支持工业相关微生物生长的冷冻铸造SiOC陶瓷。

IF 2.6 3区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES
PLoS ONE Pub Date : 2025-06-12 eCollection Date: 2025-01-01 DOI:10.1371/journal.pone.0325311
Katharina Rauchenwald, Roghayeh Shirvani, Tobias Edtmaier, Matthias Steiger, Thomas Konegger
{"title":"支持工业相关微生物生长的冷冻铸造SiOC陶瓷。","authors":"Katharina Rauchenwald, Roghayeh Shirvani, Tobias Edtmaier, Matthias Steiger, Thomas Konegger","doi":"10.1371/journal.pone.0325311","DOIUrl":null,"url":null,"abstract":"<p><p>Investigating the compatibility of ceramic support materials with industrially relevant microorganisms is a key starting point towards utilizing innovative ceramic frameworks for microbial culture support. This study demonstrates the biocompatibility of macroporous, freeze-cast SiOC monoliths with yeast Komagataella phaffii and bacteria Escherichia coli. In a first step, cultivations were carried out in the presence of non-macroporous SiOC materials pyrolyzed at 700 °C or 900 °C, which were further compared to Al2O3 and SiO2 as conventional ceramic and glass reference materials. Additionally, SiOC ceramics impregnated with 3 wt.% Cu were evaluated regarding cytotoxic effects, since Cu is recognized for its antimicrobial properties. Both E. coli and K. phaffii showed no growth inhibition in the presence of SiOC, yielding specific growth rates of 0.46 ± 0.01 h-1 and 0.088 ± 0.002 h-1, respectively, showing overall biocompatibility with SiOC. While E. coli showed growth inhibition in the presence of Cu via prolonged lag-phases, K. phaffii was resistant to Cu-modified SiOC. In the next step, adsorption of cells to macroporous SiOC was investigated after cultivation by electron microscopy of fracture surfaces of freeze-cast SiOC, structured with tert-butyl alcohol templating directional channels with pore opening diameters around 45 μm. Prevalent biofilm formation was observed within the channel walls with clear evidence for growth of K. phaffii as cell agglomerates. The study features promising results for promotion of the growth of E. coli and K. phaffii on freeze-cast SiOC ceramics, providing a versatile catalyst carrier design.</p>","PeriodicalId":20189,"journal":{"name":"PLoS ONE","volume":"20 6","pages":"e0325311"},"PeriodicalIF":2.6000,"publicationDate":"2025-06-12","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12161521/pdf/","citationCount":"0","resultStr":"{\"title\":\"Freeze-cast SiOC ceramics supporting the growth of industrially relevant microorganisms.\",\"authors\":\"Katharina Rauchenwald, Roghayeh Shirvani, Tobias Edtmaier, Matthias Steiger, Thomas Konegger\",\"doi\":\"10.1371/journal.pone.0325311\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Investigating the compatibility of ceramic support materials with industrially relevant microorganisms is a key starting point towards utilizing innovative ceramic frameworks for microbial culture support. This study demonstrates the biocompatibility of macroporous, freeze-cast SiOC monoliths with yeast Komagataella phaffii and bacteria Escherichia coli. In a first step, cultivations were carried out in the presence of non-macroporous SiOC materials pyrolyzed at 700 °C or 900 °C, which were further compared to Al2O3 and SiO2 as conventional ceramic and glass reference materials. Additionally, SiOC ceramics impregnated with 3 wt.% Cu were evaluated regarding cytotoxic effects, since Cu is recognized for its antimicrobial properties. Both E. coli and K. phaffii showed no growth inhibition in the presence of SiOC, yielding specific growth rates of 0.46 ± 0.01 h-1 and 0.088 ± 0.002 h-1, respectively, showing overall biocompatibility with SiOC. While E. coli showed growth inhibition in the presence of Cu via prolonged lag-phases, K. phaffii was resistant to Cu-modified SiOC. In the next step, adsorption of cells to macroporous SiOC was investigated after cultivation by electron microscopy of fracture surfaces of freeze-cast SiOC, structured with tert-butyl alcohol templating directional channels with pore opening diameters around 45 μm. Prevalent biofilm formation was observed within the channel walls with clear evidence for growth of K. phaffii as cell agglomerates. The study features promising results for promotion of the growth of E. coli and K. phaffii on freeze-cast SiOC ceramics, providing a versatile catalyst carrier design.</p>\",\"PeriodicalId\":20189,\"journal\":{\"name\":\"PLoS ONE\",\"volume\":\"20 6\",\"pages\":\"e0325311\"},\"PeriodicalIF\":2.6000,\"publicationDate\":\"2025-06-12\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12161521/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"PLoS ONE\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1371/journal.pone.0325311\",\"RegionNum\":3,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"2025/1/1 0:00:00\",\"PubModel\":\"eCollection\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"PLoS ONE","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1371/journal.pone.0325311","RegionNum":3,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2025/1/1 0:00:00","PubModel":"eCollection","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

研究陶瓷支撑材料与工业相关微生物的相容性是利用创新陶瓷框架进行微生物培养支撑的关键起点。本研究证明了大孔、冷冻铸造SiOC单体与酵母和细菌的生物相容性。在第一步中,在700°C或900°C热解的非大孔SiOC材料中进行培养,并将其与Al2O3和SiO2作为传统陶瓷和玻璃参考材料进行比较。此外,由于Cu具有抗菌性能,因此我们对含有3wt .% Cu的SiOC陶瓷的细胞毒性进行了评估。大肠杆菌和K. phaffii在SiOC存在下均无生长抑制作用,其比生长率分别为0.46±0.01 h-1和0.088±0.002 h-1,与SiOC具有良好的生物相容性。大肠杆菌在Cu存在下表现出长时间的滞后期生长抑制,而K. phaffii对Cu修饰的SiOC具有抗性。下一步,采用叔丁醇模板定向通道结构,孔径约为45 μm,通过电镜观察,研究了细胞对大孔SiOC的吸附。在通道壁内观察到普遍的生物膜形成,明确的证据表明菲氏K.以细胞团块的形式生长。该研究在促进大肠杆菌和K. phaffii在冻铸SiOC陶瓷上的生长方面取得了可喜的结果,提供了一种多功能的催化剂载体设计。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Freeze-cast SiOC ceramics supporting the growth of industrially relevant microorganisms.

Freeze-cast SiOC ceramics supporting the growth of industrially relevant microorganisms.

Freeze-cast SiOC ceramics supporting the growth of industrially relevant microorganisms.

Freeze-cast SiOC ceramics supporting the growth of industrially relevant microorganisms.

Investigating the compatibility of ceramic support materials with industrially relevant microorganisms is a key starting point towards utilizing innovative ceramic frameworks for microbial culture support. This study demonstrates the biocompatibility of macroporous, freeze-cast SiOC monoliths with yeast Komagataella phaffii and bacteria Escherichia coli. In a first step, cultivations were carried out in the presence of non-macroporous SiOC materials pyrolyzed at 700 °C or 900 °C, which were further compared to Al2O3 and SiO2 as conventional ceramic and glass reference materials. Additionally, SiOC ceramics impregnated with 3 wt.% Cu were evaluated regarding cytotoxic effects, since Cu is recognized for its antimicrobial properties. Both E. coli and K. phaffii showed no growth inhibition in the presence of SiOC, yielding specific growth rates of 0.46 ± 0.01 h-1 and 0.088 ± 0.002 h-1, respectively, showing overall biocompatibility with SiOC. While E. coli showed growth inhibition in the presence of Cu via prolonged lag-phases, K. phaffii was resistant to Cu-modified SiOC. In the next step, adsorption of cells to macroporous SiOC was investigated after cultivation by electron microscopy of fracture surfaces of freeze-cast SiOC, structured with tert-butyl alcohol templating directional channels with pore opening diameters around 45 μm. Prevalent biofilm formation was observed within the channel walls with clear evidence for growth of K. phaffii as cell agglomerates. The study features promising results for promotion of the growth of E. coli and K. phaffii on freeze-cast SiOC ceramics, providing a versatile catalyst carrier design.
