Jingkai Liu, Yunyun Xiao, Yiqing Wang, Yishun Wuliu, Xinbei Zhu, Liyue Zhang and Xiaoqing Liu
{"title":"通过高温触发的交联反应实现有机相变复合材料优异的内在阻燃性。","authors":"Jingkai Liu, Yunyun Xiao, Yiqing Wang, Yishun Wuliu, Xinbei Zhu, Liyue Zhang and Xiaoqing Liu","doi":"10.1039/D4MH00831F","DOIUrl":null,"url":null,"abstract":"<p >The host–guest composite that integrates a porous scaffold and organic phase change materials (PCMs) features high energy density and customizable function, promising for advanced thermal storage/utilization. However, highly flammable organic PCMs are prone to severe combustion in porous structures, making it challenging for traditional flame-retardant methods to balance fire safety and latent heat. Herein, a high-temperature-triggered crosslinking reaction between the host and guest is designed using a polybenzoxazine-based aerogel (PB-1) and benzoxazine-based PCMs (C-dad). At high temperatures, the ring-opening polymerization (ROP) of C-dad can be initiated by and reacted with the phenolic groups of PB-1 to form a polybenzoxazine copolymer monolith with an improved char yield and intrinsic low flammability and without using the typical flame-retardant components. This enables the obtained composite (PB-1/C-dad) to well balance latent heat (145.3 J g<small><sup>−1</sup></small>), char yield (a char residue of 13.1% at 600 °C), and flame retardancy (a peak heat release rate of 231 W g<small><sup>−1</sup></small>), outperforming the representative flame-retardant modified polymer/organic PCM complexes reported in the literature. This thermal-triggered mechanism allows PB-1/C-dad to be repeatedly and stably used within the working temperature and activates its flame retardancy when exposed to open flames. The proposed host–guest crosslinking strategy is believed to inspire the development of inherently nonflammable phase change composites for safer thermal management.</p>","PeriodicalId":87,"journal":{"name":"Materials Horizons","volume":" 21","pages":" 5274-5284"},"PeriodicalIF":10.7000,"publicationDate":"2024-08-14","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"A high-temperature-triggered crosslinking reaction to achieve excellent intrinsic flame retardancy of organic phase change composites†\",\"authors\":\"Jingkai Liu, Yunyun Xiao, Yiqing Wang, Yishun Wuliu, Xinbei Zhu, Liyue Zhang and Xiaoqing Liu\",\"doi\":\"10.1039/D4MH00831F\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >The host–guest composite that integrates a porous scaffold and organic phase change materials (PCMs) features high energy density and customizable function, promising for advanced thermal storage/utilization. However, highly flammable organic PCMs are prone to severe combustion in porous structures, making it challenging for traditional flame-retardant methods to balance fire safety and latent heat. Herein, a high-temperature-triggered crosslinking reaction between the host and guest is designed using a polybenzoxazine-based aerogel (PB-1) and benzoxazine-based PCMs (C-dad). At high temperatures, the ring-opening polymerization (ROP) of C-dad can be initiated by and reacted with the phenolic groups of PB-1 to form a polybenzoxazine copolymer monolith with an improved char yield and intrinsic low flammability and without using the typical flame-retardant components. This enables the obtained composite (PB-1/C-dad) to well balance latent heat (145.3 J g<small><sup>−1</sup></small>), char yield (a char residue of 13.1% at 600 °C), and flame retardancy (a peak heat release rate of 231 W g<small><sup>−1</sup></small>), outperforming the representative flame-retardant modified polymer/organic PCM complexes reported in the literature. This thermal-triggered mechanism allows PB-1/C-dad to be repeatedly and stably used within the working temperature and activates its flame retardancy when exposed to open flames. The proposed host–guest crosslinking strategy is believed to inspire the development of inherently nonflammable phase change composites for safer thermal management.</p>\",\"PeriodicalId\":87,\"journal\":{\"name\":\"Materials Horizons\",\"volume\":\" 21\",\"pages\":\" 5274-5284\"},\"PeriodicalIF\":10.7000,\"publicationDate\":\"2024-08-14\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Materials Horizons\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://pubs.rsc.org/en/content/articlelanding/2024/mh/d4mh00831f\",\"RegionNum\":2,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Materials Horizons","FirstCategoryId":"88","ListUrlMain":"https://pubs.rsc.org/en/content/articlelanding/2024/mh/d4mh00831f","RegionNum":2,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0
摘要
将多孔支架和有机相变材料(PCM)整合在一起的主客复合材料具有高能量密度和可定制功能,有望实现先进的热存储/利用。然而,高易燃性有机相变材料在多孔结构中容易发生严重燃烧,这使得传统的阻燃方法难以兼顾防火安全和潜热。在此,我们利用聚苯并恶嗪气凝胶(PB-1)和苯并恶嗪基 PCM(C-dad)设计了一种主客体之间的高温触发交联反应。在高温条件下,C-dad 的开环聚合(ROP)可由 PB-1 的酚基引发并与之反应,形成聚苯并恶嗪共聚物单体,该单体具有更高的炭化率和内在低可燃性,且无需使用典型的阻燃剂成分。这使得获得的复合材料(PB-1/C-dad)能够很好地平衡潜热(145.3 J g-1)、产炭率(600 °C 时的残炭率为 13.1%)和阻燃性(峰值热释放率为 231 W g-1),优于文献中报道的具有代表性的阻燃改性聚合物/有机 PCM 复合物。这种热触发机制允许 PB-1/C-dad 在工作温度内反复稳定地使用,并在暴露于明火时激活其阻燃性。相信所提出的主客体交联策略将有助于开发本质上不可燃的相变复合材料,从而实现更安全的热管理。
A high-temperature-triggered crosslinking reaction to achieve excellent intrinsic flame retardancy of organic phase change composites†
The host–guest composite that integrates a porous scaffold and organic phase change materials (PCMs) features high energy density and customizable function, promising for advanced thermal storage/utilization. However, highly flammable organic PCMs are prone to severe combustion in porous structures, making it challenging for traditional flame-retardant methods to balance fire safety and latent heat. Herein, a high-temperature-triggered crosslinking reaction between the host and guest is designed using a polybenzoxazine-based aerogel (PB-1) and benzoxazine-based PCMs (C-dad). At high temperatures, the ring-opening polymerization (ROP) of C-dad can be initiated by and reacted with the phenolic groups of PB-1 to form a polybenzoxazine copolymer monolith with an improved char yield and intrinsic low flammability and without using the typical flame-retardant components. This enables the obtained composite (PB-1/C-dad) to well balance latent heat (145.3 J g−1), char yield (a char residue of 13.1% at 600 °C), and flame retardancy (a peak heat release rate of 231 W g−1), outperforming the representative flame-retardant modified polymer/organic PCM complexes reported in the literature. This thermal-triggered mechanism allows PB-1/C-dad to be repeatedly and stably used within the working temperature and activates its flame retardancy when exposed to open flames. The proposed host–guest crosslinking strategy is believed to inspire the development of inherently nonflammable phase change composites for safer thermal management.
