原子薄PdIn双金属烯与表面有序钯三聚体用于N2和CO2高效电合成尿素

IF 13.1 1区 化学 Q1 CHEMISTRY, PHYSICAL
Hao Zhang, He Li*, Mengyang Xia, Ben Chong, Honghui Ou, Yang Li, Xiaoqing Yan, Bo Lin and Guidong Yang*,
{"title":"原子薄PdIn双金属烯与表面有序钯三聚体用于N2和CO2高效电合成尿素","authors":"Hao Zhang,&nbsp;He Li*,&nbsp;Mengyang Xia,&nbsp;Ben Chong,&nbsp;Honghui Ou,&nbsp;Yang Li,&nbsp;Xiaoqing Yan,&nbsp;Bo Lin and Guidong Yang*,&nbsp;","doi":"10.1021/acscatal.5c02636","DOIUrl":null,"url":null,"abstract":"<p >Urea synthesis via N<sub>2</sub> and CO<sub>2</sub> electrocatalysis has attracted significant interest but is hindered by unclear conversion mechanisms and low catalytic efficiency. Here, we report three atomically thin PdIn bimetallene catalysts, from surface-ordered Pd<sub>4</sub> tetramers to linearly arranged Pd atoms, where the Pd–In dual-site atomic geometric configuration is tuned by introducing polyamine ligands to induce a steric hindrance effect. Experimental data and simulations show that the atomically thin structure enhances the exposure of internal sites, where Pd and In act as activation centers for N<sub>2</sub> and CO<sub>2</sub>, respectively. Notably, on the orthorhombic Pd<sub>2</sub>In surface, an ordered Pd<sub>3</sub> trimers nitrogen activation region exists, enabling the transformation of nitrogen from initial end-on to more favorable side-on adsorption in the C–N coupling intermediate. This transformation highly activates the N–N group in the *NCON intermediate, promoting proton hydrogenation. Consequently, Pd<sub>2</sub>In with ordered Pd<sub>3</sub> trimers achieves a high urea yield of 5.69 ± 0.12 mmol g<sup>–1</sup> h<sup>–1</sup> and a Faradaic efficiency of 31.8 ± 0.3% at an ultralow potential of −0.1 V vs the reversible hydrogen electrode, marking one of the highest values in N<sub>2</sub> and CO<sub>2</sub> coreduction systems.</p>","PeriodicalId":9,"journal":{"name":"ACS Catalysis ","volume":"15 15","pages":"12905–12916"},"PeriodicalIF":13.1000,"publicationDate":"2025-07-15","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Atomically Thin PdIn Bimetallene with Surface-Ordered Palladium Trimers for Efficient Urea Electrosynthesis from N2 and CO2\",\"authors\":\"Hao Zhang,&nbsp;He Li*,&nbsp;Mengyang Xia,&nbsp;Ben Chong,&nbsp;Honghui Ou,&nbsp;Yang Li,&nbsp;Xiaoqing Yan,&nbsp;Bo Lin and Guidong Yang*,&nbsp;\",\"doi\":\"10.1021/acscatal.5c02636\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >Urea synthesis via N<sub>2</sub> and CO<sub>2</sub> electrocatalysis has attracted significant interest but is hindered by unclear conversion mechanisms and low catalytic efficiency. Here, we report three atomically thin PdIn bimetallene catalysts, from surface-ordered Pd<sub>4</sub> tetramers to linearly arranged Pd atoms, where the Pd–In dual-site atomic geometric configuration is tuned by introducing polyamine ligands to induce a steric hindrance effect. Experimental data and simulations show that the atomically thin structure enhances the exposure of internal sites, where Pd and In act as activation centers for N<sub>2</sub> and CO<sub>2</sub>, respectively. Notably, on the orthorhombic Pd<sub>2</sub>In surface, an ordered Pd<sub>3</sub> trimers nitrogen activation region exists, enabling the transformation of nitrogen from initial end-on to more favorable side-on adsorption in the C–N coupling intermediate. This transformation highly activates the N–N group in the *NCON intermediate, promoting proton hydrogenation. Consequently, Pd<sub>2</sub>In with ordered Pd<sub>3</sub> trimers achieves a high urea yield of 5.69 ± 0.12 mmol g<sup>–1</sup> h<sup>–1</sup> and a Faradaic efficiency of 31.8 ± 0.3% at an ultralow potential of −0.1 V vs the reversible hydrogen electrode, marking one of the highest values in N<sub>2</sub> and CO<sub>2</sub> coreduction systems.</p>\",\"PeriodicalId\":9,\"journal\":{\"name\":\"ACS Catalysis \",\"volume\":\"15 15\",\"pages\":\"12905–12916\"},\"PeriodicalIF\":13.1000,\"publicationDate\":\"2025-07-15\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"ACS Catalysis \",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://pubs.acs.org/doi/10.1021/acscatal.5c02636\",\"RegionNum\":1,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, PHYSICAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Catalysis ","FirstCategoryId":"92","ListUrlMain":"https://pubs.acs.org/doi/10.1021/acscatal.5c02636","RegionNum":1,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, PHYSICAL","Score":null,"Total":0}
引用次数: 0

摘要

N2和CO2电催化合成尿素引起了人们的极大兴趣,但由于转化机制不明确和催化效率低而受到阻碍。在这里,我们报道了三种原子薄的PdIn双金属烯催化剂,从表面有序的Pd4四聚体到线性排列的Pd原子,其中通过引入多胺配体来诱导空间位阻效应来调整Pd - in双位点原子几何构型。实验数据和模拟表明,原子薄结构增强了内部位点的暴露,其中Pd和In分别作为N2和CO2的活化中心。值得注意的是,在正交Pd2In表面,存在有序的Pd3三聚体氮活化区,使得氮在C-N偶联中间体中从最初的端对转化为更有利的侧对吸附。这种转变高度激活了*NCON中间体中的N-N基团,促进了质子氢化。结果表明,与可逆氢电极相比,在−0.1 V的超低电位下,Pd2In与有序Pd3三聚体的尿素产率达到5.69±0.12 mmol g-1 h-1,法拉第效率为31.8±0.3%,是N2和CO2共还原体系中的最高值之一。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Atomically Thin PdIn Bimetallene with Surface-Ordered Palladium Trimers for Efficient Urea Electrosynthesis from N2 and CO2

Atomically Thin PdIn Bimetallene with Surface-Ordered Palladium Trimers for Efficient Urea Electrosynthesis from N2 and CO2

Urea synthesis via N2 and CO2 electrocatalysis has attracted significant interest but is hindered by unclear conversion mechanisms and low catalytic efficiency. Here, we report three atomically thin PdIn bimetallene catalysts, from surface-ordered Pd4 tetramers to linearly arranged Pd atoms, where the Pd–In dual-site atomic geometric configuration is tuned by introducing polyamine ligands to induce a steric hindrance effect. Experimental data and simulations show that the atomically thin structure enhances the exposure of internal sites, where Pd and In act as activation centers for N2 and CO2, respectively. Notably, on the orthorhombic Pd2In surface, an ordered Pd3 trimers nitrogen activation region exists, enabling the transformation of nitrogen from initial end-on to more favorable side-on adsorption in the C–N coupling intermediate. This transformation highly activates the N–N group in the *NCON intermediate, promoting proton hydrogenation. Consequently, Pd2In with ordered Pd3 trimers achieves a high urea yield of 5.69 ± 0.12 mmol g–1 h–1 and a Faradaic efficiency of 31.8 ± 0.3% at an ultralow potential of −0.1 V vs the reversible hydrogen electrode, marking one of the highest values in N2 and CO2 coreduction systems.
