Design of improved internal mode controller for hydro-turbine governing system based on generalized inverse solver method.

Hydropower unit plays a more and more important role in guaranteeing the safe and stable operation of the power system and providing high-quality power supply. As a non-minimum phase system, one of the most concerned problems is the design of hydro-turbine governing system (HTGS). Internal mode control (IMC) is a good method for turbine speed control system. To solve the problem of inverse difficulty when conventional IMC is used for hydro-generator (non-minimum phase system), this paper proposes an improved IMC based on generalized inverse solver (GIS). The article verifies the superiority of this control method for different types of linear systems through simulation. At the same time, this method is applied to the hydro generator speed control system. Compared with IMC and some improved PID algorithms, IMC with GIS algorithm shows advantages in terms of tracking response and anti-disturbance performance. It achieves overshoot-free tracking with 30% less inversion and 31% shorter recovery time after failure. The response time fluctuation is reduced by 46% compared with other algorithms, which shows stronger robustness when facing the parameter ingestion problem.
