Comparison of CT-like MRI sequences for preoperative planning of cochlear implantation using super-high-resolution CT as a reference.

Abstract

Background: We evaluated the accuracy of magnetic resonance imaging (MRI) computed tomography (CT)-like sequences compared to normal-resolution CT (NR-CT) and super-high-resolution CT (SHR-CT) for planning of cochlear implantation.

Methods: Six cadaveric temporal bone specimens were used. 3-T MRI scans were performed using radial volumetric interpolated breath-hold (STARVIBE), pointwise-encoding time reduction with radial acquisition (PETRA), and ultrashort time of echo (UTE) sequences. CT scans were performed on two scanners for SHR-CT and NR-CT acquisitions. Two radiologists evaluated accuracy based on preimplantation metrics and the ability to identify various anatomical structures, particularly the facial recess and round window. Wilcoxon rank-sum test and intraclass correlation coefficient (ICC) were used.

Results: The facial nerve was always clearly visible (score ≥ 2) in the MRI, NR-CT, and SHR-CT scans (p ≥ 0.621). However, the chorda tympani nerve (CTN) was clearly visualized in UTE, STARVIBE, and PETRA sequences in only 33% (2/6 specimens, p = 0.016), 50% (3/6 specimens, p = 0.038), and 83% (5/6 specimens, p = 0.017) of cases, respectively, whereas it was always clearly visualized in SHR and NR-CT (p = 0.426). The round window (RW) was never visualized in MRI sequences (p ≤ 0.010), whereas it was identified in all cases in SHR and NR-CT (p = 1.000). There was a strong correlation between measurements obtained from MRI and CT modalities (ICC ≥ 0.837).

Conclusion: MRI CT-like sequences assessed the facial nerve in all cases and the CTN in up to 87% of cases. However, the detection of the RW was insufficient for surgical planning. CT and MRI measurements were in agreement.

Relevance statement: CT-like MRI sequences can image the anatomy of the facial recess and the length of the basal turn of the cochlea with similar accuracy as conventional CT, although they cannot image the round window.

Key points: CT-like MRI sequences are not widely used in preoperative cochlear implantation imaging. CT-like sequences can image the facial recess as well as conventional CT. CT-like sequences can image the basal turn length of the cochlea as well as conventional CT. Round window depiction is not possible with CT-like MRI sequences.
