无极化碳化硅和铌酸锂光子的自发参数下转换。

IF 3.9 2区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES
Tim F Weiss, Hamed Arianfard, Yang Yang, Alberto Peruzzo
{"title":"无极化碳化硅和铌酸锂光子的自发参数下转换。","authors":"Tim F Weiss, Hamed Arianfard, Yang Yang, Alberto Peruzzo","doi":"10.1038/s41598-025-92705-2","DOIUrl":null,"url":null,"abstract":"<p><p>State-of-the-art photon sources based on spontaneous parametric down-conversion (SPDC) currently rely on artificial structuring of the material nonlinearity to satisfy phase-matching conditions. This technique, known as periodic poling, is available only in a limited number of material platforms and introduces additional fabrication steps and errors, which are detrimental to up-scaling efforts. Here, we present a device architecture that enables SPDC of a wide range of frequencies without the need for periodic poling. We present explicit designs and calculations for 4H Silicon Carbide on-insulator, in which SPDC photon generation is so far unavailable, and thin-film Lithium Niobate on-insulator, a state-of-the-art quantum photonics platform. Our design, based on mode conversion and subsequent modal phase-matched SPDC, facilitates a CMOS compatible [Formula: see text] platform, and simplifies photon sources by removing the requirement of periodic poling and the associated additional fabrication complexity.</p>","PeriodicalId":21811,"journal":{"name":"Scientific Reports","volume":"15 1","pages":"10136"},"PeriodicalIF":3.9000,"publicationDate":"2025-03-24","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11933682/pdf/","citationCount":"0","resultStr":"{\"title\":\"Spontaneous parametric down conversion without poling for silicon carbide and lithium niobate photonics.\",\"authors\":\"Tim F Weiss, Hamed Arianfard, Yang Yang, Alberto Peruzzo\",\"doi\":\"10.1038/s41598-025-92705-2\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>State-of-the-art photon sources based on spontaneous parametric down-conversion (SPDC) currently rely on artificial structuring of the material nonlinearity to satisfy phase-matching conditions. This technique, known as periodic poling, is available only in a limited number of material platforms and introduces additional fabrication steps and errors, which are detrimental to up-scaling efforts. Here, we present a device architecture that enables SPDC of a wide range of frequencies without the need for periodic poling. We present explicit designs and calculations for 4H Silicon Carbide on-insulator, in which SPDC photon generation is so far unavailable, and thin-film Lithium Niobate on-insulator, a state-of-the-art quantum photonics platform. Our design, based on mode conversion and subsequent modal phase-matched SPDC, facilitates a CMOS compatible [Formula: see text] platform, and simplifies photon sources by removing the requirement of periodic poling and the associated additional fabrication complexity.</p>\",\"PeriodicalId\":21811,\"journal\":{\"name\":\"Scientific Reports\",\"volume\":\"15 1\",\"pages\":\"10136\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2025-03-24\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11933682/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Scientific Reports\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1038/s41598-025-92705-2\",\"RegionNum\":2,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Scientific Reports","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1038/s41598-025-92705-2","RegionNum":2,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

基于自发参数下转换(SPDC)的光子源目前依赖于材料非线性的人工结构来满足相位匹配条件。这种被称为周期性极点化的技术仅适用于有限数量的材料平台,并引入了额外的制造步骤和错误,这不利于扩大规模。在这里,我们提出了一种器件架构,该架构使SPDC能够在不需要周期性轮询的情况下实现广泛的频率范围。我们提出了4H绝缘体上碳化硅的明确设计和计算,其中SPDC光子产生迄今为止是不可用的,以及薄膜铌酸锂绝缘体上,最先进的量子光子平台。我们的设计,基于模式转换和随后的模态相位匹配SPDC,促进了CMOS兼容平台,并通过消除周期性轮询的要求和相关的额外制造复杂性来简化光子源。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Spontaneous parametric down conversion without poling for silicon carbide and lithium niobate photonics.

Spontaneous parametric down conversion without poling for silicon carbide and lithium niobate photonics.

Spontaneous parametric down conversion without poling for silicon carbide and lithium niobate photonics.

Spontaneous parametric down conversion without poling for silicon carbide and lithium niobate photonics.

State-of-the-art photon sources based on spontaneous parametric down-conversion (SPDC) currently rely on artificial structuring of the material nonlinearity to satisfy phase-matching conditions. This technique, known as periodic poling, is available only in a limited number of material platforms and introduces additional fabrication steps and errors, which are detrimental to up-scaling efforts. Here, we present a device architecture that enables SPDC of a wide range of frequencies without the need for periodic poling. We present explicit designs and calculations for 4H Silicon Carbide on-insulator, in which SPDC photon generation is so far unavailable, and thin-film Lithium Niobate on-insulator, a state-of-the-art quantum photonics platform. Our design, based on mode conversion and subsequent modal phase-matched SPDC, facilitates a CMOS compatible [Formula: see text] platform, and simplifies photon sources by removing the requirement of periodic poling and the associated additional fabrication complexity.
