Is conventional magnetic resonance imaging superior to radiography in the functional integrity evaluation of anterior cruciate ligament in patients with knee osteoarthritis?
Zhenguo Yu, Hongqing Wang, Xiaoyu Wang, Xin Dong, Jie Dong, Qingchen Liang, Fenglong Sun
{"title":"Is conventional magnetic resonance imaging superior to radiography in the functional integrity evaluation of anterior cruciate ligament in patients with knee osteoarthritis?","authors":"Zhenguo Yu, Hongqing Wang, Xiaoyu Wang, Xin Dong, Jie Dong, Qingchen Liang, Fenglong Sun","doi":"10.1186/s42836-024-00262-2","DOIUrl":null,"url":null,"abstract":"<p><strong>Background: </strong>The functional integrity of the anterior cruciate ligament (ACL) influences surgical decision-making in patients with knee osteoarthritis (KOA). This study aimed to compare the diagnostic value of radiography and magnetic resonance imaging (MRI) in determining the functional status of ACL.</p><p><strong>Methods: </strong>We analyzed 306 knees retrospectively using preoperative hip-to-ankle anteroposterior standing (APS) radiographs, anteroposterior (AP) and lateral knee radiographs, AP valgus stress (VS) force radiographs, and standard orthogonal MRI. Based on the intraoperative visualization, the knees were grouped into ACL functionally-intact and ACL functionally-deficient (ACLD) groups. The diagnostic validity and reliability were calculated based on the radiograph parameters such as hip-knee-ankle angle (HKA), medial proximal tibial angle (MPTA), lateral distal femoral angle (LDFA), posterior tibial slope (PTS), sagittal tibiofemoral subluxation (STFS), coronal tibiofemoral subluxation (CTFS), joint line convergence angle (JLCA), the maximum wear point of the proximal tibia plateau (MWPPT%), and MRI parameters including ACL grades and MWPPT%.</p><p><strong>Results: </strong>HKA, MPTA, PTS, STFS, JLCA, and CTFS on APS and AP radiographs, and MWPPT% on radiographs and MRI showed a significant diagnostic value (P < 0.05). There were no statistically significant differences in the single parameters from radiographs and MRI. After constructing the logistic regression models, MRI showed higher sensitivity, specificity, and accuracy, reaching 96.8%, 79.9%, and 83.3%, respectively (P < 0.001).</p><p><strong>Conclusions: </strong>In patients with KOA, the diagnostic value of single radiographic or MRI parameter in assessing the functional integrity of the ACL are equivalent. However, by constructing predictive models, MRI could significantly improve diagnostic validity compared with radiography.</p>","PeriodicalId":2,"journal":{"name":"ACS Applied Bio Materials","volume":null,"pages":null},"PeriodicalIF":4.6000,"publicationDate":"2024-06-20","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11188244/pdf/","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Applied Bio Materials","FirstCategoryId":"3","ListUrlMain":"https://doi.org/10.1186/s42836-024-00262-2","RegionNum":0,"RegionCategory":null,"ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"MATERIALS SCIENCE, BIOMATERIALS","Score":null,"Total":0}
引用次数: 0
Abstract
Background: The functional integrity of the anterior cruciate ligament (ACL) influences surgical decision-making in patients with knee osteoarthritis (KOA). This study aimed to compare the diagnostic value of radiography and magnetic resonance imaging (MRI) in determining the functional status of ACL.
Methods: We analyzed 306 knees retrospectively using preoperative hip-to-ankle anteroposterior standing (APS) radiographs, anteroposterior (AP) and lateral knee radiographs, AP valgus stress (VS) force radiographs, and standard orthogonal MRI. Based on the intraoperative visualization, the knees were grouped into ACL functionally-intact and ACL functionally-deficient (ACLD) groups. The diagnostic validity and reliability were calculated based on the radiograph parameters such as hip-knee-ankle angle (HKA), medial proximal tibial angle (MPTA), lateral distal femoral angle (LDFA), posterior tibial slope (PTS), sagittal tibiofemoral subluxation (STFS), coronal tibiofemoral subluxation (CTFS), joint line convergence angle (JLCA), the maximum wear point of the proximal tibia plateau (MWPPT%), and MRI parameters including ACL grades and MWPPT%.
Results: HKA, MPTA, PTS, STFS, JLCA, and CTFS on APS and AP radiographs, and MWPPT% on radiographs and MRI showed a significant diagnostic value (P < 0.05). There were no statistically significant differences in the single parameters from radiographs and MRI. After constructing the logistic regression models, MRI showed higher sensitivity, specificity, and accuracy, reaching 96.8%, 79.9%, and 83.3%, respectively (P < 0.001).
Conclusions: In patients with KOA, the diagnostic value of single radiographic or MRI parameter in assessing the functional integrity of the ACL are equivalent. However, by constructing predictive models, MRI could significantly improve diagnostic validity compared with radiography.
