Subintimal shift as mechanism for side-branch occlusion in percutaneous treatment of chronic total occlusions with bifurcation lesions.

Background: The aim of this study was to describe the mechanism of subintimal shift (SIS), standardise diagnostic criteria and sensitise the interventional community to this phenomenon. The treatment of chronic total occlusions (CTO) by means of percutaneous coronary intervention (PCI) is complicated by bifurcation lesions involved in the CTO segment or adjacent to it. Extraplaque expansion of intracoronary devices during CTO PCI may extend the dissection plane over the bifurcation with the consequential side or main branch compression by an intimo-medial flap. This phenomenon is hereby described for the first time and named subintimal shift.

Methods: Experienced CTO operators from 3 international high volume centers for CTO PCI retrospectively searched their personal records for paradigmatic cases of SIS, summarising key features and proposing diagnostic criteria.

Results: The series comprised 7 demonstrative cases, illustrating SIS by intravascular imaging (2 cases) or indirect angiographic signs during CTO PCI (5 cases). Five cases were triggered by stent expansion, 1 by balloon inflation and 1 case was aborted after angiographic warning signs. In 4 cases, SIS resulted in total occlusion of a branch, refractory to ballooning whenever attempted. Four cases required bailout intervention and in 2 cases the branch was left occluded, resulting in a rise of cardiac markers.

Conclusions: Subintimal shift is a noteworthy complication in CTO bifurcations, potentially resulting in occlusion of the relevant side or even the main branch. Intracoronary imaging prior to stenting is recommended to understand the tissue planes. Some counterintuitive peculiarities of this phenomenon, like its refractoriness to ballooning, must be known by CTO operators for its efficient resolution.
