Effect of Hafnium Alloying on the Structure, Phase Composition and Properties of Cold-Deformed Biocompatible Zr51–xTi31Nb18Hfx (x = 2 – 10 At.%) Alloys Subjected to Annealing

IF 0.5 4区 材料科学 Q4 METALLURGY & METALLURGICAL ENGINEERING
S. V. Grib, S. M. Illarionova, A. S. Yurovskikh, A. G. Illarionov
{"title":"Effect of Hafnium Alloying on the Structure, Phase Composition and Properties of Cold-Deformed Biocompatible Zr51–xTi31Nb18Hfx (x = 2 – 10 At.%) Alloys Subjected to Annealing","authors":"S. V. Grib,&nbsp;S. M. Illarionova,&nbsp;A. S. Yurovskikh,&nbsp;A. G. Illarionov","doi":"10.1007/s11041-025-01125-6","DOIUrl":null,"url":null,"abstract":"<p>Cold-deformed biocompatible alloys Zr<sub>51–<i>x</i></sub>Ti<sub>31</sub>Nb<sub>18</sub>Hf<sub><i>x</i></sub> (<i>x</i> =2– 10 at.%) are investigated after 1-h annealing at 700°C and furnace cooling. The structure, phase composition and texture of the alloys are studied using x-rays phase analysis, scanning electron microscopy and electron backscatter diffraction after micro-indentation and tensile testing. A methodology tested on titanium alloys is used to derive a formula for calculating the temperature of transition of zirconium alloys to a single-phase β-range (the temperature of polymorphic transformation <i>T</i><sub>pt</sub>). It is shown that decrease in the hafnium content provides more developed recrystallization and decelerates the decomposition of the β-solid solution during annealing yielding different second phases (ω, α″, α). The effect of the alloying with hafnium on the textural condition of the alloys during annealing is considered. The relation between the structural and phase conditions of the alloys and their physical and mechanical properties is established and recommendations are developed on the hafnium content ensuring a balanced combination of properties.</p>","PeriodicalId":701,"journal":{"name":"Metal Science and Heat Treatment","volume":"67 1-2","pages":"33 - 41"},"PeriodicalIF":0.5000,"publicationDate":"2025-07-30","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Metal Science and Heat Treatment","FirstCategoryId":"88","ListUrlMain":"https://link.springer.com/article/10.1007/s11041-025-01125-6","RegionNum":4,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q4","JCRName":"METALLURGY & METALLURGICAL ENGINEERING","Score":null,"Total":0}
引用次数: 0

Abstract

Cold-deformed biocompatible alloys Zr51–xTi31Nb18Hfx (x =2– 10 at.%) are investigated after 1-h annealing at 700°C and furnace cooling. The structure, phase composition and texture of the alloys are studied using x-rays phase analysis, scanning electron microscopy and electron backscatter diffraction after micro-indentation and tensile testing. A methodology tested on titanium alloys is used to derive a formula for calculating the temperature of transition of zirconium alloys to a single-phase β-range (the temperature of polymorphic transformation Tpt). It is shown that decrease in the hafnium content provides more developed recrystallization and decelerates the decomposition of the β-solid solution during annealing yielding different second phases (ω, α″, α). The effect of the alloying with hafnium on the textural condition of the alloys during annealing is considered. The relation between the structural and phase conditions of the alloys and their physical and mechanical properties is established and recommendations are developed on the hafnium content ensuring a balanced combination of properties.

Abstract Image

Abstract Image

铪合金化对退火冷变形生物相容性Zr51-xTi31Nb18Hfx (x = 2 - 10 At.%)合金组织、相组成及性能的影响
研究了Zr51-xTi31Nb18Hfx合金(x =2 ~ 10 at.%)在700℃退火1 h后的冷变形。采用x射线相分析、扫描电镜和电子背散射衍射等方法对合金的显微压痕和拉伸性能进行了研究。通过对钛合金的实验,推导出了锆合金向单相β-范围转变温度(多晶转变温度Tpt)的计算公式。结果表明,在退火过程中,铪含量的降低使β-固溶体的再结晶更加发达,并减缓了β-固溶体的分解,产生不同的第二相(ω, α″,α)。考虑了铪合金化对退火过程中合金织构状态的影响。建立了合金的结构和相条件与其物理和机械性能之间的关系,并提出了有关铪含量的建议,以确保性能的平衡组合。
