Copper(I) Iodide–Hexamethylenetetramine Complex as Stable Scintillator for Free-Standing Flexible and High-Resolution X-ray Imaging Screens

IF 8.7 1区化学 Q1 MATERIALS SCIENCE, MULTIDISCIPLINARY

ACS Materials Letters Pub Date : 2025-05-23 DOI:10.1021/acsmaterialslett.5c00649

Sergey A. Fateev, Anna D. Riabova, Daria E. Belikova, Anastasia V. Orlova, Eugene A. Goodilin and Alexey B. Tarasov*,

{"title":"Copper(I) Iodide–Hexamethylenetetramine Complex as Stable Scintillator for Free-Standing Flexible and High-Resolution X-ray Imaging Screens","authors":"Sergey A. Fateev, Anna D. Riabova, Daria E. Belikova, Anastasia V. Orlova, Eugene A. Goodilin and Alexey B. Tarasov*, ","doi":"10.1021/acsmaterialslett.5c00649","DOIUrl":null,"url":null,"abstract":"The organo–inorganic coordination polymer Cu6I6(HMTA)2 (HMTA – hexamethylenetetramine) has been explored as a scintillator for X-ray imaging applications. This material, synthesized from readily available precursors via a scalable solution-based method, exhibits high photoluminescence quantum yield (>95%) and exceptional thermal and radiation stability. Composite scintillation screens (CSS) were fabricated by embedding Cu6I6(HMTA)2 nanoparticles into an ethylene-vinyl acetate (EVA) matrix, achieving high phosphor loading (up to 75 wt %) while maintaining mechanical flexibility. These CSS exhibited a maximum light yield of 63,500 photons/MeV and spatial resolution up to 18 lp/mm (line pairs/mm). Thin-film scintillators, produced by depositing Cu6I6(HMTA)2 on porous membranes, achieved an even higher spatial resolution of 24.5 lp/mm but showed reduced mechanical robustness. Remarkably, Cu6I6(HMTA)2-based screens demonstrated superior radiation stability, retaining 95% of their initial radioluminescence intensity after exposure to high X-ray doses (∼100 Gy). These results highlight the potential of Cu6I6(HMTA)2 as a high-performance scintillator for X-ray imaging applications.","PeriodicalId":19,"journal":{"name":"ACS Materials Letters","volume":"7 7","pages":"2406–2412"},"PeriodicalIF":8.7000,"publicationDate":"2025-05-23","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Materials Letters","FirstCategoryId":"92","ListUrlMain":"https://pubs.acs.org/doi/10.1021/acsmaterialslett.5c00649","RegionNum":1,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q1","JCRName":"MATERIALS SCIENCE, MULTIDISCIPLINARY","Score":null,"Total":0}

引用次数: 0

Abstract

The organo–inorganic coordination polymer Cu₆I₆(HMTA)₂ (HMTA – hexamethylenetetramine) has been explored as a scintillator for X-ray imaging applications. This material, synthesized from readily available precursors via a scalable solution-based method, exhibits high photoluminescence quantum yield (>95%) and exceptional thermal and radiation stability. Composite scintillation screens (CSS) were fabricated by embedding Cu₆I₆(HMTA)₂ nanoparticles into an ethylene-vinyl acetate (EVA) matrix, achieving high phosphor loading (up to 75 wt %) while maintaining mechanical flexibility. These CSS exhibited a maximum light yield of 63,500 photons/MeV and spatial resolution up to 18 lp/mm (line pairs/mm). Thin-film scintillators, produced by depositing Cu₆I₆(HMTA)₂ on porous membranes, achieved an even higher spatial resolution of 24.5 lp/mm but showed reduced mechanical robustness. Remarkably, Cu₆I₆(HMTA)₂-based screens demonstrated superior radiation stability, retaining 95% of their initial radioluminescence intensity after exposure to high X-ray doses (∼100 Gy). These results highlight the potential of Cu₆I₆(HMTA)₂ as a high-performance scintillator for X-ray imaging applications.

Abstract Image

查看原文本刊更多论文

碘化铜-六亚甲基四胺配合物作为独立柔性高分辨率x射线成像屏的稳定闪烁体

有机-无机配位聚合物Cu6I6(HMTA)2 （HMTA -六亚甲基四胺）已被探索作为x射线成像应用的闪烁体。这种材料是通过可扩展的基于溶液的方法从现成的前体合成的，具有高光致发光量子产率（>95%）和优异的热稳定性和辐射稳定性。通过将Cu6I6(HMTA)2纳米颗粒嵌入乙烯-醋酸乙烯（EVA）基质中，制备了复合闪烁屏（CSS），在保持机械柔韧性的同时实现了高荧光粉负载（高达75% wt %）。这些CSS的最大产光量为63,500光子/MeV，空间分辨率高达18 lp/mm（线对/mm）。通过在多孔膜上沉积Cu6I6(HMTA)2制成的薄膜闪烁体达到了24.5 lp/mm的更高空间分辨率，但机械稳健性降低。值得注意的是，基于Cu6I6(HMTA)2的屏幕显示出优越的辐射稳定性，在暴露于高x射线剂量（~ 100 Gy）后保持95%的初始放射发光强度。这些结果突出了Cu6I6(HMTA)2作为x射线成像应用的高性能闪烁体的潜力。

本文章由计算机程序翻译，如有差异，请以英文原文为准。
