垂直石墨烯纳米片上锚定 CoFe-LDH 的 Pr6O11 簇作为氧进化电催化剂用于长期高电流密度海水电解

IF 9.5 2区 材料科学 Q1 CHEMISTRY, PHYSICAL
Quan Wu, Xiaoyu Dong, Kefeng Ouyang, Youfa Liu, Hao Lei, Jie Yu and Yan Huang
{"title":"垂直石墨烯纳米片上锚定 CoFe-LDH 的 Pr6O11 簇作为氧进化电催化剂用于长期高电流密度海水电解","authors":"Quan Wu, Xiaoyu Dong, Kefeng Ouyang, Youfa Liu, Hao Lei, Jie Yu and Yan Huang","doi":"10.1039/D4TA07515C","DOIUrl":null,"url":null,"abstract":"<p >The severe catalyst corrosion caused by chlorides and industrial-scale high current density are two critical issues for seawater electrolysis that need to be solved. Herein, due to the high adsorption energy of Cl and the stabilizing effect of Pr<small><sub>6</sub></small>O<small><sub>11</sub></small> on OER active species, our prepared material (named GP/VGSs-CoFe LDH-Pr<small><sub>6</sub></small>O<small><sub>11</sub></small>) has excellent OER catalytic activity, achieving 2 A cm<small><sup>−2</sup></small> at an overpotential of only 466 mV in alkaline seawater. The electrolysis cell NiMoN‖GP/VGSs-CoFe LDH-Pr<small><sub>6</sub></small>O<small><sub>11</sub></small> delivers 326 mA cm<small><sup>−2</sup></small> and 585 mA cm<small><sup>−2</sup></small> at 1.7 V and 1.8 V in alkaline seawater, respectively. With the aid of anti-corrosion agent K<small><sub>2</sub></small>SO<small><sub>4</sub></small>, the cell further achieves a long-term stability of 380 h (180 h) at a high current density of 600 mA cm<small><sup>−2</sup></small> (1 A cm<small><sup>−2</sup></small>) in alkaline seawater. This work provides a new insight into designing non-noble-metal-based catalysts for stable high-current-density seawater electrolysis, which exhibits great potential in large-scale industrial hydrogen production.</p>","PeriodicalId":82,"journal":{"name":"Journal of Materials Chemistry A","volume":" 4","pages":" 2583-2589"},"PeriodicalIF":9.5000,"publicationDate":"2024-11-26","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Pr6O11 cluster-anchored CoFe-LDH on vertical graphene nanosheets as an oxygen evolution electrocatalyst for long-term high-current-density seawater electrolysis†\",\"authors\":\"Quan Wu, Xiaoyu Dong, Kefeng Ouyang, Youfa Liu, Hao Lei, Jie Yu and Yan Huang\",\"doi\":\"10.1039/D4TA07515C\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >The severe catalyst corrosion caused by chlorides and industrial-scale high current density are two critical issues for seawater electrolysis that need to be solved. Herein, due to the high adsorption energy of Cl and the stabilizing effect of Pr<small><sub>6</sub></small>O<small><sub>11</sub></small> on OER active species, our prepared material (named GP/VGSs-CoFe LDH-Pr<small><sub>6</sub></small>O<small><sub>11</sub></small>) has excellent OER catalytic activity, achieving 2 A cm<small><sup>−2</sup></small> at an overpotential of only 466 mV in alkaline seawater. The electrolysis cell NiMoN‖GP/VGSs-CoFe LDH-Pr<small><sub>6</sub></small>O<small><sub>11</sub></small> delivers 326 mA cm<small><sup>−2</sup></small> and 585 mA cm<small><sup>−2</sup></small> at 1.7 V and 1.8 V in alkaline seawater, respectively. With the aid of anti-corrosion agent K<small><sub>2</sub></small>SO<small><sub>4</sub></small>, the cell further achieves a long-term stability of 380 h (180 h) at a high current density of 600 mA cm<small><sup>−2</sup></small> (1 A cm<small><sup>−2</sup></small>) in alkaline seawater. This work provides a new insight into designing non-noble-metal-based catalysts for stable high-current-density seawater electrolysis, which exhibits great potential in large-scale industrial hydrogen production.</p>\",\"PeriodicalId\":82,\"journal\":{\"name\":\"Journal of Materials Chemistry A\",\"volume\":\" 4\",\"pages\":\" 2583-2589\"},\"PeriodicalIF\":9.5000,\"publicationDate\":\"2024-11-26\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Journal of Materials Chemistry A\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://pubs.rsc.org/en/content/articlelanding/2025/ta/d4ta07515c\",\"RegionNum\":2,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, PHYSICAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Journal of Materials Chemistry A","FirstCategoryId":"88","ListUrlMain":"https://pubs.rsc.org/en/content/articlelanding/2025/ta/d4ta07515c","RegionNum":2,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, PHYSICAL","Score":null,"Total":0}
引用次数: 0

摘要

氯化物对催化剂的严重腐蚀以及工业规模的高电流密度是海水电解亟待解决的两个关键问题。在此,由于 Cl 的高吸附能和 Pr6O11 对 OER 活性物种的稳定作用,我们制备的材料(命名为 GP/VGSs-CoFe LDH-Pr6O11)具有优异的 OER 催化活性,在碱性海水中仅需 466 mV 的过电位即可达到 2 A/cm2 的催化活性。电解池 NiMoN||GP/VGSs-CoFe LDH-Pr6O11 在碱性海水中的电压分别为 1.7 V 和 1.8 V 时,输出电流分别为 326 mA/cm2 和 585 mA/cm2。借助 K2SO4 防腐剂,该电池在碱性海水中 600 mA/cm2(1 A/cm2)的高电流密度下,进一步实现了 380 小时(180 小时)的长期稳定性。这项工作为设计非贵金属基催化剂用于稳定的高电流密度海水电解提供了新的见解,在大规模工业制氢方面具有巨大潜力。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Pr6O11 cluster-anchored CoFe-LDH on vertical graphene nanosheets as an oxygen evolution electrocatalyst for long-term high-current-density seawater electrolysis†

Pr6O11 cluster-anchored CoFe-LDH on vertical graphene nanosheets as an oxygen evolution electrocatalyst for long-term high-current-density seawater electrolysis†

The severe catalyst corrosion caused by chlorides and industrial-scale high current density are two critical issues for seawater electrolysis that need to be solved. Herein, due to the high adsorption energy of Cl and the stabilizing effect of Pr6O11 on OER active species, our prepared material (named GP/VGSs-CoFe LDH-Pr6O11) has excellent OER catalytic activity, achieving 2 A cm−2 at an overpotential of only 466 mV in alkaline seawater. The electrolysis cell NiMoN‖GP/VGSs-CoFe LDH-Pr6O11 delivers 326 mA cm−2 and 585 mA cm−2 at 1.7 V and 1.8 V in alkaline seawater, respectively. With the aid of anti-corrosion agent K2SO4, the cell further achieves a long-term stability of 380 h (180 h) at a high current density of 600 mA cm−2 (1 A cm−2) in alkaline seawater. This work provides a new insight into designing non-noble-metal-based catalysts for stable high-current-density seawater electrolysis, which exhibits great potential in large-scale industrial hydrogen production.
