Spectral Normalization and Voigt–Reuss net: A universal approach to microstructure-property forecasting with physical guarantees

Abstract

Heterogeneous materials are crucial to producing lightweight components, functional components, and structures composed of them. A crucial step in the design process is the rapid evaluation of their effective mechanical, thermal, or, in general, constitutive properties. The established procedure is to use forward models that accept microstructure geometry and local constitutive properties as inputs. The classical simulation-based approach, which uses, for example, finite elements and FFT-based solvers, can require substantial computational resources. At the same time, simulation-based models struggle to provide gradients with respect to the microstructure and the constitutive parameters. Such gradients are, however, of paramount importance for microstructure design and for inverting the microstructure-property mapping. Machine learning surrogates can excel in these situations. However, they can lead to unphysical predictions that violate essential bounds on the constitutive response, such as the upper (Voigt-like) or the lower (Reuss-like) bound in linear elasticity. Therefore, we propose a novel spectral normalization scheme that a priori enforces these bounds. The approach is fully agnostic with respect to the chosen microstructural features and the utilized surrogate model: It can be linked to neural networks, kernel methods, or combined schemes. All of these will automatically and strictly predict outputs that obey the upper and lower bounds by construction. The technique can be used for any constitutive tensor that is symmetric and where upper and lower bounds (in the Löwner sense) exist, that is, for permeability, thermal conductivity, linear elasticity, and many more. We demonstrate the use of spectral normalization in the Voigt–Reuss net using a simple neural network. Numerical examples on truly extensive datasets illustrate the improved accuracy, robustness, and independence of the type of input features in comparison to much-used neural networks.
