Study on Nitrogen Doped Hollow Cubic Carbon Electromagnetic Wave Absorbing Materials

Carbon based materials have the characteristics of light weight, adjustable dielectric and stable performance, so they have become the most concerned wave absorbing materials. In this paper, phenolic resin was prepared with sodium chloride as template, and then L-lysine as nitrogen source was used to add nitrogen into phenolic resin, and the final nitrogen doped hollow cubic carbon material was obtained by etching after carbonization. During the experiment, the material with excellent wave absorbing performance was prepared by controlling the doping amount of nitrogen element. Finally, it was found that the nitrogen-doped hollow cubic carbon wave absorbing material could obtain the best reflection loss of –50.26 dB and the maximum effective bandwidth of 4.68 GHz at the extremely low load of 1.75 wt %. The one-component wave absorbing material can have good absorbing performance under very low load, which can become the best candidate material for lightweight and efficient electromagnetic wave absorber without adding other materials, and achieve the purpose of “wide, strong, light and thin.”
