Er:YAG、Er:Cr:YSGG和Ho:Yb:Cr:YSGG高功率二极管泵浦激光器

IF 0.7 4区 物理与天体物理 Q4 PHYSICS, MULTIDISCIPLINARY
V. P. Mitrokhin, A. D. Savvin, V. A. Simonova, A. A. Sirotkin, K. N. Firsov, A. E. Dormidonov
{"title":"Er:YAG、Er:Cr:YSGG和Ho:Yb:Cr:YSGG高功率二极管泵浦激光器","authors":"V. P. Mitrokhin,&nbsp;A. D. Savvin,&nbsp;V. A. Simonova,&nbsp;A. A. Sirotkin,&nbsp;K. N. Firsov,&nbsp;A. E. Dormidonov","doi":"10.3103/S1068335625600160","DOIUrl":null,"url":null,"abstract":"<p>We study the oscillation of three-micron lasers based on Er<sup>3+</sup>:YAG, Er<sup>3+</sup>:Cr<sup>3+</sup>: YSGG, and Ho<sup>3+</sup>:Yb<sup>3+</sup>:Cr<sup>3+</sup>:YSGG crystals under optical pumping by pulsed diode arrays with a total peak power of up to 15 kW at a wavelength of 970 nm and a pulse repetition rate of up to 50 Hz. In a diode-pumped Er<sup>3+</sup>:Cr<sup>3+</sup>:YSGG laser, the maximum output energy of more than 0.8 J was achieved for the first time in the free lasing regime. In the case of active g-switching, the peak power of the output laser pulses with a duration of 55 ns exceeded 1 MW with an energy stability (standard deviation) of less than 3%. Using the developed laser systems as sources for stable pulsed pumping of a Fe<sup>2+</sup>:ZnSe single-crystal laser with a short optical cavity, pulses with a duration of less than 2 ns at a wavelength in the vicinity of 4.3 μm were obtained.</p>","PeriodicalId":503,"journal":{"name":"Bulletin of the Lebedev Physics Institute","volume":"52 1 supplement","pages":"S7 - S17"},"PeriodicalIF":0.7000,"publicationDate":"2025-05-31","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Er:YAG, Er:Cr:YSGG, and Ho:Yb:Cr:YSGG Lasers with High Power Diode Pumping\",\"authors\":\"V. P. Mitrokhin,&nbsp;A. D. Savvin,&nbsp;V. A. Simonova,&nbsp;A. A. Sirotkin,&nbsp;K. N. Firsov,&nbsp;A. E. Dormidonov\",\"doi\":\"10.3103/S1068335625600160\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p>We study the oscillation of three-micron lasers based on Er<sup>3+</sup>:YAG, Er<sup>3+</sup>:Cr<sup>3+</sup>: YSGG, and Ho<sup>3+</sup>:Yb<sup>3+</sup>:Cr<sup>3+</sup>:YSGG crystals under optical pumping by pulsed diode arrays with a total peak power of up to 15 kW at a wavelength of 970 nm and a pulse repetition rate of up to 50 Hz. In a diode-pumped Er<sup>3+</sup>:Cr<sup>3+</sup>:YSGG laser, the maximum output energy of more than 0.8 J was achieved for the first time in the free lasing regime. In the case of active g-switching, the peak power of the output laser pulses with a duration of 55 ns exceeded 1 MW with an energy stability (standard deviation) of less than 3%. Using the developed laser systems as sources for stable pulsed pumping of a Fe<sup>2+</sup>:ZnSe single-crystal laser with a short optical cavity, pulses with a duration of less than 2 ns at a wavelength in the vicinity of 4.3 μm were obtained.</p>\",\"PeriodicalId\":503,\"journal\":{\"name\":\"Bulletin of the Lebedev Physics Institute\",\"volume\":\"52 1 supplement\",\"pages\":\"S7 - S17\"},\"PeriodicalIF\":0.7000,\"publicationDate\":\"2025-05-31\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Bulletin of the Lebedev Physics Institute\",\"FirstCategoryId\":\"101\",\"ListUrlMain\":\"https://link.springer.com/article/10.3103/S1068335625600160\",\"RegionNum\":4,\"RegionCategory\":\"物理与天体物理\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q4\",\"JCRName\":\"PHYSICS, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Bulletin of the Lebedev Physics Institute","FirstCategoryId":"101","ListUrlMain":"https://link.springer.com/article/10.3103/S1068335625600160","RegionNum":4,"RegionCategory":"物理与天体物理","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q4","JCRName":"PHYSICS, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

本文研究了Er3+:YAG、Er3+:Cr3+: YSGG和Ho3+:Yb3+:Cr3+:YSGG三微米激光器在脉冲二极管阵列光泵浦下的振荡,在970 nm波长下,脉冲重复频率高达50 Hz,总峰值功率高达15 kW。在二极管泵浦的Er3+:Cr3+:YSGG激光器中,首次在自由激光区实现了大于0.8 J的最大输出能量。在主动g开关情况下,持续时间为55 ns的输出激光脉冲的峰值功率超过1 MW,能量稳定性(标准差)小于3%。利用所研制的激光系统作为短光腔Fe2+:ZnSe单晶激光器的稳定脉冲泵浦源,在波长4.3 μm附近获得了持续时间小于2 ns的脉冲。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Er:YAG, Er:Cr:YSGG, and Ho:Yb:Cr:YSGG Lasers with High Power Diode Pumping

Er:YAG, Er:Cr:YSGG, and Ho:Yb:Cr:YSGG Lasers with High Power Diode Pumping

We study the oscillation of three-micron lasers based on Er3+:YAG, Er3+:Cr3+: YSGG, and Ho3+:Yb3+:Cr3+:YSGG crystals under optical pumping by pulsed diode arrays with a total peak power of up to 15 kW at a wavelength of 970 nm and a pulse repetition rate of up to 50 Hz. In a diode-pumped Er3+:Cr3+:YSGG laser, the maximum output energy of more than 0.8 J was achieved for the first time in the free lasing regime. In the case of active g-switching, the peak power of the output laser pulses with a duration of 55 ns exceeded 1 MW with an energy stability (standard deviation) of less than 3%. Using the developed laser systems as sources for stable pulsed pumping of a Fe2+:ZnSe single-crystal laser with a short optical cavity, pulses with a duration of less than 2 ns at a wavelength in the vicinity of 4.3 μm were obtained.

求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
Bulletin of the Lebedev Physics Institute
Bulletin of the Lebedev Physics Institute PHYSICS, MULTIDISCIPLINARY-
CiteScore
0.70
自引率
25.00%
发文量
41
审稿时长
6-12 weeks
期刊介绍: Bulletin of the Lebedev Physics Institute is an international peer reviewed journal that publishes results of new original experimental and theoretical studies on all topics of physics: theoretical physics; atomic and molecular physics; nuclear physics; optics; lasers; condensed matter; physics of solids; biophysics, and others.
×
