Optimization of Wire Electric Discharge Machining (WEDM) Process Parameters for AISI 1045 Medium Carbon Steel Using Taguchi Design of Experiments.

Abstract

With the growth of the manufacturing industry, the demand for alloy materials with high hardness, toughness, and impact strength has increased. Since products from such alloy materials are extremely difficult to manufacture with high accuracy and reduced surface roughness using traditional machining techniques, wire electric discharge machining can be used to machine such complex parts with more precision. In this case-study-based research, machining factors such as current, pulse-on time, and voltage are studied to determine their effects on the material removal rate for AISI 1045 medium carbon steel. The Taguchi L₉ orthogonal array is used in the design of experiments for optimization. Statistical techniques such as analysis of variance and signal-to-noise ratio are used to identify the control parameters that matter most in bringing about optimal results. Based on the results, the current is the most crucial control variable in this investigation. Moreover, the maximum material removal rate obtained was 0.7112 mm³/min with the obtained optimized values of current (I) = 16 A, voltage (V) = 50 V, and pulse-on time (Ton) = 100 µs.
