International Journal for Numerical Methods in Fluids","volume":"97 9","pages":"1280-1288"},"PeriodicalIF":1.8000,"publicationDate":"2025-05-28","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://onlinelibrary.wiley.com/doi/epdf/10.1002/fld.5404","citationCount":"0","resultStr":"{\"title\":\"Comparison of Numerical Methods for Geometric Warpage Compensation\",\"authors\":\"Steffen Tillmann,&nbsp;Stefan Basermann,&nbsp;Stefanie Elgeti\",\"doi\":\"10.1002/fld.5404\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p>In injection molding processes, shrinkage and warpage cause deviations in the size and shape of produced parts compared to the cavity shape. While shrinkage is due to the change of material density during solidification, warpage is caused by uneven cooling and internal stresses within the part. One approach to mitigate these effects is by adjusting the cavity shape to anticipate the deformation. While finding the optimal cavity shape is often experience-based in practice, numerical design optimization can greatly assist in this process. In this study, we evaluate various numerical algorithms from existing literature to identify the optimal cavity shape. Each method is briefly outlined regarding how it adapts the geometry, and we discuss their respective strengths and weaknesses for different scenarios. We conduct comparisons using 3D geometries of varying complexity. Our findings demonstrate that, for geometric warpage compensation, the node-based reverse geometry method yields the least warpage and is computationally cost-effective. Furthermore, it is straightforward to implement and consistently performs well across different geometries.</p>\",\"PeriodicalId\":50348,\"journal\":{\"name\":\"International Journal for Numerical Methods in Fluids\",\"volume\":\"97 9\",\"pages\":\"1280-1288\"},\"PeriodicalIF\":1.8000,\"publicationDate\":\"2025-05-28\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://onlinelibrary.wiley.com/doi/epdf/10.1002/fld.5404\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"International Journal for Numerical Methods in Fluids\",\"FirstCategoryId\":\"5\",\"ListUrlMain\":\"https://onlinelibrary.wiley.com/doi/10.1002/fld.5404\",\"RegionNum\":4,\"RegionCategory\":\"工程技术\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q3\",\"JCRName\":\"COMPUTER SCIENCE, INTERDISCIPLINARY APPLICATIONS\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"International Journal for Numerical Methods in Fluids","FirstCategoryId":"5","ListUrlMain":"https://onlinelibrary.wiley.com/doi/10.1002/fld.5404","RegionNum":4,"RegionCategory":"工程技术","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q3","JCRName":"COMPUTER SCIENCE, INTERDISCIPLINARY APPLICATIONS","Score":null,"Total":0}
引用次数: 0

摘要

在注射成型过程中,收缩和翘曲会导致所生产零件的尺寸和形状与型腔形状相偏差。收缩是由于凝固过程中材料密度的变化,而翘曲是由于冷却不均匀和零件内部应力引起的。减轻这些影响的一种方法是通过调整空腔形状来预测变形。虽然在实践中寻找最佳的空腔形状通常是基于经验的,但数值设计优化可以极大地帮助这一过程。在本研究中,我们评估了现有文献中的各种数值算法,以确定最佳的空腔形状。每种方法都简要概述了它如何适应几何形状,并讨论了不同场景下它们各自的优缺点。我们使用不同复杂性的三维几何图形进行比较。我们的研究结果表明,对于几何翘曲补偿,基于节点的反向几何方法产生的翘曲最小,并且计算成本效益高。此外,它很容易实现,并且在不同的几何形状中表现一致。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Comparison of Numerical Methods for Geometric Warpage Compensation

Comparison of Numerical Methods for Geometric Warpage Compensation

In injection molding processes, shrinkage and warpage cause deviations in the size and shape of produced parts compared to the cavity shape. While shrinkage is due to the change of material density during solidification, warpage is caused by uneven cooling and internal stresses within the part. One approach to mitigate these effects is by adjusting the cavity shape to anticipate the deformation. While finding the optimal cavity shape is often experience-based in practice, numerical design optimization can greatly assist in this process. In this study, we evaluate various numerical algorithms from existing literature to identify the optimal cavity shape. Each method is briefly outlined regarding how it adapts the geometry, and we discuss their respective strengths and weaknesses for different scenarios. We conduct comparisons using 3D geometries of varying complexity. Our findings demonstrate that, for geometric warpage compensation, the node-based reverse geometry method yields the least warpage and is computationally cost-effective. Furthermore, it is straightforward to implement and consistently performs well across different geometries.
