利用二苯基膦氧化物取代基改善高效倒钙钛矿太阳能电池的埋藏界面接触

IF 17.1 1区 材料科学 Q1 CHEMISTRY, PHYSICAL
Yanjie Wu , Anudari Dolgormaa , Yichi Zhang , Liu Yang , Bing Yao , Hongmei Zhan , Yanxiang Cheng , Lixiang Wang , Chuanjiang Qin
{"title":"利用二苯基膦氧化物取代基改善高效倒钙钛矿太阳能电池的埋藏界面接触","authors":"Yanjie Wu ,&nbsp;Anudari Dolgormaa ,&nbsp;Yichi Zhang ,&nbsp;Liu Yang ,&nbsp;Bing Yao ,&nbsp;Hongmei Zhan ,&nbsp;Yanxiang Cheng ,&nbsp;Lixiang Wang ,&nbsp;Chuanjiang Qin","doi":"10.1016/j.nanoen.2025.111319","DOIUrl":null,"url":null,"abstract":"<div><div>(3,6-dimethyl-9H-carbazol-9-yl)butyl]phosphonic acid (Me-4PACz) is widely employed as a self-assembled monolayer (SAM) for the hole transport layer (HTL) in inverted perovskite solar cells (PSCs), but its performance is limited by the carbazole core's insufficient defect passivation, weak phosphate anchoring to NiOx, and energy level mismatch with the perovskite layer. We design and synthesize a stable SAM, 4-(3,6-bis(diphenylphosphoryl)-9H-carbazol-9-yl)butylphosphonic acid (DPPO-4PACz), which enhances and stabilizes the interface between NiOₓ and perovskite. DPPO-4PACz is doped with Me-4PACz to form a co-SAM, which enhances the interfacial binding energy of the NiOx surface, suppresses surface defect states and increases conductivity. Furthermore, DPPO-4PACz promotes the growth of perovskite crystals, passivates buried interface defects, relieves residual stress in the perovskite film, and optimizes the energy level alignment at the hole-selective interface, thereby enhancing hole extraction efficiency. As a result, the champion inverted device achieves a high power conversion efficiency (PCE) of 25.67 %. Notably, after continuous operation at the maximum power point for 1200 h, the encapsulated device retains 93 % of its initial PCE. Our work underscores the critical role of head group design in SAMs at the buried interface for achieving high-performance PSCs, paving the way for further advancements in their practical applications.</div></div>","PeriodicalId":394,"journal":{"name":"Nano Energy","volume":"143 ","pages":"Article 111319"},"PeriodicalIF":17.1000,"publicationDate":"2025-07-11","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Improving buried interface contact by diphenylphosphine oxide substituent for highly efficient inverted perovskite solar cells\",\"authors\":\"Yanjie Wu ,&nbsp;Anudari Dolgormaa ,&nbsp;Yichi Zhang ,&nbsp;Liu Yang ,&nbsp;Bing Yao ,&nbsp;Hongmei Zhan ,&nbsp;Yanxiang Cheng ,&nbsp;Lixiang Wang ,&nbsp;Chuanjiang Qin\",\"doi\":\"10.1016/j.nanoen.2025.111319\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><div>(3,6-dimethyl-9H-carbazol-9-yl)butyl]phosphonic acid (Me-4PACz) is widely employed as a self-assembled monolayer (SAM) for the hole transport layer (HTL) in inverted perovskite solar cells (PSCs), but its performance is limited by the carbazole core's insufficient defect passivation, weak phosphate anchoring to NiOx, and energy level mismatch with the perovskite layer. We design and synthesize a stable SAM, 4-(3,6-bis(diphenylphosphoryl)-9H-carbazol-9-yl)butylphosphonic acid (DPPO-4PACz), which enhances and stabilizes the interface between NiOₓ and perovskite. DPPO-4PACz is doped with Me-4PACz to form a co-SAM, which enhances the interfacial binding energy of the NiOx surface, suppresses surface defect states and increases conductivity. Furthermore, DPPO-4PACz promotes the growth of perovskite crystals, passivates buried interface defects, relieves residual stress in the perovskite film, and optimizes the energy level alignment at the hole-selective interface, thereby enhancing hole extraction efficiency. As a result, the champion inverted device achieves a high power conversion efficiency (PCE) of 25.67 %. Notably, after continuous operation at the maximum power point for 1200 h, the encapsulated device retains 93 % of its initial PCE. Our work underscores the critical role of head group design in SAMs at the buried interface for achieving high-performance PSCs, paving the way for further advancements in their practical applications.</div></div>\",\"PeriodicalId\":394,\"journal\":{\"name\":\"Nano Energy\",\"volume\":\"143 \",\"pages\":\"Article 111319\"},\"PeriodicalIF\":17.1000,\"publicationDate\":\"2025-07-11\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Nano Energy\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://www.sciencedirect.com/science/article/pii/S2211285525006780\",\"RegionNum\":1,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, PHYSICAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Nano Energy","FirstCategoryId":"88","ListUrlMain":"https://www.sciencedirect.com/science/article/pii/S2211285525006780","RegionNum":1,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, PHYSICAL","Score":null,"Total":0}
引用次数: 0

摘要

(3,6-二甲基- 9h -咔唑-9-基)丁基]膦酸(Me-4PACz)被广泛应用于反向钙钛矿太阳能电池(PSCs)的空穴传输层(HTL)中,作为自组装单层(SAM),但其性能受到咔唑核缺陷钝化不足、磷酸盐对NiOx的弱锚定以及与钙钛矿层的能级不匹配的限制。我们设计并合成了一种稳定的SAM, 4-(3,6-双(二苯基磷酸基)- 9h -咔唑-9-基)丁基膦酸(DPPO-4PACz),它增强和稳定了NiOₓ与钙钛矿之间的界面。DPPO-4PACz掺杂Me-4PACz形成共sam,增强了NiOx表面的界面结合能,抑制了表面缺陷态,提高了电导率。此外,DPPO-4PACz促进钙钛矿晶体的生长,钝化埋藏界面缺陷,消除钙钛矿膜中的残余应力,优化选穴界面处的能级排列,从而提高取穴效率。因此,冠军倒置装置实现了25.67%的高功率转换效率(PCE)。值得注意的是,在最大功率点连续工作1200小时后,封装器件保留了93%的初始PCE。我们的工作强调了埋地接口处SAMs头组设计对于实现高性能psc的关键作用,为其实际应用的进一步发展铺平了道路。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Improving buried interface contact by diphenylphosphine oxide substituent for highly efficient inverted perovskite solar cells

Improving buried interface contact by diphenylphosphine oxide substituent for highly efficient inverted perovskite solar cells
(3,6-dimethyl-9H-carbazol-9-yl)butyl]phosphonic acid (Me-4PACz) is widely employed as a self-assembled monolayer (SAM) for the hole transport layer (HTL) in inverted perovskite solar cells (PSCs), but its performance is limited by the carbazole core's insufficient defect passivation, weak phosphate anchoring to NiOx, and energy level mismatch with the perovskite layer. We design and synthesize a stable SAM, 4-(3,6-bis(diphenylphosphoryl)-9H-carbazol-9-yl)butylphosphonic acid (DPPO-4PACz), which enhances and stabilizes the interface between NiOₓ and perovskite. DPPO-4PACz is doped with Me-4PACz to form a co-SAM, which enhances the interfacial binding energy of the NiOx surface, suppresses surface defect states and increases conductivity. Furthermore, DPPO-4PACz promotes the growth of perovskite crystals, passivates buried interface defects, relieves residual stress in the perovskite film, and optimizes the energy level alignment at the hole-selective interface, thereby enhancing hole extraction efficiency. As a result, the champion inverted device achieves a high power conversion efficiency (PCE) of 25.67 %. Notably, after continuous operation at the maximum power point for 1200 h, the encapsulated device retains 93 % of its initial PCE. Our work underscores the critical role of head group design in SAMs at the buried interface for achieving high-performance PSCs, paving the way for further advancements in their practical applications.
求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
Nano Energy
Nano Energy CHEMISTRY, PHYSICAL-NANOSCIENCE & NANOTECHNOLOGY
CiteScore
30.30
自引率
7.40%
发文量
1207
审稿时长
23 days
期刊介绍: Nano Energy is a multidisciplinary, rapid-publication forum of original peer-reviewed contributions on the science and engineering of nanomaterials and nanodevices used in all forms of energy harvesting, conversion, storage, utilization and policy. Through its mixture of articles, reviews, communications, research news, and information on key developments, Nano Energy provides a comprehensive coverage of this exciting and dynamic field which joins nanoscience and nanotechnology with energy science. The journal is relevant to all those who are interested in nanomaterials solutions to the energy problem. Nano Energy publishes original experimental and theoretical research on all aspects of energy-related research which utilizes nanomaterials and nanotechnology. Manuscripts of four types are considered: review articles which inform readers of the latest research and advances in energy science; rapid communications which feature exciting research breakthroughs in the field; full-length articles which report comprehensive research developments; and news and opinions which comment on topical issues or express views on the developments in related fields.
×
