Postoperative Extremity Tomosynthesis-A Superimposition-Free Alternative to Standard Radiography?

IF 7 1区医学 Q1 RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING

Investigative Radiology Pub Date : 2024-11-01 Epub Date: 2024-05-07 DOI:10.1097/RLI.0000000000001085

Jan-Peter Grunz, Andreas Steven Kunz, Mila Marie Paul, Karsten Sebastian Luetkens, Henner Huflage, Nora Conrads, Süleyman Ergün, Thomas Weber, Magdalena Herbst, Sophia Herold, Thorsten Alexander Bley, Theresa Sophie Patzer

{"title":"Postoperative Extremity Tomosynthesis-A Superimposition-Free Alternative to Standard Radiography?","authors":"Jan-Peter Grunz, Andreas Steven Kunz, Mila Marie Paul, Karsten Sebastian Luetkens, Henner Huflage, Nora Conrads, Süleyman Ergün, Thomas Weber, Magdalena Herbst, Sophia Herold, Thorsten Alexander Bley, Theresa Sophie Patzer","doi":"10.1097/RLI.0000000000001085","DOIUrl":null,"url":null,"abstract":"Rationale and objectives: This study investigates the performance of tomosynthesis in the presence of osteosynthetic implants, aiming to overcome superimposition-induced limitations in conventional radiograms.Materials and methods: After surgical fracture induction and subsequent osteosynthesis, 8 cadaveric fracture models (wrist, metacarpus, ankle, metatarsus) were scanned with the prototypical tomosynthesis mode of a multiuse x-ray system. Tomosynthesis protocols at 60, 80, and 116 kV (sweep angle 10°, 13 FPS) were compared with standard radiograms. Five radiologists independently rated diagnostic assessability based on an equidistant 7-point scale focusing on fracture delineation, intra-articular screw placement, and implant positioning. The intraclass correlation coefficient (ICC) was calculated to analyze interrater agreement.Results: Radiation dose in radiography was 0.48 ± 0.26 dGy·cm 2 versus 0.12 ± 0.01, 0.36 ± 0.02, and 1.95 ± 0.11 dGy·cm 2 for tomosynthesis scans at 60, 80, and 116 kV. Delineation of fracture lines was superior for 80/116 kV tomosynthesis compared with radiograms ( P ≤ 0.003). Assessability of intra-articular screw placement was deemed favorable for all tomosynthesis protocols ( P ≤ 0.004), whereas superiority for evaluation of implant positioning could not be ascertained (all P 's ≥ 0.599). Diagnostic confidence was higher for 80/116 kV tomosynthesis versus radiograms and 60 kV tomosynthesis ( P ≤ 0.002). Interrater agreement was good for fracture delineation (ICC, 0.803; 95% confidence interval [CI], 0.598-0.904), intra-articular screw placement (ICC, 0.802; 95% CI, 0.599-0.903), implant positioning (ICC, 0.855; 95% CI, 0.729-0.926), and diagnostic confidence (ICC, 0.842; 95% CI, 0.556-0.934).Conclusions: In the postoperative workup of extremity fractures, tomosynthesis allows for superior assessment of fracture lines and intra-articular screw positioning with greater diagnostic confidence at radiation doses comparable to conventional radiograms.","PeriodicalId":14486,"journal":{"name":"Investigative Radiology","volume":" ","pages":"761-766"},"PeriodicalIF":7.0000,"publicationDate":"2024-11-01","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11462900/pdf/","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Investigative Radiology","FirstCategoryId":"3","ListUrlMain":"https://doi.org/10.1097/RLI.0000000000001085","RegionNum":1,"RegionCategory":"医学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2024/5/7 0:00:00","PubModel":"Epub","JCR":"Q1","JCRName":"RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING","Score":null,"Total":0}

引用次数: 0

Abstract

Rationale and objectives: This study investigates the performance of tomosynthesis in the presence of osteosynthetic implants, aiming to overcome superimposition-induced limitations in conventional radiograms.

Materials and methods: After surgical fracture induction and subsequent osteosynthesis, 8 cadaveric fracture models (wrist, metacarpus, ankle, metatarsus) were scanned with the prototypical tomosynthesis mode of a multiuse x-ray system. Tomosynthesis protocols at 60, 80, and 116 kV (sweep angle 10°, 13 FPS) were compared with standard radiograms. Five radiologists independently rated diagnostic assessability based on an equidistant 7-point scale focusing on fracture delineation, intra-articular screw placement, and implant positioning. The intraclass correlation coefficient (ICC) was calculated to analyze interrater agreement.

Results: Radiation dose in radiography was 0.48 ± 0.26 dGy·cm 2 versus 0.12 ± 0.01, 0.36 ± 0.02, and 1.95 ± 0.11 dGy·cm 2 for tomosynthesis scans at 60, 80, and 116 kV. Delineation of fracture lines was superior for 80/116 kV tomosynthesis compared with radiograms ( P ≤ 0.003). Assessability of intra-articular screw placement was deemed favorable for all tomosynthesis protocols ( P ≤ 0.004), whereas superiority for evaluation of implant positioning could not be ascertained (all P 's ≥ 0.599). Diagnostic confidence was higher for 80/116 kV tomosynthesis versus radiograms and 60 kV tomosynthesis ( P ≤ 0.002). Interrater agreement was good for fracture delineation (ICC, 0.803; 95% confidence interval [CI], 0.598-0.904), intra-articular screw placement (ICC, 0.802; 95% CI, 0.599-0.903), implant positioning (ICC, 0.855; 95% CI, 0.729-0.926), and diagnostic confidence (ICC, 0.842; 95% CI, 0.556-0.934).

Conclusions: In the postoperative workup of extremity fractures, tomosynthesis allows for superior assessment of fracture lines and intra-articular screw positioning with greater diagnostic confidence at radiation doses comparable to conventional radiograms.

查看原文本刊更多论文

术后四肢断层摄影--标准放射摄影的无叠加替代品？

理由和目的：本研究调查了在存在骨合成植入物的情况下断层合成的性能，旨在克服传统射线照片中叠加引起的局限性：在手术诱导骨折并随后进行骨合成后，使用多用途 X 光系统的原型断层合成模式扫描 8 个尸体骨折模型（腕部、掌骨、踝关节、跖骨）。将 60、80 和 116 kV（扫描角度 10°，13 FPS）的断层合成方案与标准射线照片进行了比较。五位放射科医生根据等距 7 分制独立评定诊断可评估性，重点是骨折划线、关节内螺钉置入和植入物定位。通过计算类内相关系数（ICC）来分析医生间的一致性：结果：在 60、80 和 116 千伏电压下，放射摄影的辐射剂量为 0.48 ± 0.26 dGy-cm2，而断层扫描的辐射剂量分别为 0.12 ± 0.01、0.36 ± 0.02 和 1.95 ± 0.11 dGy-cm2。与射线照片相比，80/116 千伏断层扫描对骨折线的描述更清晰（P ≤ 0.003）。对关节内螺钉置放的评估在所有断层扫描方案中都是有利的（P ≤ 0.004），而对植入物定位的评估则无法确定其优劣（所有 P 均≥ 0.599）。80/116 kV断层扫描的诊断可信度高于放射摄影和60 kV断层扫描（P≤0.002）。在骨折分界（ICC，0.803；95% 置信区间[CI]，0.598-0.904）、关节内螺钉置入（ICC，0.802；95% CI，0.599-0.903）、植入物定位（ICC，0.855；95% CI，0.729-0.926）和诊断可信度（ICC，0.842；95% CI，0.556-0.934）方面，术者之间的一致性良好：结论：在四肢骨折的术后检查中，断层合成术可对骨折线和关节内螺钉定位进行更好的评估，诊断可信度更高，而辐射剂量与传统放射线造影相当。

本文章由计算机程序翻译，如有差异，请以英文原文为准。
