低介电性、高阻燃性、高耐热性聚硅氧烷的一步法制备

IF 4.7 2区 化学 Q2 MATERIALS SCIENCE, MULTIDISCIPLINARY
Miao-Miao Shi, Bo Han, Jia-Xin Song and Zhu-Bao Shao*,
{"title":"低介电性、高阻燃性、高耐热性聚硅氧烷的一步法制备","authors":"Miao-Miao Shi,&nbsp;Bo Han,&nbsp;Jia-Xin Song and Zhu-Bao Shao*,&nbsp;","doi":"10.1021/acsapm.5c0114710.1021/acsapm.5c01147","DOIUrl":null,"url":null,"abstract":"<p >The development of polymer materials with simultaneously high flame retardancy, high heat resistance, and low dielectric property for high-frequency and high-speed communication applications remains a challenge. Herein, a phosphorus- and benzene-containing siloxane monomer (VDDP) featuring double bonds was synthesized through sol–gel polycondensation using methyl vinyldimethylsilane (VMS), diphenylsilanediol (DPSD), and diphenylphosphine oxide (DPO). Subsequently, polysiloxane composites (PVDDPs) were fabricated through a double-bond cross-linking reaction. The introduced benzene-functionalized siloxane structures endowed PVDDP composites with exceptional thermal stability, demonstrating an initial thermal decomposition temperature (<i>T</i><sub>5%</sub>) of 450 °C. The phosphorus–silicon synergistic effect imparted outstanding fire safety, achieving both a limiting oxygen index (LOI) of 30.8% and a V0 rating in the UL-94 test. Notably, the peak heat release rate (pHRR) and peak smoke production rate (pSPR) of PVDDP dramatically decreased to 238.9 kW/m<sup>2</sup> and 0.26 m<sup>2</sup>/s, respectively. Due to the introduction of DPO, the increase of the free volume fraction between polysiloxane molecules effectively lowered the dielectric constant (<i>D</i><sub>k</sub>) to 2.80. The PVDDP composites with high flame retardancy, low dielectric property, and high heat resistance display a good application prospect in the field of high-frequency and high-speed electronic communication.</p>","PeriodicalId":7,"journal":{"name":"ACS Applied Polymer Materials","volume":"7 11","pages":"7507–7515 7507–7515"},"PeriodicalIF":4.7000,"publicationDate":"2025-06-02","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"One-Step Fabrication of Polysiloxane with Simultaneously Low Dielectric Property, High Flame Retardancy, and High Heat Resistance\",\"authors\":\"Miao-Miao Shi,&nbsp;Bo Han,&nbsp;Jia-Xin Song and Zhu-Bao Shao*,&nbsp;\",\"doi\":\"10.1021/acsapm.5c0114710.1021/acsapm.5c01147\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >The development of polymer materials with simultaneously high flame retardancy, high heat resistance, and low dielectric property for high-frequency and high-speed communication applications remains a challenge. Herein, a phosphorus- and benzene-containing siloxane monomer (VDDP) featuring double bonds was synthesized through sol–gel polycondensation using methyl vinyldimethylsilane (VMS), diphenylsilanediol (DPSD), and diphenylphosphine oxide (DPO). Subsequently, polysiloxane composites (PVDDPs) were fabricated through a double-bond cross-linking reaction. The introduced benzene-functionalized siloxane structures endowed PVDDP composites with exceptional thermal stability, demonstrating an initial thermal decomposition temperature (<i>T</i><sub>5%</sub>) of 450 °C. The phosphorus–silicon synergistic effect imparted outstanding fire safety, achieving both a limiting oxygen index (LOI) of 30.8% and a V0 rating in the UL-94 test. Notably, the peak heat release rate (pHRR) and peak smoke production rate (pSPR) of PVDDP dramatically decreased to 238.9 kW/m<sup>2</sup> and 0.26 m<sup>2</sup>/s, respectively. Due to the introduction of DPO, the increase of the free volume fraction between polysiloxane molecules effectively lowered the dielectric constant (<i>D</i><sub>k</sub>) to 2.80. The PVDDP composites with high flame retardancy, low dielectric property, and high heat resistance display a good application prospect in the field of high-frequency and high-speed electronic communication.</p>\",\"PeriodicalId\":7,\"journal\":{\"name\":\"ACS Applied Polymer Materials\",\"volume\":\"7 11\",\"pages\":\"7507–7515 7507–7515\"},\"PeriodicalIF\":4.7000,\"publicationDate\":\"2025-06-02\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"ACS Applied Polymer Materials\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://pubs.acs.org/doi/10.1021/acsapm.5c01147\",\"RegionNum\":2,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"MATERIALS SCIENCE, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Applied Polymer Materials","FirstCategoryId":"92","ListUrlMain":"https://pubs.acs.org/doi/10.1021/acsapm.5c01147","RegionNum":2,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"MATERIALS SCIENCE, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

开发同时具有高阻燃性、高耐热性和低介电性的高分子材料用于高频高速通信仍然是一个挑战。本文以甲基乙烯基二甲基硅烷(VMS)、二苯基硅二醇(DPSD)和二苯基氧化膦(DPO)为原料,通过溶胶-凝胶缩聚法合成了一种具有双键结构的含磷、含苯硅氧烷单体(VDDP)。随后,通过双键交联反应制备了聚硅氧烷复合材料。引入的苯功能化硅氧烷结构赋予了PVDDP复合材料优异的热稳定性,显示出450℃的初始热分解温度(T5%)。磷硅的协同效应赋予了出色的防火安全性,在UL-94测试中,极限氧指数(LOI)达到30.8%,V0等级。PVDDP的峰值放热速率(pHRR)和峰值产烟速率(pSPR)显著降低,分别为238.9 kW/m2和0.26 m2/s。由于DPO的引入,聚硅氧烷分子间自由体积分数的增加有效地降低了介电常数(Dk)至2.80。高阻燃性、低介电性、高耐热性的PVDDP复合材料在高频高速电子通信领域显示出良好的应用前景。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

One-Step Fabrication of Polysiloxane with Simultaneously Low Dielectric Property, High Flame Retardancy, and High Heat Resistance

One-Step Fabrication of Polysiloxane with Simultaneously Low Dielectric Property, High Flame Retardancy, and High Heat Resistance

The development of polymer materials with simultaneously high flame retardancy, high heat resistance, and low dielectric property for high-frequency and high-speed communication applications remains a challenge. Herein, a phosphorus- and benzene-containing siloxane monomer (VDDP) featuring double bonds was synthesized through sol–gel polycondensation using methyl vinyldimethylsilane (VMS), diphenylsilanediol (DPSD), and diphenylphosphine oxide (DPO). Subsequently, polysiloxane composites (PVDDPs) were fabricated through a double-bond cross-linking reaction. The introduced benzene-functionalized siloxane structures endowed PVDDP composites with exceptional thermal stability, demonstrating an initial thermal decomposition temperature (T5%) of 450 °C. The phosphorus–silicon synergistic effect imparted outstanding fire safety, achieving both a limiting oxygen index (LOI) of 30.8% and a V0 rating in the UL-94 test. Notably, the peak heat release rate (pHRR) and peak smoke production rate (pSPR) of PVDDP dramatically decreased to 238.9 kW/m2 and 0.26 m2/s, respectively. Due to the introduction of DPO, the increase of the free volume fraction between polysiloxane molecules effectively lowered the dielectric constant (Dk) to 2.80. The PVDDP composites with high flame retardancy, low dielectric property, and high heat resistance display a good application prospect in the field of high-frequency and high-speed electronic communication.
