基于浆岩耦合效应的深埋岩层纵向劈裂注浆。

IF 3.9 2区 综合性期刊 Q1 MULTIDISCIPLINARY SCIENCES
Liu Xiangyang, Cheng Hua, Xu Xueqing, Qian Jianyuan, Liu Wenlin
{"title":"基于浆岩耦合效应的深埋岩层纵向劈裂注浆。","authors":"Liu Xiangyang, Cheng Hua, Xu Xueqing, Qian Jianyuan, Liu Wenlin","doi":"10.1038/s41598-024-81617-2","DOIUrl":null,"url":null,"abstract":"<p><p>The coupling effect between slurry and a fractured rock layer controls the width of the fracturing channel and the grouting pressure. This effect is attenuated as the slurry diffusion front spreads from the grouting hole. This study examined the motion of slurry and the fracture expansion process, thereby establishing a longitudinal grout-splitting model of slurry-rock coupling by deriving a slurry-splitting diffusion motion equation that considers the time-varying viscosity of the slurry and attenuation of the fracture width. Research has demonstrated that in the initial stage of grouting, the plastic viscosity of the slurry is low, making grouting pressure and grouting rate the main determinants of the slurry's splitting and diffusion range, as both factors can significantly expand the diffusion range of the slurry. However, once the viscosity of the slurry exceeds a certain threshold, viscosity becomes the primary factor that restricts the diffusion range of the slurry. Therefore, when using a slurry with time-varying viscosity, a higher initial grouting rate and grouting pressure should be selected in the early stages of grouting. As the grouting pressure stabilizes, the viscosity of the slurry should be appropriately increased to enable the slurry to quickly gel and seal the fractures.</p>","PeriodicalId":21811,"journal":{"name":"Scientific Reports","volume":"14 1","pages":"30145"},"PeriodicalIF":3.9000,"publicationDate":"2024-12-03","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11615258/pdf/","citationCount":"0","resultStr":"{\"title\":\"Longitudinal splitting and grouting in deep buried rock layers based on the coupling effect between slurry and rock.\",\"authors\":\"Liu Xiangyang, Cheng Hua, Xu Xueqing, Qian Jianyuan, Liu Wenlin\",\"doi\":\"10.1038/s41598-024-81617-2\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>The coupling effect between slurry and a fractured rock layer controls the width of the fracturing channel and the grouting pressure. This effect is attenuated as the slurry diffusion front spreads from the grouting hole. This study examined the motion of slurry and the fracture expansion process, thereby establishing a longitudinal grout-splitting model of slurry-rock coupling by deriving a slurry-splitting diffusion motion equation that considers the time-varying viscosity of the slurry and attenuation of the fracture width. Research has demonstrated that in the initial stage of grouting, the plastic viscosity of the slurry is low, making grouting pressure and grouting rate the main determinants of the slurry's splitting and diffusion range, as both factors can significantly expand the diffusion range of the slurry. However, once the viscosity of the slurry exceeds a certain threshold, viscosity becomes the primary factor that restricts the diffusion range of the slurry. Therefore, when using a slurry with time-varying viscosity, a higher initial grouting rate and grouting pressure should be selected in the early stages of grouting. As the grouting pressure stabilizes, the viscosity of the slurry should be appropriately increased to enable the slurry to quickly gel and seal the fractures.</p>\",\"PeriodicalId\":21811,\"journal\":{\"name\":\"Scientific Reports\",\"volume\":\"14 1\",\"pages\":\"30145\"},\"PeriodicalIF\":3.9000,\"publicationDate\":\"2024-12-03\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11615258/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Scientific Reports\",\"FirstCategoryId\":\"103\",\"ListUrlMain\":\"https://doi.org/10.1038/s41598-024-81617-2\",\"RegionNum\":2,\"RegionCategory\":\"综合性期刊\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"MULTIDISCIPLINARY SCIENCES\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Scientific Reports","FirstCategoryId":"103","ListUrlMain":"https://doi.org/10.1038/s41598-024-81617-2","RegionNum":2,"RegionCategory":"综合性期刊","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"MULTIDISCIPLINARY SCIENCES","Score":null,"Total":0}
引用次数: 0

摘要

浆液与裂隙岩层之间的耦合作用控制着裂隙通道宽度和注浆压力。随着浆液扩散前缘从注浆孔向外扩散,这种影响逐渐减弱。本研究考察了浆液的运动和裂缝扩展过程,通过推导考虑浆液时变黏度和裂缝宽度衰减的浆液劈裂扩散运动方程,建立了浆液-岩石耦合的纵向浆液劈裂模型。研究表明,在注浆初期,浆体的塑性粘度较低,注浆压力和注浆速率是浆体劈裂扩散范围的主要决定因素,这两个因素都能显著扩大浆体的扩散范围。然而,一旦浆体粘度超过一定阈值,粘度就成为制约浆体扩散范围的首要因素。因此,在使用黏度随时间变化的浆液时,应在注浆初期选择较高的初始注浆速率和注浆压力。随着注浆压力的稳定,应适当提高浆液的粘度,使浆液迅速凝胶化,密封裂缝。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Longitudinal splitting and grouting in deep buried rock layers based on the coupling effect between slurry and rock.

Longitudinal splitting and grouting in deep buried rock layers based on the coupling effect between slurry and rock.

Longitudinal splitting and grouting in deep buried rock layers based on the coupling effect between slurry and rock.

Longitudinal splitting and grouting in deep buried rock layers based on the coupling effect between slurry and rock.

The coupling effect between slurry and a fractured rock layer controls the width of the fracturing channel and the grouting pressure. This effect is attenuated as the slurry diffusion front spreads from the grouting hole. This study examined the motion of slurry and the fracture expansion process, thereby establishing a longitudinal grout-splitting model of slurry-rock coupling by deriving a slurry-splitting diffusion motion equation that considers the time-varying viscosity of the slurry and attenuation of the fracture width. Research has demonstrated that in the initial stage of grouting, the plastic viscosity of the slurry is low, making grouting pressure and grouting rate the main determinants of the slurry's splitting and diffusion range, as both factors can significantly expand the diffusion range of the slurry. However, once the viscosity of the slurry exceeds a certain threshold, viscosity becomes the primary factor that restricts the diffusion range of the slurry. Therefore, when using a slurry with time-varying viscosity, a higher initial grouting rate and grouting pressure should be selected in the early stages of grouting. As the grouting pressure stabilizes, the viscosity of the slurry should be appropriately increased to enable the slurry to quickly gel and seal the fractures.
