通过与化学环制氢和合成氨相结合，改造天然气联合循环，形成碳中性的三联产系统

IF 10 1区环境科学与生态学 Q1 ENGINEERING, ENVIRONMENTAL

Journal of Cleaner Production Pub Date : 2025-05-14 DOI:10.1016/j.jclepro.2025.145691

Azaria Haykal Ahmad , Alfian Muhammad Reza , Muhammad Aziz

{"title":"通过与化学环制氢和合成氨相结合，改造天然气联合循环，形成碳中性的三联产系统","authors":"Azaria Haykal Ahmad , Alfian Muhammad Reza , Muhammad Aziz","doi":"10.1016/j.jclepro.2025.145691","DOIUrl":null,"url":null,"abstract":"<div><div>The global electricity sector is currently dominated by fossil fuels, posing a significant challenge to achieving net-zero emissions targets. Decarbonizing the power sector while utilizing existing fossil fuel-based power plants is essential. Natural gas (NG), the second-largest source of electricity globally, can be partially replaced with hydrogen (H2) and/or ammonia (NH3). A 50:50 M mixture of H2 and NH3 offers a promising solution, providing a flame speed comparable to NG while addressing these limitations. Despite this potential, H2 production is still predominantly reliant on fossil fuel-based grey H2. In this study, the integration of biomass CLHG, NH3 synthesis, and an existing 500 MW NGCC power plant was investigated through process simulation and off-design analysis. This approach addressed key limitations of conventional H2 and NH3 production pathways and assessed necessary modifications to accommodate H2-NH3 co-firing while maintaining efficiency. The CLHG system achieved an H2 production efficiency of 75 %, while the NH3 synthesis process exhibited an efficiency of 63 %. When NG was replaced by the H2-NH3 mixture, the overall efficiency of the system decreased from 56.19 % to 47.1 %, primarily due to fuel production processes. Under partial load conditions, the efficiency trends of NGCC were comparable to those observed in conventional NGCC systems, except at 40 % load, due to the high steam flow rate in the heat recovery steam generator. The calculated levelized cost of electricity for the integrated system was 0.1075 USD/kWh, lower than that of imported fuels. Additionally, the levelized costs of H2 and NH3 were 1.439 USD/kg-H2 and 0.365 USD/kg-NH3, respectively. By leveraging a steady-state CLHG-NH3 system with flexible NGCC operation, this study presents a viable pathway for decarbonizing NGCC plants while ensuring cost competitiveness in a transitioning energy market.</div></div>","PeriodicalId":349,"journal":{"name":"Journal of Cleaner Production","volume":"513 ","pages":"Article 145691"},"PeriodicalIF":10.0000,"publicationDate":"2025-05-14","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Retrofitting the natural gas combined cycle through integration with chemical looping hydrogen generation and ammonia synthesis toward a carbon-neutral trigeneration system\",\"authors\":\"Azaria Haykal Ahmad , Alfian Muhammad Reza , Muhammad Aziz\",\"doi\":\"10.1016/j.jclepro.2025.145691\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<div><div>The global electricity sector is currently dominated by fossil fuels, posing a significant challenge to achieving net-zero emissions targets. Decarbonizing the power sector while utilizing existing fossil fuel-based power plants is essential. Natural gas (NG), the second-largest source of electricity globally, can be partially replaced with hydrogen (H2) and/or ammonia (NH3). A 50:50 M mixture of H2 and NH3 offers a promising solution, providing a flame speed comparable to NG while addressing these limitations. Despite this potential, H2 production is still predominantly reliant on fossil fuel-based grey H2. In this study, the integration of biomass CLHG, NH3 synthesis, and an existing 500 MW NGCC power plant was investigated through process simulation and off-design analysis. This approach addressed key limitations of conventional H2 and NH3 production pathways and assessed necessary modifications to accommodate H2-NH3 co-firing while maintaining efficiency. The CLHG system achieved an H2 production efficiency of 75 %, while the NH3 synthesis process exhibited an efficiency of 63 %. When NG was replaced by the H2-NH3 mixture, the overall efficiency of the system decreased from 56.19 % to 47.1 %, primarily due to fuel production processes. Under partial load conditions, the efficiency trends of NGCC were comparable to those observed in conventional NGCC systems, except at 40 % load, due to the high steam flow rate in the heat recovery steam generator. The calculated levelized cost of electricity for the integrated system was 0.1075 USD/kWh, lower than that of imported fuels. Additionally, the levelized costs of H2 and NH3 were 1.439 USD/kg-H2 and 0.365 USD/kg-NH3, respectively. By leveraging a steady-state CLHG-NH3 system with flexible NGCC operation, this study presents a viable pathway for decarbonizing NGCC plants while ensuring cost competitiveness in a transitioning energy market.</div></div>\",\"PeriodicalId\":349,\"journal\":{\"name\":\"Journal of Cleaner Production\",\"volume\":\"513 \",\"pages\":\"Article 145691\"},\"PeriodicalIF\":10.0000,\"publicationDate\":\"2025-05-14\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Journal of Cleaner Production\",\"FirstCategoryId\":\"93\",\"ListUrlMain\":\"https://www.sciencedirect.com/science/article/pii/S0959652625010418\",\"RegionNum\":1,\"RegionCategory\":\"环境科学与生态学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"ENGINEERING, ENVIRONMENTAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Journal of Cleaner Production","FirstCategoryId":"93","ListUrlMain":"https://www.sciencedirect.com/science/article/pii/S0959652625010418","RegionNum":1,"RegionCategory":"环境科学与生态学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"ENGINEERING, ENVIRONMENTAL","Score":null,"Total":0}

引用次数: 0

摘要

目前，全球电力行业以化石燃料为主，这对实现净零排放目标构成了重大挑战。在利用现有化石燃料发电厂的同时，使电力部门脱碳是至关重要的。天然气（NG）是全球第二大电力来源，可以部分被氢气（H2）和/或氨（NH3）取代。H2和NH3的50:50摩尔混合物提供了一个有前途的解决方案，提供与NG相当的火焰速度，同时解决了这些限制。尽管有这种潜力，氢气生产仍然主要依赖于基于化石燃料的灰色氢气。在本研究中，通过过程模拟和非设计分析，研究了生物质CLHG， NH3合成和现有500mw NGCC发电厂的整合。该方法解决了传统H2和NH3生产途径的主要局限性，并评估了在保持效率的同时适应H2-NH3共烧的必要修改。CLHG制氢效率为75%，NH3合成效率为63%。当天然气被H2-NH3混合物取代时，系统的整体效率从56.19%下降到47.1%，主要是由于燃料生产过程。在部分负荷条件下，由于余热蒸汽发生器的蒸汽流量较大，除负荷为40%时外，NGCC系统的效率变化趋势与常规NGCC系统相当。综合系统计算的平准化电费为0.1075美元/千瓦时，低于进口燃料电费。H2和NH3的平准化成本分别为1.439美元/kg-H2和0.365美元/kg-NH3。通过利用具有灵活NGCC操作的稳态CLHG-NH3系统，本研究为NGCC工厂脱碳提供了一条可行的途径，同时确保了能源市场转型中的成本竞争力。

本文章由计算机程序翻译，如有差异，请以英文原文为准。

Retrofitting the natural gas combined cycle through integration with chemical looping hydrogen generation and ammonia synthesis toward a carbon-neutral trigeneration system

查看原文本刊更多论文

Retrofitting the natural gas combined cycle through integration with chemical looping hydrogen generation and ammonia synthesis toward a carbon-neutral trigeneration system

The global electricity sector is currently dominated by fossil fuels, posing a significant challenge to achieving net-zero emissions targets. Decarbonizing the power sector while utilizing existing fossil fuel-based power plants is essential. Natural gas (NG), the second-largest source of electricity globally, can be partially replaced with hydrogen (H₂) and/or ammonia (NH₃). A 50:50 M mixture of H₂ and NH₃ offers a promising solution, providing a flame speed comparable to NG while addressing these limitations. Despite this potential, H₂ production is still predominantly reliant on fossil fuel-based grey H₂. In this study, the integration of biomass CLHG, NH₃ synthesis, and an existing 500 MW NGCC power plant was investigated through process simulation and off-design analysis. This approach addressed key limitations of conventional H₂ and NH₃ production pathways and assessed necessary modifications to accommodate H₂-NH₃ co-firing while maintaining efficiency. The CLHG system achieved an H₂ production efficiency of 75 %, while the NH₃ synthesis process exhibited an efficiency of 63 %. When NG was replaced by the H₂-NH₃ mixture, the overall efficiency of the system decreased from 56.19 % to 47.1 %, primarily due to fuel production processes. Under partial load conditions, the efficiency trends of NGCC were comparable to those observed in conventional NGCC systems, except at 40 % load, due to the high steam flow rate in the heat recovery steam generator. The calculated levelized cost of electricity for the integrated system was 0.1075 USD/kWh, lower than that of imported fuels. Additionally, the levelized costs of H₂ and NH₃ were 1.439 USD/kg-H₂ and 0.365 USD/kg-NH₃, respectively. By leveraging a steady-state CLHG-NH₃ system with flexible NGCC operation, this study presents a viable pathway for decarbonizing NGCC plants while ensuring cost competitiveness in a transitioning energy market.
