通过TaOX钝化增强钙钛矿/硅串联太阳能电池的界面接触

IF 12.1 2区 材料科学 Q1 CHEMISTRY, MULTIDISCIPLINARY
Small Pub Date : 2025-05-05 DOI:10.1002/smll.202503173
Yihan Sun, Zhiqin Ying, Xin Li, Meili Zhang, Xuchao Guo, Haojiang Du, Huan Li, Linhui Liu, Jun Wu, Haofan Ma, Yunyun Yu, Ziyu He, Yuheng Zeng, Xi Yang, Jichun Ye
{"title":"通过TaOX钝化增强钙钛矿/硅串联太阳能电池的界面接触","authors":"Yihan Sun,&nbsp;Zhiqin Ying,&nbsp;Xin Li,&nbsp;Meili Zhang,&nbsp;Xuchao Guo,&nbsp;Haojiang Du,&nbsp;Huan Li,&nbsp;Linhui Liu,&nbsp;Jun Wu,&nbsp;Haofan Ma,&nbsp;Yunyun Yu,&nbsp;Ziyu He,&nbsp;Yuheng Zeng,&nbsp;Xi Yang,&nbsp;Jichun Ye","doi":"10.1002/smll.202503173","DOIUrl":null,"url":null,"abstract":"<p>Perovskite/silicon tandem solar cells demonstrating tremendous potential for commercialization that position them as a transformative technology in photovoltaics. However, the poor interface contact between perovskite and C<sub>60</sub> has long been a critical factor limiting the power conversion efficiency (PCE) of top perovskite solar cells. Here, a multifunctional inorganic tantalum oxide (TaO<sub>X)</sub> film as a passivation layer is introduced, which not only suppresses recombination across the interface but also improves energy level alignment and enhances charge extraction at the perovskite/C<sub>60</sub> interface. More importantly, TaO<sub>X</sub> demonstrates exceptional thermal stability, which significantly enhances the overall stability of the device. These synergistic effects enable the fabrication of a single-junction cell with a PCE of 21.0% at a bandgap of 1.68 eV. Furthermore, when combined with a double-sided tunnel oxide passivated contact silicon bottom cell, a tandem cell with a PCE of 29.5% at 1 cm<sup>2</sup> is achieved. Furthermore, the unencapsulated TaO<sub>X</sub>-based devices exhibited significantly improved stability when subjected to ISOS-L-1 accelerated aging conditions.</p>","PeriodicalId":228,"journal":{"name":"Small","volume":"21 24","pages":""},"PeriodicalIF":12.1000,"publicationDate":"2025-05-05","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Enhancing Interfacial Contact in Perovskite/Silicon Tandem Solar Cells Through TaOX Passivation\",\"authors\":\"Yihan Sun,&nbsp;Zhiqin Ying,&nbsp;Xin Li,&nbsp;Meili Zhang,&nbsp;Xuchao Guo,&nbsp;Haojiang Du,&nbsp;Huan Li,&nbsp;Linhui Liu,&nbsp;Jun Wu,&nbsp;Haofan Ma,&nbsp;Yunyun Yu,&nbsp;Ziyu He,&nbsp;Yuheng Zeng,&nbsp;Xi Yang,&nbsp;Jichun Ye\",\"doi\":\"10.1002/smll.202503173\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p>Perovskite/silicon tandem solar cells demonstrating tremendous potential for commercialization that position them as a transformative technology in photovoltaics. However, the poor interface contact between perovskite and C<sub>60</sub> has long been a critical factor limiting the power conversion efficiency (PCE) of top perovskite solar cells. Here, a multifunctional inorganic tantalum oxide (TaO<sub>X)</sub> film as a passivation layer is introduced, which not only suppresses recombination across the interface but also improves energy level alignment and enhances charge extraction at the perovskite/C<sub>60</sub> interface. More importantly, TaO<sub>X</sub> demonstrates exceptional thermal stability, which significantly enhances the overall stability of the device. These synergistic effects enable the fabrication of a single-junction cell with a PCE of 21.0% at a bandgap of 1.68 eV. Furthermore, when combined with a double-sided tunnel oxide passivated contact silicon bottom cell, a tandem cell with a PCE of 29.5% at 1 cm<sup>2</sup> is achieved. Furthermore, the unencapsulated TaO<sub>X</sub>-based devices exhibited significantly improved stability when subjected to ISOS-L-1 accelerated aging conditions.</p>\",\"PeriodicalId\":228,\"journal\":{\"name\":\"Small\",\"volume\":\"21 24\",\"pages\":\"\"},\"PeriodicalIF\":12.1000,\"publicationDate\":\"2025-05-05\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Small\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://onlinelibrary.wiley.com/doi/10.1002/smll.202503173\",\"RegionNum\":2,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Small","FirstCategoryId":"88","ListUrlMain":"https://onlinelibrary.wiley.com/doi/10.1002/smll.202503173","RegionNum":2,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

钙钛矿/硅串联太阳能电池显示出巨大的商业化潜力,将其定位为光伏发电领域的变革性技术。然而,钙钛矿与C60之间的界面接触不良一直是限制顶部钙钛矿太阳能电池功率转换效率(PCE)的关键因素。本文介绍了一种多功能无机氧化钽(TaOX)薄膜作为钝化层,该钝化层不仅抑制了界面上的复合,而且改善了钙钛矿/C60界面上的能级排列并增强了电荷提取。更重要的是,TaOX表现出优异的热稳定性,这大大提高了设备的整体稳定性。这些协同效应使我们能够在1.68 eV的带隙下制造出PCE为21.0%的单结电池。此外,当与双面隧道氧化物钝化接触硅底部电池结合时,可获得1 cm2时PCE为29.5%的串联电池。此外,未封装的TaOX - based器件在ISOS - L - 1加速老化条件下表现出显着改善的稳定性。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Enhancing Interfacial Contact in Perovskite/Silicon Tandem Solar Cells Through TaOX Passivation

Enhancing Interfacial Contact in Perovskite/Silicon Tandem Solar Cells Through TaOX Passivation

Perovskite/silicon tandem solar cells demonstrating tremendous potential for commercialization that position them as a transformative technology in photovoltaics. However, the poor interface contact between perovskite and C60 has long been a critical factor limiting the power conversion efficiency (PCE) of top perovskite solar cells. Here, a multifunctional inorganic tantalum oxide (TaOX) film as a passivation layer is introduced, which not only suppresses recombination across the interface but also improves energy level alignment and enhances charge extraction at the perovskite/C60 interface. More importantly, TaOX demonstrates exceptional thermal stability, which significantly enhances the overall stability of the device. These synergistic effects enable the fabrication of a single-junction cell with a PCE of 21.0% at a bandgap of 1.68 eV. Furthermore, when combined with a double-sided tunnel oxide passivated contact silicon bottom cell, a tandem cell with a PCE of 29.5% at 1 cm2 is achieved. Furthermore, the unencapsulated TaOX-based devices exhibited significantly improved stability when subjected to ISOS-L-1 accelerated aging conditions.
