通过改变柔性超表面的图案大小、形状和深度来控制可见光范围内的透射和反射雾度。

IF 4.1 3区 工程技术 Q2 ENGINEERING, ELECTRICAL & ELECTRONIC
Avijit Maity, Vaswati Biswas, R Vijaya
{"title":"通过改变柔性超表面的图案大小、形状和深度来控制可见光范围内的透射和反射雾度。","authors":"Avijit Maity, Vaswati Biswas, R Vijaya","doi":"10.1007/s12200-024-00125-3","DOIUrl":null,"url":null,"abstract":"<p><p>Cost-effective soft imprint lithography technique is used to prepare flexible thin polymeric surfaces containing a periodic arrangement of nanodimples and nanobumps of sub-micron size. Using a single master mold of self-assembled colloidal crystal, metasurfaces with different depths and heights of patterns with a fixed pitch are possible, which makes the process inexpensive and simple. These metasurfaces are studied for their diffuse and total transmission and reflection spectra in the visible range. The transmission haze and reflection haze are calculated from the measurements. The surface containing nanobumps of lesser pattern height result in higher values of reflection and transmission haze than from surfaces containing nanodimples of much higher depth for the same pitch. The haze is more dependent on the pattern depth or height and less dependent on the pitch of the pattern. Far-field transmission profiles measured in the same wavelength range from the patterned surfaces show that the scattering increases with the increase of the ratio of pattern depth/height to pitch, similar to the haze measurements conducted with a closed integrating sphere. These profiles show that the angular spread of scattered light in transmission is within 10°, explaining the reason for the relatively low transmission haze in all the patterned surfaces. Simulation results confirm that the nanobump pattern gives higher transmission haze compared to nanodimple pattern. By controlling the ratio of pattern depth/height to pitch of the features on these surfaces, both an increase in optical haze and a balance between total reflection intensity and total transmission intensity can be achieved.</p>","PeriodicalId":12685,"journal":{"name":"Frontiers of Optoelectronics","volume":null,"pages":null},"PeriodicalIF":4.1000,"publicationDate":"2024-07-30","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11289189/pdf/","citationCount":"0","resultStr":"{\"title\":\"Control of visible-range transmission and reflection haze by varying pattern size, shape and depth in flexible metasurfaces.\",\"authors\":\"Avijit Maity, Vaswati Biswas, R Vijaya\",\"doi\":\"10.1007/s12200-024-00125-3\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Cost-effective soft imprint lithography technique is used to prepare flexible thin polymeric surfaces containing a periodic arrangement of nanodimples and nanobumps of sub-micron size. Using a single master mold of self-assembled colloidal crystal, metasurfaces with different depths and heights of patterns with a fixed pitch are possible, which makes the process inexpensive and simple. These metasurfaces are studied for their diffuse and total transmission and reflection spectra in the visible range. The transmission haze and reflection haze are calculated from the measurements. The surface containing nanobumps of lesser pattern height result in higher values of reflection and transmission haze than from surfaces containing nanodimples of much higher depth for the same pitch. The haze is more dependent on the pattern depth or height and less dependent on the pitch of the pattern. Far-field transmission profiles measured in the same wavelength range from the patterned surfaces show that the scattering increases with the increase of the ratio of pattern depth/height to pitch, similar to the haze measurements conducted with a closed integrating sphere. These profiles show that the angular spread of scattered light in transmission is within 10°, explaining the reason for the relatively low transmission haze in all the patterned surfaces. Simulation results confirm that the nanobump pattern gives higher transmission haze compared to nanodimple pattern. By controlling the ratio of pattern depth/height to pitch of the features on these surfaces, both an increase in optical haze and a balance between total reflection intensity and total transmission intensity can be achieved.</p>\",\"PeriodicalId\":12685,\"journal\":{\"name\":\"Frontiers of Optoelectronics\",\"volume\":null,\"pages\":null},\"PeriodicalIF\":4.1000,\"publicationDate\":\"2024-07-30\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11289189/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Frontiers of Optoelectronics\",\"FirstCategoryId\":\"5\",\"ListUrlMain\":\"https://doi.org/10.1007/s12200-024-00125-3\",\"RegionNum\":3,\"RegionCategory\":\"工程技术\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"ENGINEERING, ELECTRICAL & ELECTRONIC\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Frontiers of Optoelectronics","FirstCategoryId":"5","ListUrlMain":"https://doi.org/10.1007/s12200-024-00125-3","RegionNum":3,"RegionCategory":"工程技术","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"ENGINEERING, ELECTRICAL & ELECTRONIC","Score":null,"Total":0}
引用次数: 0

摘要

本研究利用经济高效的软压印光刻技术制备了柔性薄聚合物表面,该表面含有周期性排列的亚微米级纳米微粒和纳米凸点。利用自组装胶体晶体的单个母模,可以制备出具有不同深度和高度的固定间距图案的元表面,从而使制备过程既便宜又简单。我们研究了这些元表面在可见光范围内的漫反射、全透射和反射光谱。根据测量结果计算出透射雾度和反射雾度。在相同间距下,含有图案高度较小的纳米凸点的表面,其反射雾度和透射雾度的值要高于含有深度较大的纳米凹点的表面。雾度与图案深度或高度的关系较大,而与图案间距的关系较小。在相同波长范围内从图案表面测量的远场透射曲线显示,散射随图案深度/高度与间距之比增加而增加,这与使用封闭积分球进行的雾度测量类似。这些剖面图显示,透射散射光的角度散布在 10° 以内,这就解释了所有图案表面透射雾度相对较低的原因。模拟结果证实,纳米凸点图案比纳米简单图案的透射雾度更高。通过控制这些表面的图案深度/高度与特征间距之比,既能增加光学雾度,又能实现总反射强度与总透射强度之间的平衡。
本文章由计算机程序翻译,如有差异,请以英文原文为准。
Control of visible-range transmission and reflection haze by varying pattern size, shape and depth in flexible metasurfaces.

Cost-effective soft imprint lithography technique is used to prepare flexible thin polymeric surfaces containing a periodic arrangement of nanodimples and nanobumps of sub-micron size. Using a single master mold of self-assembled colloidal crystal, metasurfaces with different depths and heights of patterns with a fixed pitch are possible, which makes the process inexpensive and simple. These metasurfaces are studied for their diffuse and total transmission and reflection spectra in the visible range. The transmission haze and reflection haze are calculated from the measurements. The surface containing nanobumps of lesser pattern height result in higher values of reflection and transmission haze than from surfaces containing nanodimples of much higher depth for the same pitch. The haze is more dependent on the pattern depth or height and less dependent on the pitch of the pattern. Far-field transmission profiles measured in the same wavelength range from the patterned surfaces show that the scattering increases with the increase of the ratio of pattern depth/height to pitch, similar to the haze measurements conducted with a closed integrating sphere. These profiles show that the angular spread of scattered light in transmission is within 10°, explaining the reason for the relatively low transmission haze in all the patterned surfaces. Simulation results confirm that the nanobump pattern gives higher transmission haze compared to nanodimple pattern. By controlling the ratio of pattern depth/height to pitch of the features on these surfaces, both an increase in optical haze and a balance between total reflection intensity and total transmission intensity can be achieved.
