共溶剂占有溶解调谐抗氧化疗法实现高度安全的 4.7V 级 NCM811 电池

IF 30.8 1区 材料科学 Q1 CHEMISTRY, MULTIDISCIPLINARY
Yuqing Chen, Yun Zhao, Aiping Wang, Daozhen Zhang, Baohua Li, Xiangming He, Xiulin Fan and Jilei Liu
{"title":"共溶剂占有溶解调谐抗氧化疗法实现高度安全的 4.7V 级 NCM811 电池","authors":"Yuqing Chen, Yun Zhao, Aiping Wang, Daozhen Zhang, Baohua Li, Xiangming He, Xiulin Fan and Jilei Liu","doi":"10.1039/D4EE02074J","DOIUrl":null,"url":null,"abstract":"<p >Fluorinated electrolytes are promising for stabilizing the interfacial chemistry in high-voltage LiNi<small><sub>0.8</sub></small>Co<small><sub>0.1</sub></small>Mn<small><sub>0.1</sub></small>O<small><sub>2</sub></small> (NCM811) batteries. However, the design of previous fluorinated electrolytes overlooked the essential role of the cathode–electrolyte interface (CEI) on de-solvation, relying heavily on weak solvation. Theoretically, the cosolvent occupied solvation structure characteristic of the highly antioxidative cosolvent and the easily oxidized salt additive in the first solvation shell is highly desirable to both widen the electrochemical window and promote the anion-enriched CEI to facilitate de-solvation. The key challenges lie in identifying ideal cosolvents that are highly polar, antioxidative, and have a stronger interaction with anions, to replace the solvation site of the main solvents without oxidation of itself and promote the oxidation of additive anions. Herein sulfone (SL) and DFOB<small><sup>−</sup></small> are screened out following developed rules, and the interaction relationships are: (i) Li<small><sup>+</sup></small>–cosolvent &gt; Li<small><sup>+</sup></small>–main solvent; (ii) DFOB<small><sup>−</sup></small>–cosolvent &gt; DFOB<small><sup>−</sup></small>–main solvent; (iii) DFOB<small><sup>−</sup></small>–cosolvent &gt; DFOB<small><sup>−</sup></small>–Li<small><sup>+</sup></small>. And an optimized fluorinated electrolyte composed of 10% SL and 0.02 M LiDFOB is therefore successfully developed. This occupied solvation design promotes both interfacial/anodic stability and de-solvation under an aggressive 4.7 V. Consequently, ∼400 W h kg<small><sup>−1</sup></small> NCM811/Li cells at 4.7 V demonstrate an 82% capacity retention after 200 cycles. Commercial NCM811/Gr pouch cells at 4.5 V achieve 92% capacity retention over 500 cycles, concurrently with unexpectedly high safety performance in terms of thermal, mechanical, and electrical abuse. This work underscores the critical impact of solvation site-occupied cosolvent on the CEI modification and kinetics optimization, opening a new avenue for high voltage electrolyte design.</p>","PeriodicalId":72,"journal":{"name":"Energy & Environmental Science","volume":" 16","pages":" 6113-6126"},"PeriodicalIF":30.8000,"publicationDate":"2024-07-18","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Cosolvent occupied solvation tuned anti-oxidation therapy toward highly safe 4.7 V-class NCM811 batteries†\",\"authors\":\"Yuqing Chen, Yun Zhao, Aiping Wang, Daozhen Zhang, Baohua Li, Xiangming He, Xiulin Fan and Jilei Liu\",\"doi\":\"10.1039/D4EE02074J\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >Fluorinated electrolytes are promising for stabilizing the interfacial chemistry in high-voltage LiNi<small><sub>0.8</sub></small>Co<small><sub>0.1</sub></small>Mn<small><sub>0.1</sub></small>O<small><sub>2</sub></small> (NCM811) batteries. However, the design of previous fluorinated electrolytes overlooked the essential role of the cathode–electrolyte interface (CEI) on de-solvation, relying heavily on weak solvation. Theoretically, the cosolvent occupied solvation structure characteristic of the highly antioxidative cosolvent and the easily oxidized salt additive in the first solvation shell is highly desirable to both widen the electrochemical window and promote the anion-enriched CEI to facilitate de-solvation. The key challenges lie in identifying ideal cosolvents that are highly polar, antioxidative, and have a stronger interaction with anions, to replace the solvation site of the main solvents without oxidation of itself and promote the oxidation of additive anions. Herein sulfone (SL) and DFOB<small><sup>−</sup></small> are screened out following developed rules, and the interaction relationships are: (i) Li<small><sup>+</sup></small>–cosolvent &gt; Li<small><sup>+</sup></small>–main solvent; (ii) DFOB<small><sup>−</sup></small>–cosolvent &gt; DFOB<small><sup>−</sup></small>–main solvent; (iii) DFOB<small><sup>−</sup></small>–cosolvent &gt; DFOB<small><sup>−</sup></small>–Li<small><sup>+</sup></small>. And an optimized fluorinated electrolyte composed of 10% SL and 0.02 M LiDFOB is therefore successfully developed. This occupied solvation design promotes both interfacial/anodic stability and de-solvation under an aggressive 4.7 V. Consequently, ∼400 W h kg<small><sup>−1</sup></small> NCM811/Li cells at 4.7 V demonstrate an 82% capacity retention after 200 cycles. Commercial NCM811/Gr pouch cells at 4.5 V achieve 92% capacity retention over 500 cycles, concurrently with unexpectedly high safety performance in terms of thermal, mechanical, and electrical abuse. This work underscores the critical impact of solvation site-occupied cosolvent on the CEI modification and kinetics optimization, opening a new avenue for high voltage electrolyte design.</p>\",\"PeriodicalId\":72,\"journal\":{\"name\":\"Energy & Environmental Science\",\"volume\":\" 16\",\"pages\":\" 6113-6126\"},\"PeriodicalIF\":30.8000,\"publicationDate\":\"2024-07-18\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Energy & Environmental Science\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://pubs.rsc.org/en/content/articlelanding/2024/ee/d4ee02074j\",\"RegionNum\":1,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q1\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Energy & Environmental Science","FirstCategoryId":"88","ListUrlMain":"https://pubs.rsc.org/en/content/articlelanding/2024/ee/d4ee02074j","RegionNum":1,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

氟化电解质有望稳定高压镍钴锰锂电池(NCM811)的界面化学。然而,以往的含氟电解质忽视了阴极-电解质界面(CEI)对去溶解的重要作用,而严重依赖于弱溶解。从理论上讲,具有高抗氧化性的共溶剂和第一溶壳中易氧化的盐添加剂所构成的共溶剂占位溶解结构是非常理想的,既能拓宽电化学窗口,又能促进阴离子富集的阴极-电解质界面(CEI),从而促进去溶解。关键的挑战在于找到极性强、抗氧化、与阴离子相互作用更强的理想助溶剂,以取代主溶剂的溶解位点而不使其本身氧化,并促进添加剂阴离子的氧化。在此,根据制定的规则筛选出砜(SL)和 DFOB-,其相互作用关系为:i) Li+ - 助溶剂 > Li+ - 主溶剂;ii) DFOB- - 助溶剂 > DFOB- - 主溶剂;iii) DFOB- - 助溶剂 > DFOB- - Li+。因此,由 10% SL 和 0.02 M LiDFOB 组成的优化含氟电解质研制成功。这种占位溶解设计既能提高界面/阳极稳定性,又能在苛刻的 4.7 V 电压下去溶解。因此,在 4.7 V 电压下,约 400 Wh kg-1 的 NCM811/Li 电池在 200 次循环后显示出 82% 的容量保持率。4.5 V 的商用 NCM811/Gr 袋式电池在 500 次循环后的容量保持率达到 92%,同时在热滥用、机械滥用和电气滥用方面具有出乎意料的高安全性能。这项工作强调了溶解位点共溶剂对 CEI 改性和动力学优化的关键影响,为高压电解液的设计开辟了一条新途径。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Cosolvent occupied solvation tuned anti-oxidation therapy toward highly safe 4.7 V-class NCM811 batteries†

Cosolvent occupied solvation tuned anti-oxidation therapy toward highly safe 4.7 V-class NCM811 batteries†

Fluorinated electrolytes are promising for stabilizing the interfacial chemistry in high-voltage LiNi0.8Co0.1Mn0.1O2 (NCM811) batteries. However, the design of previous fluorinated electrolytes overlooked the essential role of the cathode–electrolyte interface (CEI) on de-solvation, relying heavily on weak solvation. Theoretically, the cosolvent occupied solvation structure characteristic of the highly antioxidative cosolvent and the easily oxidized salt additive in the first solvation shell is highly desirable to both widen the electrochemical window and promote the anion-enriched CEI to facilitate de-solvation. The key challenges lie in identifying ideal cosolvents that are highly polar, antioxidative, and have a stronger interaction with anions, to replace the solvation site of the main solvents without oxidation of itself and promote the oxidation of additive anions. Herein sulfone (SL) and DFOB are screened out following developed rules, and the interaction relationships are: (i) Li+–cosolvent > Li+–main solvent; (ii) DFOB–cosolvent > DFOB–main solvent; (iii) DFOB–cosolvent > DFOB–Li+. And an optimized fluorinated electrolyte composed of 10% SL and 0.02 M LiDFOB is therefore successfully developed. This occupied solvation design promotes both interfacial/anodic stability and de-solvation under an aggressive 4.7 V. Consequently, ∼400 W h kg−1 NCM811/Li cells at 4.7 V demonstrate an 82% capacity retention after 200 cycles. Commercial NCM811/Gr pouch cells at 4.5 V achieve 92% capacity retention over 500 cycles, concurrently with unexpectedly high safety performance in terms of thermal, mechanical, and electrical abuse. This work underscores the critical impact of solvation site-occupied cosolvent on the CEI modification and kinetics optimization, opening a new avenue for high voltage electrolyte design.
