基于[公式:见文]的遥感多图像超分辨率研究

IF 3.9 2区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES
Wenxin Liu, Shengbing Che, Wanqin Wang, Yafei Du, Yangzhuo Tuo, Zixuan Zhang
{"title":"基于[公式:见文]的遥感多图像超分辨率研究","authors":"Wenxin Liu, Shengbing Che, Wanqin Wang, Yafei Du, Yangzhuo Tuo, Zixuan Zhang","doi":"10.1038/s41598-025-93049-7","DOIUrl":null,"url":null,"abstract":"<p><p>Remote sensing images are essential in various fields, but their high-resolution (HR) acquisition is often limited by factors such as sensor resolution and high costs. To address this challenge, we propose the Multi-image Remote Sensing Super-Resolution with Enhanced Spatio-temporal Feature Interaction Fusion Network ([Formula: see text]N). This model is a deep neural network based on end-to-end. The main innovations of the [Formula: see text]N network model include the following aspects. Firstly, through the Attention-Based Feature Encoder (ABFE) module, the spatial features of low-resolution (LR) images are precisely extracted. Combined with the Channel Attention Block (CAB) module, global information guidance and weighting are provided for the input features, effectively strengthening the spatial feature extraction capability of ABFE. Secondly, in terms of temporal feature modeling, we designed the Residual Temporal Attention Block (RTAB). This module effectively weights k LR images of the same location captured at different times via a global residual temporal connection mechanism, fully exploiting their similarities and temporal dependencies, and enhancing the cross-layer information transmission. The ConvGRU-RTAB Fusion Module (CRFM) captures the temporal features using RTAB based on ABFE and fuses the spatial and temporal features. Finally, the Decoder module enlarges the resolution of the fused features to achieve high quality super resolution image reconstruction. The comparative experiment results show that our model achieves notable improvements in the cPSNR metric, with values of 49.69 dB and 51.57 dB in the NIR and RED bands of the PROBA-V dataset, respectively. The visual quality of the reconstructed images surpasses that of state-of-the-art methods, including TR-MISR and MAST etc.</p>","PeriodicalId":21811,"journal":{"name":"Scientific Reports","volume":"15 1","pages":"9501"},"PeriodicalIF":3.9000,"publicationDate":"2025-03-19","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11923292/pdf/","citationCount":"0","resultStr":"{\"title\":\"Research on remote sensing multi-image super-resolution based on [Formula: see text]N.\",\"authors\":\"Wenxin Liu, Shengbing Che, Wanqin Wang, Yafei Du, Yangzhuo Tuo, Zixuan Zhang\",\"doi\":\"10.1038/s41598-025-93049-7\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Remote sensing images are essential in various fields, but their high-resolution (HR) acquisition is often limited by factors such as sensor resolution and high costs. To address this challenge, we propose the Multi-image Remote Sensing Super-Resolution with Enhanced Spatio-temporal Feature Interaction Fusion Network ([Formula: see text]N). This model is a deep neural network based on end-to-end. The main innovations of the [Formula: see text]N network model include the following aspects. Firstly, through the Attention-Based Feature Encoder (ABFE) module, the spatial features of low-resolution (LR) images are precisely extracted. Combined with the Channel Attention Block (CAB) module, global information guidance and weighting are provided for the input features, effectively strengthening the spatial feature extraction capability of ABFE. Secondly, in terms of temporal feature modeling, we designed the Residual Temporal Attention Block (RTAB). This module effectively weights k LR images of the same location captured at different times via a global residual temporal connection mechanism, fully exploiting their similarities and temporal dependencies, and enhancing the cross-layer information transmission. The ConvGRU-RTAB Fusion Module (CRFM) captures the temporal features using RTAB based on ABFE and fuses the spatial and temporal features. Finally, the Decoder module enlarges the resolution of the fused features to achieve high quality super resolution image reconstruction. The comparative experiment results show that our model achieves notable improvements in the cPSNR metric, with values of 49.69 dB and 51.57 dB in the NIR and RED bands of the PROBA-V dataset, respectively. The visual quality of the reconstructed images surpasses that of state-of-the-art methods, including TR-MISR and MAST etc.</p>\",\"PeriodicalId\":21811,\"journal\":{\"name\":\"Scientific Reports\",\"volume\":\"15 1\",\"pages\":\"9501\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2025-03-19\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11923292/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Scientific Reports\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1038/s41598-025-93049-7\",\"RegionNum\":2,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Scientific Reports","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1038/s41598-025-93049-7","RegionNum":2,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

遥感图像在许多领域都是必不可少的,但其高分辨率(HR)的获取往往受到传感器分辨率和高成本等因素的限制。为了解决这一挑战,我们提出了具有增强时空特征交互融合网络的多图像遥感超分辨率([公式:见文]N)。该模型是基于端到端的深度神经网络。[公式:见文]N网络模型的主要创新点包括以下几个方面。首先,通过基于注意力的特征编码器(ABFE)模块,精确提取低分辨率图像的空间特征;结合信道注意块(Channel Attention Block, CAB)模块,对输入特征进行全局信息引导和加权,有效增强了ABFE的空间特征提取能力。其次,在时间特征建模方面,设计了残余时间注意块(Residual temporal Attention Block, RTAB)。该模块通过全局残差时间连接机制,对同一位置不同时间的k幅LR图像进行有效加权,充分利用其相似性和时间依赖性,增强跨层信息传输。ConvGRU-RTAB融合模块(CRFM)利用基于ABFE的RTAB捕获时间特征,融合时空特征。最后,解码器模块对融合特征的分辨率进行放大,实现高质量的超分辨率图像重建。对比实验结果表明,我们的模型在cPSNR指标上取得了显著的改进,在PROBA-V数据集的NIR和RED波段分别达到49.69 dB和51.57 dB。重建图像的视觉质量超过了最先进的方法,包括TR-MISR和MAST等。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Research on remote sensing multi-image super-resolution based on [Formula: see text]N.

Research on remote sensing multi-image super-resolution based on [Formula: see text]N.

Research on remote sensing multi-image super-resolution based on [Formula: see text]N.

Research on remote sensing multi-image super-resolution based on [Formula: see text]N.

Remote sensing images are essential in various fields, but their high-resolution (HR) acquisition is often limited by factors such as sensor resolution and high costs. To address this challenge, we propose the Multi-image Remote Sensing Super-Resolution with Enhanced Spatio-temporal Feature Interaction Fusion Network ([Formula: see text]N). This model is a deep neural network based on end-to-end. The main innovations of the [Formula: see text]N network model include the following aspects. Firstly, through the Attention-Based Feature Encoder (ABFE) module, the spatial features of low-resolution (LR) images are precisely extracted. Combined with the Channel Attention Block (CAB) module, global information guidance and weighting are provided for the input features, effectively strengthening the spatial feature extraction capability of ABFE. Secondly, in terms of temporal feature modeling, we designed the Residual Temporal Attention Block (RTAB). This module effectively weights k LR images of the same location captured at different times via a global residual temporal connection mechanism, fully exploiting their similarities and temporal dependencies, and enhancing the cross-layer information transmission. The ConvGRU-RTAB Fusion Module (CRFM) captures the temporal features using RTAB based on ABFE and fuses the spatial and temporal features. Finally, the Decoder module enlarges the resolution of the fused features to achieve high quality super resolution image reconstruction. The comparative experiment results show that our model achieves notable improvements in the cPSNR metric, with values of 49.69 dB and 51.57 dB in the NIR and RED bands of the PROBA-V dataset, respectively. The visual quality of the reconstructed images surpasses that of state-of-the-art methods, including TR-MISR and MAST etc.
