卟啉敏化锌聚七嗪亚胺促进自然光催化整体水分解,量子产率5.5%。

IF 8.2 2区 材料科学 Q1 MATERIALS SCIENCE, MULTIDISCIPLINARY
ACS Applied Materials & Interfaces Pub Date : 2024-12-11 Epub Date: 2024-11-29 DOI:10.1021/acsami.4c12548
Horaţiu Szalad, Andrés Uscategui-Linares, Rodrigo García-Muelas, Alexey Galushchinskiy, Oleksandr Savateev, Markus Antonietti, Josep Albero, Hermenegildo García
{"title":"卟啉敏化锌聚七嗪亚胺促进自然光催化整体水分解,量子产率5.5%。","authors":"Horaţiu Szalad, Andrés Uscategui-Linares, Rodrigo García-Muelas, Alexey Galushchinskiy, Oleksandr Savateev, Markus Antonietti, Josep Albero, Hermenegildo García","doi":"10.1021/acsami.4c12548","DOIUrl":null,"url":null,"abstract":"<p><p><i>Meso-</i>tetrakis(4-carboxyphenyl)porphyrin (H<sub>4</sub>TCPP) has been loaded on a partially exchanged Zn<sup>2+</sup> poly(heptazine imide) (PHI), changing the light harvesting properties of the system, without altering the PHI structure. At the optimal loading (20 wt %), the photosensitized (Zn/K)-PHI is able to produce 1.06 mmol<sub>H2</sub>/g and 0.46 mmol<sub>O2</sub>/g after 12 h of reaction irradiation of Milli-Q water under visible light by a 100 mW/cm<sup>2</sup> white LED. The apparent quantum yield for the overall water splitting reaction was 5.5% at 400 nm and 2% at 700 nm. Outdoor water splitting irradiation with natural sunlight shows the feasibility of the process. The photocatalytic performance of TCPP20%@(Zn/K)-PHI is considerably higher than that of analyzed reference samples such as graphitic carbon nitride, poly(triazine imide), and potassium PHI with H<sub>4</sub>TCPP photosensitization. These relative photocatalytic activities point out the relevance of the PHI structure and the presence of Zn<sup>2+</sup>. It is proposed that Zn<sup>2+</sup> simultaneously binds PHI and H<sub>4</sub>TCPP. Transient absorption spectroscopy supports the occurrence of photoinduced electron transfer in which electrons are located at the H<sub>4</sub>TCPP and holes at the PHI moiety. Transient photocurrent measurements show a higher charge separation efficiency on TCPP20%@-(Zn/K)-PHI compared to (Zn/K)-PHI, and measurement of the frontier orbitals indicates an adequate energy alignment of the HOMO/LUMO levels of TCPP<sup>4-</sup> with respect to (Zn/K)-PHI. The results show the possibility of developing efficient noble metal-free photocatalytic systems based on PHI dye sensitization.</p>","PeriodicalId":5,"journal":{"name":"ACS Applied Materials & Interfaces","volume":" ","pages":"67597-67608"},"PeriodicalIF":8.2000,"publicationDate":"2024-12-11","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Natural Sunlight-Driven Photocatalytic Overall Water Splitting with 5.5% Quantum Yield Promoted by Porphyrin-Sensitized Zn Poly(heptazine imide).\",\"authors\":\"Horaţiu Szalad, Andrés Uscategui-Linares, Rodrigo García-Muelas, Alexey Galushchinskiy, Oleksandr Savateev, Markus Antonietti, Josep Albero, Hermenegildo García\",\"doi\":\"10.1021/acsami.4c12548\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p><i>Meso-</i>tetrakis(4-carboxyphenyl)porphyrin (H<sub>4</sub>TCPP) has been loaded on a partially exchanged Zn<sup>2+</sup> poly(heptazine imide) (PHI), changing the light harvesting properties of the system, without altering the PHI structure. At the optimal loading (20 wt %), the photosensitized (Zn/K)-PHI is able to produce 1.06 mmol<sub>H2</sub>/g and 0.46 mmol<sub>O2</sub>/g after 12 h of reaction irradiation of Milli-Q water under visible light by a 100 mW/cm<sup>2</sup> white LED. The apparent quantum yield for the overall water splitting reaction was 5.5% at 400 nm and 2% at 700 nm. Outdoor water splitting irradiation with natural sunlight shows the feasibility of the process. The photocatalytic performance of TCPP20%@(Zn/K)-PHI is considerably higher than that of analyzed reference samples such as graphitic carbon nitride, poly(triazine imide), and potassium PHI with H<sub>4</sub>TCPP photosensitization. These relative photocatalytic activities point out the relevance of the PHI structure and the presence of Zn<sup>2+</sup>. It is proposed that Zn<sup>2+</sup> simultaneously binds PHI and H<sub>4</sub>TCPP. Transient absorption spectroscopy supports the occurrence of photoinduced electron transfer in which electrons are located at the H<sub>4</sub>TCPP and holes at the PHI moiety. Transient photocurrent measurements show a higher charge separation efficiency on TCPP20%@-(Zn/K)-PHI compared to (Zn/K)-PHI, and measurement of the frontier orbitals indicates an adequate energy alignment of the HOMO/LUMO levels of TCPP<sup>4-</sup> with respect to (Zn/K)-PHI. The results show the possibility of developing efficient noble metal-free photocatalytic systems based on PHI dye sensitization.</p>\",\"PeriodicalId\":5,\"journal\":{\"name\":\"ACS Applied Materials & Interfaces\",\"volume\":\" \",\"pages\":\"67597-67608\"},\"PeriodicalIF\":8.2000,\"publicationDate\":\"2024-12-11\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"ACS Applied Materials & Interfaces\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://doi.org/10.1021/acsami.4c12548\",\"RegionNum\":2,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"2024/11/29 0:00:00\",\"PubModel\":\"Epub\",\"JCR\":\"Q1\",\"JCRName\":\"MATERIALS SCIENCE, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Applied Materials & Interfaces","FirstCategoryId":"88","ListUrlMain":"https://doi.org/10.1021/acsami.4c12548","RegionNum":2,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2024/11/29 0:00:00","PubModel":"Epub","JCR":"Q1","JCRName":"MATERIALS SCIENCE, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

将中四(4-羧基苯基)卟啉(H4TCPP)负载在部分交换的Zn2+聚七嗪酰亚胺(PHI)上,在不改变PHI结构的情况下改变了体系的光捕获性能。在最佳负载(20 wt %)下,光敏化(Zn/K)-PHI在100 mW/cm2白光LED的可见光下,经过mil - q水12 h的反应照射,能产生1.06 mmmolh2 /g和0.46 mmmolo2 /g。整个水裂解反应的表观量子产率在400 nm为5.5%,在700 nm为2%。室外自然光裂解水辐照试验表明了该工艺的可行性。TCPP20%@(Zn/K)-PHI的光催化性能明显高于所分析的参考样品,如石墨氮化碳、聚三嗪亚胺和具有H4TCPP光敏性的PHI钾。这些相对光催化活性表明了PHI结构与Zn2+存在的相关性。提出Zn2+可以同时结合PHI和H4TCPP。瞬态吸收光谱支持光致电子转移的发生,其中电子位于H4TCPP,空穴位于PHI部分。瞬态光电流测量表明,与(Zn/K)- phi相比,TCPP4- 20%@-(Zn/K)- phi上的电荷分离效率更高,前沿轨道测量表明TCPP4-相对于(Zn/K)- phi有足够的HOMO/LUMO能级的能量排列。结果表明,基于PHI染料敏化技术开发高效的无贵金属光催化体系是可能的。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Natural Sunlight-Driven Photocatalytic Overall Water Splitting with 5.5% Quantum Yield Promoted by Porphyrin-Sensitized Zn Poly(heptazine imide).

Natural Sunlight-Driven Photocatalytic Overall Water Splitting with 5.5% Quantum Yield Promoted by Porphyrin-Sensitized Zn Poly(heptazine imide).

Meso-tetrakis(4-carboxyphenyl)porphyrin (H4TCPP) has been loaded on a partially exchanged Zn2+ poly(heptazine imide) (PHI), changing the light harvesting properties of the system, without altering the PHI structure. At the optimal loading (20 wt %), the photosensitized (Zn/K)-PHI is able to produce 1.06 mmolH2/g and 0.46 mmolO2/g after 12 h of reaction irradiation of Milli-Q water under visible light by a 100 mW/cm2 white LED. The apparent quantum yield for the overall water splitting reaction was 5.5% at 400 nm and 2% at 700 nm. Outdoor water splitting irradiation with natural sunlight shows the feasibility of the process. The photocatalytic performance of TCPP20%@(Zn/K)-PHI is considerably higher than that of analyzed reference samples such as graphitic carbon nitride, poly(triazine imide), and potassium PHI with H4TCPP photosensitization. These relative photocatalytic activities point out the relevance of the PHI structure and the presence of Zn2+. It is proposed that Zn2+ simultaneously binds PHI and H4TCPP. Transient absorption spectroscopy supports the occurrence of photoinduced electron transfer in which electrons are located at the H4TCPP and holes at the PHI moiety. Transient photocurrent measurements show a higher charge separation efficiency on TCPP20%@-(Zn/K)-PHI compared to (Zn/K)-PHI, and measurement of the frontier orbitals indicates an adequate energy alignment of the HOMO/LUMO levels of TCPP4- with respect to (Zn/K)-PHI. The results show the possibility of developing efficient noble metal-free photocatalytic systems based on PHI dye sensitization.
