基于蒸发/溶液两步沉积的宽禁带钙钛矿太阳能电池控制成核和靶向界面修饰

IF 16 1区 材料科学 Q1 CHEMISTRY, MULTIDISCIPLINARY
ACS Nano Pub Date : 2025-04-14 DOI:10.1021/acsnano.5c00458
Yi-Peng Zhou, Liang-Xu Wang, Sheng-Chao Hui, Lin Song, Chenxin Ran, Zhongbin Wu, Wei Huang
{"title":"基于蒸发/溶液两步沉积的宽禁带钙钛矿太阳能电池控制成核和靶向界面修饰","authors":"Yi-Peng Zhou, Liang-Xu Wang, Sheng-Chao Hui, Lin Song, Chenxin Ran, Zhongbin Wu, Wei Huang","doi":"10.1021/acsnano.5c00458","DOIUrl":null,"url":null,"abstract":"Solution deposition struggles to achieve conformal and pinhole-free wide-bandgap (WBG) perovskite films on micrometer-scale textured silicon subcells due to challenges in nucleation dynamics and film uniformity, necessitating smaller textures in the efficient perovskite/silicon tandems, which compromise light trapping and current density. While evaporation-assisted two-step deposition improves conformality, it often yields films with suboptimal crystallinity and a high defect density. To address this, we elucidate the formation mechanism of CsPbI<sub><i>x</i></sub>Br<sub>3–<i>x</i></sub> nanocrystals during the thermal evaporation of PbI<sub>2</sub>/CsBr templates, which can serve as preferential nucleation sites to facilitate the growth of high-quality perovskite films. By optimizing evaporation conditions and incorporating 2,3,4,5,6-pentafluorobenzylphosphonic acid (pFBPA) during the spin-coating process, we achieved enhanced crystallization kinetics of nucleation sites and improved perovskite film uniformity. Further interface modification with pFBPA and ethane-1,2-diammonium iodide induces targeted surface dipoles at both carrier transport layers/perovskite interfaces, which not only offers better band alignment and surface passivation at both interfaces but also creates an enhanced electric field to boost electron extraction. These advancements enabled a WBG (1.68 eV) perovskite solar cell (PSC) to achieve an impressive power conversion efficiency (PCE) among WBG (1.65–1.7 eV) PSCs based on evaporation-assisted deposition. This study provides fundamental insights into achieving conformal high-quality WBG perovskite films, offering a theoretical foundation for the development of efficient perovskite/silicon tandems.","PeriodicalId":21,"journal":{"name":"ACS Nano","volume":"60 1","pages":""},"PeriodicalIF":16.0000,"publicationDate":"2025-04-14","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Controlled Nucleation and Targeted Interface Modification in Wide-Bandgap Perovskite Solar Cells Based on Evaporation/Solution Two-Step Deposition\",\"authors\":\"Yi-Peng Zhou, Liang-Xu Wang, Sheng-Chao Hui, Lin Song, Chenxin Ran, Zhongbin Wu, Wei Huang\",\"doi\":\"10.1021/acsnano.5c00458\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"Solution deposition struggles to achieve conformal and pinhole-free wide-bandgap (WBG) perovskite films on micrometer-scale textured silicon subcells due to challenges in nucleation dynamics and film uniformity, necessitating smaller textures in the efficient perovskite/silicon tandems, which compromise light trapping and current density. While evaporation-assisted two-step deposition improves conformality, it often yields films with suboptimal crystallinity and a high defect density. To address this, we elucidate the formation mechanism of CsPbI<sub><i>x</i></sub>Br<sub>3–<i>x</i></sub> nanocrystals during the thermal evaporation of PbI<sub>2</sub>/CsBr templates, which can serve as preferential nucleation sites to facilitate the growth of high-quality perovskite films. By optimizing evaporation conditions and incorporating 2,3,4,5,6-pentafluorobenzylphosphonic acid (pFBPA) during the spin-coating process, we achieved enhanced crystallization kinetics of nucleation sites and improved perovskite film uniformity. Further interface modification with pFBPA and ethane-1,2-diammonium iodide induces targeted surface dipoles at both carrier transport layers/perovskite interfaces, which not only offers better band alignment and surface passivation at both interfaces but also creates an enhanced electric field to boost electron extraction. These advancements enabled a WBG (1.68 eV) perovskite solar cell (PSC) to achieve an impressive power conversion efficiency (PCE) among WBG (1.65–1.7 eV) PSCs based on evaporation-assisted deposition. This study provides fundamental insights into achieving conformal high-quality WBG perovskite films, offering a theoretical foundation for the development of efficient perovskite/silicon tandems.\",\"PeriodicalId\":21,\"journal\":{\"name\":\"ACS Nano\",\"volume\":\"60 1\",\"pages\":\"\"},\"PeriodicalIF\":16.0000,\"publicationDate\":\"2025-04-14\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"ACS Nano\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://doi.org/10.1021/acsnano.5c00458\",\"RegionNum\":1,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Nano","FirstCategoryId":"88","ListUrlMain":"https://doi.org/10.1021/acsnano.5c00458","RegionNum":1,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

由于成核动力学和薄膜均匀性方面的挑战,溶液沉积很难在微米级纹理硅子电池上实现保形和无针孔的宽带隙(WBG)包晶石薄膜,这就需要在高效的包晶石/硅串联体中形成较小的纹理,从而影响光捕获和电流密度。蒸发辅助两步沉积法虽然能改善薄膜的一致性,但往往会产生结晶度不理想和缺陷密度较高的薄膜。为了解决这个问题,我们阐明了在 PbI2/CsBr 模板热蒸发过程中 CsPbIxBr3-x 纳米晶体的形成机制,它可以作为优先成核点,促进高质量过氧化物薄膜的生长。通过优化蒸发条件,并在旋涂过程中加入 2,3,4,5,6-五氟苄基膦酸(pFBPA),我们提高了成核点的结晶动力学,并改善了包晶薄膜的均匀性。使用 pFBPA 和碘化乙烷-1,2-二铵对界面进行进一步修饰,可在载流子传输层/包晶界面上诱导目标表面偶极子,这不仅能在两个界面上提供更好的带排列和表面钝化,还能产生增强电场以促进电子萃取。这些进步使 WBG(1.68 eV)过氧化物太阳能电池(PSC)在基于蒸发辅助沉积的 WBG(1.65-1.7 eV)PSC 中实现了惊人的功率转换效率(PCE)。这项研究为实现保形优质 WBG 包晶薄膜提供了基本见解,为开发高效的包晶/硅串联电池奠定了理论基础。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Controlled Nucleation and Targeted Interface Modification in Wide-Bandgap Perovskite Solar Cells Based on Evaporation/Solution Two-Step Deposition

Controlled Nucleation and Targeted Interface Modification in Wide-Bandgap Perovskite Solar Cells Based on Evaporation/Solution Two-Step Deposition
Solution deposition struggles to achieve conformal and pinhole-free wide-bandgap (WBG) perovskite films on micrometer-scale textured silicon subcells due to challenges in nucleation dynamics and film uniformity, necessitating smaller textures in the efficient perovskite/silicon tandems, which compromise light trapping and current density. While evaporation-assisted two-step deposition improves conformality, it often yields films with suboptimal crystallinity and a high defect density. To address this, we elucidate the formation mechanism of CsPbIxBr3–x nanocrystals during the thermal evaporation of PbI2/CsBr templates, which can serve as preferential nucleation sites to facilitate the growth of high-quality perovskite films. By optimizing evaporation conditions and incorporating 2,3,4,5,6-pentafluorobenzylphosphonic acid (pFBPA) during the spin-coating process, we achieved enhanced crystallization kinetics of nucleation sites and improved perovskite film uniformity. Further interface modification with pFBPA and ethane-1,2-diammonium iodide induces targeted surface dipoles at both carrier transport layers/perovskite interfaces, which not only offers better band alignment and surface passivation at both interfaces but also creates an enhanced electric field to boost electron extraction. These advancements enabled a WBG (1.68 eV) perovskite solar cell (PSC) to achieve an impressive power conversion efficiency (PCE) among WBG (1.65–1.7 eV) PSCs based on evaporation-assisted deposition. This study provides fundamental insights into achieving conformal high-quality WBG perovskite films, offering a theoretical foundation for the development of efficient perovskite/silicon tandems.
求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
ACS Nano
ACS Nano 工程技术-材料科学:综合
CiteScore
26.00
自引率
4.10%
发文量
1627
审稿时长
1.7 months
期刊介绍: ACS Nano, published monthly, serves as an international forum for comprehensive articles on nanoscience and nanotechnology research at the intersections of chemistry, biology, materials science, physics, and engineering. The journal fosters communication among scientists in these communities, facilitating collaboration, new research opportunities, and advancements through discoveries. ACS Nano covers synthesis, assembly, characterization, theory, and simulation of nanostructures, nanobiotechnology, nanofabrication, methods and tools for nanoscience and nanotechnology, and self- and directed-assembly. Alongside original research articles, it offers thorough reviews, perspectives on cutting-edge research, and discussions envisioning the future of nanoscience and nanotechnology.
×
