Doaa Essam, Ashour M Ahmed, Ahmed A Abdel-Khaliek, Mohamed Shaban, Mohamed Rabia
{"title":"一锅法合成聚间甲苯胺含银和氧化银纳米复合材料作为一种极有前途的超级电容器电极。","authors":"Doaa Essam, Ashour M Ahmed, Ahmed A Abdel-Khaliek, Mohamed Shaban, Mohamed Rabia","doi":"10.1038/s41598-024-84848-5","DOIUrl":null,"url":null,"abstract":"<p><p>The design and fabrication of novel electrodes with strong electrochemical responses are crucial in advanced supercapacitor technology. In this study, a poly(m-toluidine)/silver-silver oxide (PMT/Ag-Ag<sub>2</sub>O) nanocomposite was prepared using the photopolymerization method. Various characterization techniques were employed to analyze the prepared nanomaterials. The resulting structure of Ag-Ag<sub>2</sub>O minimizes ion diffusion distances, increases active sites, and accelerates redox reactions. The electrochemical response of PMT and PMT/Ag-Ag<sub>2</sub>O electrodes was evaluated in three different electrolyte solutions (Na<sub>2</sub>SO<sub>4</sub>, H<sub>2</sub>SO<sub>4</sub>, and HCl). The specific capacitance of PMT/Ag-Ag<sub>2</sub>O nanocomposite was found to be higher than that of PMT alone. Among the tested electrolytes, HCl exhibited the highest specific capacitance of 443 F g<sup>-1</sup> at a gravimetric current density of 0.4 A g<sup>-1</sup>, surpassing H<sub>2</sub>SO<sub>4</sub> (104 F g<sup>-1</sup>) and Na<sub>2</sub>SO<sub>4</sub> (32 F g<sup>-1</sup>). Also, the PMT/Ag-Ag<sub>2</sub>O nanocomposite has demonstrated good cycling stability. It exhibited a high specific power density of 156 W Kg<sup>-1</sup> and a specific energy density of 1.8 Wh Kg<sup>-1</sup>. These results highlight the potential of the prepared PMT/Ag-Ag<sub>2</sub>O nanocomposite as a nanoelectrode material for high-performance supercapacitors.</p>","PeriodicalId":21811,"journal":{"name":"Scientific Reports","volume":"15 1","pages":"2698"},"PeriodicalIF":3.9000,"publicationDate":"2025-01-21","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11750978/pdf/","citationCount":"0","resultStr":"{\"title\":\"One pot synthesis of poly m-toluidine incorporated silver and silver oxide nanocomposite as a promising electrode for supercapacitor devices.\",\"authors\":\"Doaa Essam, Ashour M Ahmed, Ahmed A Abdel-Khaliek, Mohamed Shaban, Mohamed Rabia\",\"doi\":\"10.1038/s41598-024-84848-5\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>The design and fabrication of novel electrodes with strong electrochemical responses are crucial in advanced supercapacitor technology. In this study, a poly(m-toluidine)/silver-silver oxide (PMT/Ag-Ag<sub>2</sub>O) nanocomposite was prepared using the photopolymerization method. Various characterization techniques were employed to analyze the prepared nanomaterials. The resulting structure of Ag-Ag<sub>2</sub>O minimizes ion diffusion distances, increases active sites, and accelerates redox reactions. The electrochemical response of PMT and PMT/Ag-Ag<sub>2</sub>O electrodes was evaluated in three different electrolyte solutions (Na<sub>2</sub>SO<sub>4</sub>, H<sub>2</sub>SO<sub>4</sub>, and HCl). The specific capacitance of PMT/Ag-Ag<sub>2</sub>O nanocomposite was found to be higher than that of PMT alone. Among the tested electrolytes, HCl exhibited the highest specific capacitance of 443 F g<sup>-1</sup> at a gravimetric current density of 0.4 A g<sup>-1</sup>, surpassing H<sub>2</sub>SO<sub>4</sub> (104 F g<sup>-1</sup>) and Na<sub>2</sub>SO<sub>4</sub> (32 F g<sup>-1</sup>). Also, the PMT/Ag-Ag<sub>2</sub>O nanocomposite has demonstrated good cycling stability. It exhibited a high specific power density of 156 W Kg<sup>-1</sup> and a specific energy density of 1.8 Wh Kg<sup>-1</sup>. These results highlight the potential of the prepared PMT/Ag-Ag<sub>2</sub>O nanocomposite as a nanoelectrode material for high-performance supercapacitors.</p>\",\"PeriodicalId\":21811,\"journal\":{\"name\":\"Scientific Reports\",\"volume\":\"15 1\",\"pages\":\"2698\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2025-01-21\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11750978/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Scientific Reports\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1038/s41598-024-84848-5\",\"RegionNum\":2,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Scientific Reports","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1038/s41598-024-84848-5","RegionNum":2,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0
摘要
设计和制造具有强电化学响应的新型电极是先进超级电容器技术的关键。本研究采用光聚合法制备了聚间甲苯胺/氧化银(PMT/Ag-Ag2O)纳米复合材料。采用各种表征技术对制备的纳米材料进行了分析。Ag-Ag2O的结构减小了离子扩散距离,增加了活性位点,加速了氧化还原反应。研究了PMT和PMT/Ag-Ag2O电极在三种不同电解质溶液(Na2SO4、H2SO4和HCl)中的电化学响应。发现PMT/Ag-Ag2O纳米复合材料的比电容高于PMT单独的比电容。在重量电流密度为0.4 a g-1时,HCl的比电容最高,为443 F -1,超过H2SO4 (104 F -1)和Na2SO4 (32 F -1)。此外,PMT/Ag-Ag2O纳米复合材料具有良好的循环稳定性。其比功率密度为156 W Kg-1,比能量密度为1.8 Wh Kg-1。这些结果突出了制备的PMT/Ag-Ag2O纳米复合材料作为高性能超级电容器纳米电极材料的潜力。
One pot synthesis of poly m-toluidine incorporated silver and silver oxide nanocomposite as a promising electrode for supercapacitor devices.
The design and fabrication of novel electrodes with strong electrochemical responses are crucial in advanced supercapacitor technology. In this study, a poly(m-toluidine)/silver-silver oxide (PMT/Ag-Ag2O) nanocomposite was prepared using the photopolymerization method. Various characterization techniques were employed to analyze the prepared nanomaterials. The resulting structure of Ag-Ag2O minimizes ion diffusion distances, increases active sites, and accelerates redox reactions. The electrochemical response of PMT and PMT/Ag-Ag2O electrodes was evaluated in three different electrolyte solutions (Na2SO4, H2SO4, and HCl). The specific capacitance of PMT/Ag-Ag2O nanocomposite was found to be higher than that of PMT alone. Among the tested electrolytes, HCl exhibited the highest specific capacitance of 443 F g-1 at a gravimetric current density of 0.4 A g-1, surpassing H2SO4 (104 F g-1) and Na2SO4 (32 F g-1). Also, the PMT/Ag-Ag2O nanocomposite has demonstrated good cycling stability. It exhibited a high specific power density of 156 W Kg-1 and a specific energy density of 1.8 Wh Kg-1. These results highlight the potential of the prepared PMT/Ag-Ag2O nanocomposite as a nanoelectrode material for high-performance supercapacitors.
