{"title":"Multispectral Polarization-Insensitive Graphene/Silicon Guided Mode Resonance Active Metasurfaces","authors":"Prateeksha Sharma, Dor Oz, Eleftheria Lampadariou, Spyros Doukas, Elefterios Lidorikis, Ilya Goykhman","doi":"10.1002/adpr.202500072","DOIUrl":null,"url":null,"abstract":"<p>An advanced complementary metal-oxide-semiconductor (CMOS)compatible graphene/silicon multispectral active metasurfaces are investigated based on guided-mode resonance filters. The simulated results show a high extinction ratio (>25 dB), narrow linewidth (≈1.5 @1550 nm), quality factor of Q ≈ 1000, and polarization-insensitive operation. By taking advantage of graphene broadband absorption, the device operation is presented in the multiple spectral bands (NIR-MIR) using simple geometrical scaling rules. The same device architecture can be employed for combined electro-optic and thermo-optic tuning using graphene as an integrated microheater. This work contributes to the development of advanced broadband silicon-based active metasurfaces for tunable spectral filters and laser mirrors, optical switches, modulators, and sensors.</p>","PeriodicalId":7263,"journal":{"name":"Advanced Photonics Research","volume":"6 8","pages":""},"PeriodicalIF":3.9000,"publicationDate":"2025-06-09","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://onlinelibrary.wiley.com/doi/epdf/10.1002/adpr.202500072","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Advanced Photonics Research","FirstCategoryId":"1085","ListUrlMain":"https://advanced.onlinelibrary.wiley.com/doi/10.1002/adpr.202500072","RegionNum":0,"RegionCategory":null,"ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"MATERIALS SCIENCE, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0
Abstract
An advanced complementary metal-oxide-semiconductor (CMOS)compatible graphene/silicon multispectral active metasurfaces are investigated based on guided-mode resonance filters. The simulated results show a high extinction ratio (>25 dB), narrow linewidth (≈1.5 @1550 nm), quality factor of Q ≈ 1000, and polarization-insensitive operation. By taking advantage of graphene broadband absorption, the device operation is presented in the multiple spectral bands (NIR-MIR) using simple geometrical scaling rules. The same device architecture can be employed for combined electro-optic and thermo-optic tuning using graphene as an integrated microheater. This work contributes to the development of advanced broadband silicon-based active metasurfaces for tunable spectral filters and laser mirrors, optical switches, modulators, and sensors.
